- Page 1 Manual #15000000 XciteRC Hotbee 3D Quadrocopter...
-
Page 2: Table Of Contents
Text and illustrations of this manual, no claims can be derived. NO LIABILITY FOR PRINTING ERROR! SUBJECT TO CHANGE! The latest version of this manual can be found on the Internet at www.XciteRC.de © Copyright 2013 by XciteRC-Modellbau GmbH & Co. KG... -
Page 3: Intended Usage
All rights reserved. Intended Usage The XciteRC Hotbee 3D Quadrocopter is an electrically driven ready to fly RC helicopter including motor and speed controller. The control is wireless with an optional available 2.4 GHz transmitter. The model may only be operated on a suitable and sufficiently indoor room without obstacles. An operation outdoor is not recommended. -
Page 4: Warnings And Safety Notes
The following safety instructions must be strictly observed. For property damage, personal injury or conse- quential damage caused by improper use or non-observance of the safety instructions the XciteRC Modell- bau GmbH & Co. KG accepts no liability. In these cases, the warranty becomes void. -
Page 5: Handling Precautions For Batteries Or Rechargeable Batteries
The XciteRC Modellbau GmbH & Co. KG cannot monitor the proper use of the battery or batteries you use, therefore, the warranty is excluded due to incorrect charging or discharging. -
Page 6: Attention Before Flight
(front of pilot). The left hand of pilot Is the left side of Hotbee 3D Quadrocopter, the right hand of pilot Is the right side of Hotbee 3D Quadrocopter. Its head is to the front and its tail boom is to the back. -
Page 7: Lnstruction For Charger
• Pull down the throttle stick to the lowest position. • Turn on the power of transmitter. • Install the battery pack in the battery compartment. • Connect the power cable of to receive signal from transmitter. 15000000 XciteRC Hotbee 3D Quadrocopter... -
Page 8: Flight Control Diagram
3. When moving the rudder stick left or right, the 4. When moving the elevator stick up or down, head of helicopter accordingly flies left or right. the helicopter accordingly flies forward or back- ward. 15000000 XciteRC Hotbee 3D Quadrocopter... - Page 9 The default selling is 100%. • Practice of throttle slick: when the Hotbee 3D roll from normal status,the throttle stick need to be pulled • down slowly; push up the throttle when it exchanged normal status to roll. Please adjust according •...
-
Page 10: Steps Of Ending Flight
• The front propellers are in orange color while the rear propellers are in black • After connecting the power of the Hotbee 3D, left rear / right front blades rotate clockwise, left front / right rear blades rotate counterclockwise. -
Page 11: Exploded View
Overall length 127.7 mm Overall height 36 mm All-up weight 35 g Main rotor blade Dia 56 mm Overall rotation Dia 176 mm Battery 3.7 V 250 mAh 15C Flight time 6 to 7 min. 15000000 XciteRC Hotbee 3D Quadrocopter... -
Page 12: Repairs
Some parts are available as spares. If a part is defective or worn, you can identify it with the help of the exploded view. In case of problems or questions, please contact your dealer or: XciteRC Modellbau GmbH & Co. KG - Service, Autenbachstrasse 12, D-73035 Göppingen, Phone +49 7161 40 799 50 Email: service@xciterc.de Spare parts you may order in your local hobby shop or online at http://www.XciteRC.de/... -
Page 13: Environmental Protection Notes
This crossed-out bin means that you must not dispose of batteries with household waste. Among these characters, see also the following symbols have the following meanings: • Cd = cadmium • Pb = plumbium • Hg = mercury • Li = lithium Li-Po 15000000 XciteRC Hotbee 3D Quadrocopter... -
Page 14: Spare Parts
Motor Pedestal negative complete Potence moteur complète rotation à droite Pales de rotor black (2) Potence moteur complète rotation à gauche 13000027 15000015 Rotorblätter orange (2) LiPo-Ladegerät Orange Blades (2) LiPo-Charger Pales de rotor orange (2) Chargeur LiPo 15000000 XciteRC Hotbee 3D Quadrocopter... - Page 15 Conformité 15000000 XciteRC Hotbee 3D Quadrocopter...
- Page 16 XciteRC Modellbau GmbH & Co. KG Autenbachstraße 12 D-73035 Göppingen Phone: +49 7161 40 799 0 Fax: +49 7161 40 799 99 E-Mail: info@xciterc.de Web: www.XciteRC.de...
