  • Page 1 SparVision 200 SparVision 200 SparVision 200 SparVision 200 SparVision 200 V i d e o I n s p e c t i o n S y s t e m V i d e o I n s p e c t i o n S y s t e m...
  • Page 2 Warning Warning Warning Warning Read the safety and operating instructions before using any Spartan Tool products. — Drain and sewer cleaning can be dangerous if proper procedures are not followed and appropri- ate safety gear is not utilized. Before starting unit, be sure to wear personal protective equipment such as safety —...

  • Page 3: Table Of Contents

    Contents Contents Contents Contents Contents Operating Section SparVision 200 Features ............................4-5 Unpacking .................................... 6 Description ..................................6 Safety Instructions ................................6-8 Familiarization ................................9-10 iPad Application ................................11 Operating Instructions & Tips ..........................12-13 Battery Operation and Charging ..........................14 Trap-Eze (optional) ................................. 15 Maintenance ..................................

  • Page 4: Sparvision 200 Features

    SparVision 200 Features SparVision 200 Features SparVision 200 Features SparVision 200 Features SparVision 200 Features 16 GB IPAD WITH RETINA DISPLAY 9.7-inch (diagonal) LED-backlit Multi-Touch display with IPS technology 2048-by-1536 resolution at 264 pixels per inch (ppi) 16gig On-board memory Bluetooth 4.0 wireless technology...
  • Page 5 SparVision 200 Features SparVision 200 Features SparVision 200 Features SparVision 200 Features SparVision 200 Features SELF-LEVELING COLOR CAMERA HEAD 1.375” diameter 1.812” length 0.5 LUX sensitivity (without lights) 3.7 mm wide angle lens 768 Effective Pixel (horizontal) 494 Effective Pixel (vertical)

  • Page 6: Unpacking

    By doing so, you have cut off your protection from shock. The SparVision 200 must be grounded while charging or operating using the 110V power cord to protect the operator from electrical shock. The SparVision 200 comes with a three-conductor cord and three-prong grounding type plug to fit the properly grounded receptacle.
  • Page 7 D. AVOID ELECTRICAL CORD ABUSE — Never move or lift Spartan Tool equipment by the cord. Do not yank cord at one end to disconnect it from the receptacle. Keep cord away from heat, oil and sharp edges to avoid damage. Always replace or repair damaged cords.
  • Page 8 CAUTION #3 Drains/sewers carry bacteria and the possibility of infectious disease exists, if exposed. A. Always wear safety goggles and Spartan Tool riveted gloves with rubber gloves inside the riveted gloves to minimize exposure to infection from bacteria in pipes.

  • Page 9: Familiarization

    Familiarization Familiarization Familiarization Familiarization Familiarization External Reel Connector iPad Lid Latch Fig. 9-1 System Power Battery Fuse Toggle Switch Camera Home Fig. 9-2 Telescoping Handle Push Rod Drum AC Fuse Block AC Cord Fig. 9-3 Page 9...
  • Page 10 Familiarization (cont.) Familiarization (cont.) Familiarization (cont.) Familiarization (cont.) Familiarization (cont.) Flex Link with 512 Hz Beacon Assembly 200 Feet Push Rod 15 High Intensity LED’s Centering Guide Self Leveling Camera Head Centering Guide Locking Ring Page 10...

  • Page 11: Ipad Application

    iPad Application iPad Application iPad Application iPad Application iPad Application To begin using Spartan Application, turn iPad on by pressing Home button and then slide to unlock. Fig. 11-1 Fig. 11-2 Spartan App Page 11...

  • Page 12: Operating Instructions & Tips

    Pushing the push-cable back into the reel will cause the distance to decrease. 8. System is now ready for pipe inspection. NOTE - Please reference the SparVision 200 Tutorial for a complete description of the Spartan Tool iPad Application. Page 12...
  • Page 13 Operation Tips Operation Tips Operation Tips Operation Tips Operation Tips If you get stuck in a line, try to rotate the push-cable by hand first clockwise then counter-clockwise. The use of a lubricating agent on the push-cable itself can often increase the distance you are able to push the unit.

  • Page 14: Battery Operation And Charging

    Battery Operation & Charging BATTERY OPERATION The system is designed to operate using internal battery power or 110 /220 V AC (household current). A fully charged battery will last approximately 4 hours. To check battery life, choose the “Systems Options” button on the main screen. The battery gauge will display in the lower left hand corner.

  • Page 15: Trap-Eze (Optional)

    Trap-EZE (Optional) The SparVision 200 has the ability to connect to the Trap-Eze mini reel. To use this feature, you will need to purchase a Spartan Trap-Eze which includes a 15’ patch cable to connect the reel to the SparVision 200.

