InfiNet R5000 Quick Installation Manual

InfiNet Wireless R5000
InfiNet Wireless R5000
The document is intended to be used by qualified RF engineers/technicians and IT professionals. Qualified personnel should
have skills and experience in the following areas: outdoor/indoor radio equipment installation, outdoor wireless networks,
TCP/IP networking protocols, safety procedures and instructions for installing antenna equipment, professional manage of
electrical equipment and accessories, safety procedures and instructions for working on towers and heights.
The warranty is not spread for the devices which stopped working properly due to improper usage, careless treatment,
incorrect deployment or exploitation. The warranty voids in the following cases: the device was opened and/or repaired by
the owner on his own, improper exploitation conditions (including improper grounding), electrical damaging of the print
circuit board due to electric disruption caused by improper grounding, mechanical defects of the case.

Components and accessories required for the installation

• Indoor Unit (IDU)
• Outdoor Unit (ODU)
• Service cable for IDU-to-ODU connection. Service
cable should be STP (or FTP) Category 5E cable. The
total cable length between LAN equipment (behind
IDU) and ODU should not be longer than 100 meters.
• One shielded and one standard RJ-45 connectors for
service cable
• Ethernet cable for connecting IDU to LAN equipment
(use a straight Ethernet cable for connecting to a
hub/switch or a cross-over cable for connecting
directly to a PC)
• IDU's AC power cord with a power plug
• Console cable for easy direct connection to ODU
(optional)

Tools required for the installation

• Screwdrivers set
• Pliers
• Spanners set
• RJ-45 Crimp Tool (for RJ-45 connectors)

Cables preparation

1. In case of installing ODU with external antenna: prepare RF cable of the required length. RF low loss cable of 1 meter
length is recommended. Install and seal the connectors on the RF cable.
2. Determine the Service cable length that you need to connect IDU to ODU. The total length of cables between LAN
equipment and ODU should not be longer than 100 meters.
For example, total length of the Ethernet cable connecting your switch to IDU and Service cable connecting IDU to
ODU should not be more than 100 meters. So if you are using 60 meters Service cable then Ethernet cable length
should not be more than 40 meters.
Service cable should be STP/FTP Category 5E cable.
Section 1. Installation preparations
Copyright © 2004-2009 by InfiNet Wireless Limited.
Quick Installation Guide
• ODU mounting kit assembling (Pole, Low-diameter
Pole or Wall mounting kit).
• IDU mounting kit assembling (optional)
In case of using ODU with external antenna:
• Antenna
• Antenna installation kit assembling
• RF low loss cable for connecting antenna to ODU
• Required grounding system.
• InfiNet Wireless "RapidView-1" visual diagnostic
device for easy antenna
(optional)
• Connectors sealing set.
• Optional: GPS receiver
Optional: Big zoom binocular
•
Quick Installation Guide
alignment procedure
