SERVICE MANUAL
STEREO CASSETTE PLAYER
This Service Manual contains information about the different between
HS-PX590/997<[L]AH,AE> and HS-PX997<AHK>.
If requiring other information, see Service Manual HS-PX590/997<[L]AH,AE>
(S/M Code No. 09-996-405-2R3).
S/M Code No. 09-997-405-2S1
HS-PX997
BASIC TAPE MECHANISM : 7ZM-1 P1
AHK
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Aiwa HS-PX99
Summary of Contents for Aiwa HS-PX99
- Page 1 HS-PX997 SERVICE MANUAL BASIC TAPE MECHANISM : 7ZM-1 P1 STEREO CASSETTE PLAYER This Service Manual contains information about the different between HS-PX590/997<[L]AH,AE> and HS-PX997<AHK>. If requiring other information, see Service Manual HS-PX590/997<[L]AH,AE> (S/M Code No. 09-996-405-2R3). S/M Code No. 09-997-405-2S1...
-
Page 2: Specifications
SPECIFICATIONS Maximum output: 4 mW + 4 mW (EIAJ/32W ) Load impedance: 16 – 32 ohms Power sources: DC 1.2 V using supplied rechargeable battery NB-5G, DC 1.5 V using an R6 (AA) dry cell battery, AC house current using the optional AC adaptor Maximum dimensions: 80 (W) x 112.9 (H) x 18.9 (D) mm (3 in.) - Page 3 ELECTRICAL MAIN PARTS LIST REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION C155 87-016-526-080 C-CAP,S 0.47-16 BK HEAD FLEX C.B C156 87-016-526-080 C-CAP,S 0.47-16 BK 87-A21-179-010 C-IC,TA2123AF C157...
- Page 4 WIRING...
- Page 5 SCHEMATIC DIAGRAM...
- Page 6 MECHANICAL EXPLODED VIEW 1/1 MECHANICAL PARTS LIST 1/1 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 8Z-HK4-027-010 LID,CASS SIL ASSY 997 8Z-HK4-016-010 KNOB,SL HOLD BLU 8Z-HK4-006-010 WINDOW,CASS 8Z-HK4-008-010...
- Page 7 ACCESSORIES / PACKAGE LIST REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 1 8Z-HK4-914-010 IB,HK (ECH) 2 87-B30-253-010 HEADPHONE,HP-M041 3 8Z-HK4-952-010 RC UNIT,RC997 4 87-B30-038-010 BAT,NB-5G 5 87-B30-097-010 CHARGER,RB-107 K 6 8Z-HK4-090-010 BOX,BAT ASSY SIL 7 82-HK3-951-010 CARRYING,CASE...
- Page 8 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 2-11, IKENOHATA 1-CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 931261 9630469 Printed in Singapore...