  • Page 16: Maintenance

    Maintenance Maintenance The SparVision 200 is designed for easy maintenance and trouble free operation. Regular maintenance will prolong the life of the product. Follow these simple procedures: Do not store outdoors and do not allow the unit to sit for extended periods in a hot environment such as a truck or automobile in bright sunlight.

  • Page 17: Troubleshooting

    Troubleshooting Troubleshooting Troubleshooting Troubleshooting Troubleshooting SY M P TO M P O SSIBLE C AU SE S C O RRE C TIV E ACTIO N N o Pow er PO W ER O N /O FF button Turn system on using pow er sw itch has not been sw itched Battery m ay be run dow n C harge battery...

  • Page 18: Assembly/Part Descriptions

    SparVision Final Assembly SparVision Final Assembly SparVision Final Assembly SparVision Final Assembly SparVision Final Assembly ITEM PART NUMBER DESCRIPTION 61046900 BODY, CAMERA CENTERING GUIDE 61047000 LOCKING RING, CAMERA CENTERING GUIDE 62016100 FUSE, TIME DELAY5MM 63030045 FUSE, SLO-BLO 64020010 AC POWER CORD, 118" - 10A, 125 V - RED 64020050 IPAD, 4TH GENERATION - 16 GIGS - BLACK 64020090...
  • Page 19 SparVision Final Assembly cont. SparVision Final Assembly cont. SparVision Final Assembly cont. SparVision Final Assembly cont. SparVision Final Assembly cont. Page 19...
  • Page 20 SQUARE BUMPER - 1-1/2" X 1-1/8" HGT 64023200 BLOCK, SLIP RING COVER - SPAR-V 64023300 CAP, SLIP RING COVER - SPAR-V 64023400 PLATE, SLIP RING COVER - SPAR-V 64024200 BATTERY, SPARVISION 200 64024300 POWER SUPPLY, 3-CELL LI-ION 64026100 RUBBER CLAMP, MINI QUICK FIST Page 20...
  • Page 21 Base Assembly cont. Base Assembly cont. Base Assembly cont. Base Assembly cont. Base Assembly cont. Page 21...
  • Page 22 Kickplate Assembly Kickplate Assembly Kickplate Assembly Kickplate Assembly Kickplate Assembly ITEM PART NUMBER DESCRIPTION 63036310 SCREW, 10-32 X FLT SCK BLK 64022080 WASHER, FLAT #10 ALUM 64022655 LOCKNUT, 10-32 NYLON INSERT - ALUM 64023010 PLATE, KICKPLATE - SPARVISION 64023020 TELESCOPING HANDLE - 3-STAGE - 38" Page 22...
  • Page 23 Drum Assembly Drum Assembly Drum Assembly Drum Assembly Drum Assembly ITEM PART NUMBER DESCRIPTION 03850100 NUT, HEX KEP 10-32 ZINC PLTD 63032155 SCREW, BT HD 10-32 X 3/4'' BLCK 64021035 SCREW, 1/4-20 X 3/4" - BT HD SS 64021050 SCREW, 5/16-18 X 5/8 - SCK CAP 64021060 SPACER, NYLON 1/2"...
  • Page 24 Lid Assembly Lid Assembly Lid Assembly Lid Assembly Lid Assembly ITEM QTY PART NUMBER DESCRIPTION 2.9' 63031010 RUBBER SEAL, 3/8 X 7/32 BLACK 64022680 LATCH, SLIDE TO OPEN - BLACK 64022770 SCREW, 6-32 X 1/2 - BLK SS 64022780 LOCKNUT, 6-32 NYLON INSERT 64022910 PLATE, IPAD COMPARTMENT COVER 64022915...
  • Page 25 Lid Assembly Cont. Lid Assembly Cont. Lid Assembly Cont. Lid Assembly Cont. Lid Assembly Cont. 15 14 Page 25...

  • Page 26: Product Information

    Product Information Product Information Product Information Product Information Product Information 64020500 - 2” Centering Guide 64020600 - 6” Centering Guide 63050000 Trap-Eze Camera System 61048900 Locator with Carrying Case Page 26...

  • Page 27: Note Space

    Notes Notes Notes Notes Notes Page 27...

  • Page 28: Warranty Information

    SPARTAN TOOL L.L.C. MENDOTA, ILLINOIS 61342 Spartan Tool L.L.C. reserves the right to make changes at any time, without notice, to specifica- tions and models and also discontinue models. The right is also reserved to change specifica- tions or parts at any time without incurring any obligation to equip same on models manufactured prior to the date of change.
