- Page 1 DT150 Installation Manual English MAEN844C, 2009-01...
- Page 2 The information in this document is subject to change without notice and is provided as available at the time of printing. Beijer Electronics AB reserves the right to change any information without updating this publica- tion. Beijer Electronics AB assumes no responsibility for any errors that may appear in this document.
-
Page 3: Table Of Contents
Operation Messages ..............15 Video Input Timing..............15 Audio Support ................15 Calibrate the Touch Screen ............16 4 Chemical Resistance ................17 Metal Casing................17 Touch Screen and Overlay ............18 5 Drawings ....................21 DT150 Outline ................. 21 Beijer Electronics, MAEN844C... - Page 4 Contents Beijer Electronics, MAEN844C...
-
Page 5: Safety Precautions
– The supplier neither guarantees that the monitor is suitable for your particu- lar application, nor assumes responsibility for your product design, installa- tion or operation. Beijer Electronics, MAEN844C... -
Page 6: During Use
– Clean the display and surrounding front cover with a soft cloth and mild de- tergent. Dismantling and Scrapping – The monitor or parts thereof shall be recycled according to local regulations. – The following components contain substances that might be hazardous to health and the environment: electrolytic capacitor and display. Beijer Electronics, MAEN844C... -
Page 7: Installation
Installation Installation Space Requirements Installation plate thickness: 1.5 - 9.0 mm (0.06 - 0.35 inch) Space requirements when installing DT150: 50 mm (2.0 inch) 304 mm (11.97 inch) 45 mm (1.77 inch) 25 mm 25 mm (1.0 inch) (1.0 inch) 50 mm (2.0 inch) - Page 8 2. Place the panel cut out where the monitor is to be situated, draw along the outer sides of the holes and cut according to the markings. 3. Secure the monitor in position, using all the fastening holes and the pro- vided brackets and screws: x 14 0.5 - 1.0 Nm Beijer Electronics, MAEN844C...
- Page 9 Monitor 115/230 V AC Ground connected power cord Industrial PC AC/DC Adaptor 12 V DC 5. Carefully remove the laminated film over the monitor display, to avoid static electricity that could damage the monitor. Beijer Electronics, MAEN844C...
- Page 10 Installation Beijer Electronics, MAEN844C...
-
Page 11: Technical Data
-20 ° to +70 °C Relative humidity 5 - 85% non-condensed The monitor conforms with the essential protection requirements of the directive 2004/108/EC. Noise tested according to EN61000-6-3 emission and EN61000-6-2 immunity. * See section 4 Chemical Resistance Beijer Electronics, MAEN844C... -
Page 12: The On Screen Display Menu
Opens the OSD menu and works as Select and Deselect button. Down Arrow Return or Exit in the OSD menu. Automatic display configuration Decrease/left key Brightness decrease Increase/right key Brightness increase VGA/DVI Source select (VGA or DVI) Power Turns on/off the monitor. Beijer Electronics, MAEN844C... - Page 13 Color Temperature User: Red, green and blue colors can be adjusted Warm: Red-tinged screen Normal: Green-tinged screen Cool: Blue-tinged screen Auto Color Color automatically set from strange input signal (A-RGB only) Exit Go back to main menu Beijer Electronics, MAEN844C...
- Page 14 Reset Reset to initial setup (factory settings) Reset Color Initial color Reset Position Initial position Mute Set sound on or off (Audio Option) Volume Adjust the volume of sound (Audio Option) Exit Go back to main menu Beijer Electronics, MAEN844C...
-
Page 15: Operation Messages
OSD interface or the OSD buttons on the rear side. The monitor is equipped with one audio input port and one speaker out port. Parameter Specification 2 x 2W @ 8 Ω Maximum output Note: The industrial monitor does not include built-in speakers. Beijer Electronics, MAEN844C... -
Page 16: Calibrate The Touch Screen
The industrial monitor has a built in touch screen. This is not operational when shipped from the supplier and must be installed. Instructions and drivers for in- stallation of the touch screen function are available at: www.hmi.beijerelectronics.com Beijer Electronics, MAEN844C... -
Page 17: Chemical Resistance
The powder paint shows little or no resistance to the following chemicals at room temperature: Acetic acid, conc. Methyl-ethyl ketone Toluene Acetone Nitric acid 30% Trichlorethylene Ammonia 5% Phenol Xylene Ammonia, conc. Sodium hydroxide 5% 97 octan unleaded petrol Ethyl acetate Sodium hydroxide 30% 98 octan leaded petrol Beijer Electronics, MAEN844C... -
Page 18: Touch Screen And Overlay
Autotex is not resistant to high pressure steam at over 100 °C or the following chemicals: Concentrated mineral acids Benzyl alcohol Concentrated caustic solution Methylene chloride Outdoor Use In common with all polyester based films Autotex F157/F207 is not suitable for use in conditions of long term exposure to direct sunlight. Beijer Electronics, MAEN844C... - Page 19 5 hours 4.2.3 Autoflex EB It is recommended to use the Autoflex EB touch display protection film, that can be ordered from Beijer Electronics. Solvent Resistance Autoflex EB withstands exposure to the same chemicals as Autotex F157 or F207 according to section Autotex F157/F207.
- Page 20 Chemical Resistance Beijer Electronics, MAEN844C...
-
Page 21: Drawings
Drawings Drawings DT150 Outline Beijer Electronics, MAEN844C... - Page 22 HEAD OFFICE SUBSIDIARIES SWEDEN GERMANY Beijer Electronics Products AB Elektronik-Systeme Lauer GmbH & Co. KG Beijer Electronics Inc. Box 426 Kelterstraße 59 939 N. Plum Grove Road, Suite F SE-201 24 Malmö, Sweden 72669 Unterensingen, GERMANY Schaumburg, IL 601 73, USA...
