Owner's Manual
120V AC
Heat Alarm
9V
with
Battery
Back-up
WARNING! Heat alarms are not life safety devices and are not designed to
detect smoke or fire. Heat alarms detect temperatures of 135°
and are intended to be used as supplements to smoke alarms by providing
early warning. See the IMPORTANT SAFETY INFORMATION section of this
manual.
Printed information describing proper installation, operation, testing,
maintenance, evacuation planning, and repair service is provided with
this equipment in this manual.
• This heat alarm is powered by 120V AC and a 9-volt battery
back-up source. AC/DC heat alarms offer added protection in the
event of a power failure or a drained battery.
• Unique power connector prevents interconnection with
incompatible heat alarms, smoke alarms, or security systems.
• This heat alarm is interconnectable to a maximum of 12 Firex
devices. It is compatible with Firex smoke alarm models AD,
ADC, and FADC. It can be interconnected with Firex heat alarm
model ADH (6 maximum).
• Optional tamper-resist feature.
• Unique "battery missing" lockout – heat alarm will not attach to
the mounting bracket if a battery is not in the battery pocket.
• Improperly connected or weak battery signal – heat alarm will
sound a short beep once a minute if the battery is weak or
improperly connected.
• Green LED indicates that the heat alarm is receiving AC power,
working under normal operation, or in alarm.
• Loud alarm horn—85 decibels at 10 feet—sounds to alert you
to an emergency.
• Test button checks heat alarm operation.
SPECIFICATIONS
Model Number:
Electrical Rating:
Interconnect Quantity:
U.L. temperature rating:
U.L. Maximum ambient
temperature at unit:
Operating temperature:
U.L. Recommended coverage: 2500 square feet (see Note A)
U.L. Recommended spacing:
Maximum distance from wall:
NOTE A: Maximum alarm coverage has been determined by UL to provide detection
time equal to sprinkler devices spaced at 10-ft intervals (100 square foot area) on a
smooth ceiling 15 ft 9 in. high. Higher ceilings can adversely affect detection time. In
some instances, earlier detection may be obtained by reducing the distance between
detectors. See the latest edition of the NFPA 72E, Automatic Fire Detectors.
NOTE B: Maximum distance is measured from any wall partition or ceiling projection
extending down more than 12 inches.
IMPORTANT SAFETY INFORMATION
!
• This heat alarm requires constant 120-volt, AC power AND
a working 9-volt battery to operate properly. This heat alarm
WILL NOT work if AC power is not connected, has failed, or
has been interrupted for any reason AND if the battery is
removed, drained or improperly connected. DO NOT use any
other kind of battery except as specified in this manual. DO
NOT connect this heat alarm to any smoke alarm, heat alarm,
or auxiliary device, except those listed in this manual.
• The Push-to-Test button accurately tests all heat alarm
functions. For temperatures that are below -10°F use a hand
held hair dryer and blow hot air into heat alarm to test. DO
NOT use any other test method. Test heat alarm weekly to
ensure proper operation.
• This heat alarm should be installed only by a licensed, qual-
ified electrician. Observe and follow all local and national elec-
trical and building codes for installation.
HEAT ALARM FEATURES
ADH
120 VAC, 60 HZ, 80mA, max, 9 volt battery back-up
12 units maximum
135°F (58°C) fixed temperature
100°F
-10°F to 158°F (-23°C to 70°C)
50 feet
25 feet (see Note B)
PLEASE READ AND SAVE
THESE INSTRUCTIONS
W A R N I N G
MODEL ADH
PLEASE READ AND SAVE
THIS MANUAL
Installer: Please leave this
manual with the product.
110-609F
or greater,
F
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Firex ADH
Summary of Contents for Firex ADH
- Page 1 • Unique power connector prevents interconnection with incompatible heat alarms, smoke alarms, or security systems. • This heat alarm is interconnectable to a maximum of 12 Firex devices. It is compatible with Firex smoke alarm models AD, ADC, and FADC. It can be interconnected with Firex heat alarm model ADH (6 maximum).
- Page 2 • This heat alarm IS NOT designed to be the PRIMARY protection for buildings that require complete fire alarm systems. Buildings of thistype includes hotels, motels, dormito- ries, hospitals, nursing homes, and group homes. This is true even if they were once single family homes. However, this heat alarm MAY be used inside individual rooms as SUPPLEMENTAL protection.
- Page 3 “11.5.1.1 Where required by applicable laws, codes, or standards for the specified occupancy, approved single- and multiple-sta- tion smoke alarms shall be installed as follows: 1. In all sleeping rooms Exception: Smoke alarms shall not be required in sleeping rooms in existing one- and two-family swelling units.
-
Page 4: How To Install
DO NOT install heat alarms: • In areas with high humidity, like bathrooms or areas near dish- washers or washing machines. Install at least 10 feet (3 meters) away from these areas, if possible. • Near air returns, heating and cooling supply vents, fans, deco- rative objects, window molding etc. - Page 5 15. Test heat alarm. See TESTING THE HEAT ALARM. INTERCONNECTING HEAT ALARMS • This heat alarm is interconnectable to a maximum of 12 Firex devices. It is compatible with Firex smoke alarm models AD, ADC, and FADC. It can be interconnected with Firex heat alarm model ADH (6 maximum).
-
Page 6: Battery Replacement
If the heat alarm is no longer under warranty, have a licensed electrician replace the heat alarm immediately with a comparable Firex brand heat alarm. PRACTICE FIRE SAFETY If the heat alarm sounds its alarm horn, and you have not pushed the test button, it is warning of a dangerous situation. -
Page 7: Troubleshooting
• Expose everyone to the sound of the smoke alarm and heat alarm and explain what the sounds means. • Determine TWO exits from each room and an escape route to the outside from each exit. • Teach all household members to touch the door and use an alternate exit if the door is hot. -
Page 8: Warranty Information
WARRANTY INFORMATION Invensys Controls Americas warrants to the original consumer purchaser each new heat alarm, excluding battery, to be free from defects in material and workmanship under nor- mal use and service for a period of five (5) years from the date of purchase. Invensys Controls Americas agrees to repair or replace, at its option, any defective heat alarm pro- vided that it is returned with postage prepaid and with proof of purchase date to Invensys Controls Americas.
