InfiNet Wireless R5000

Technical User Manual

Revision date: 15 February 2008

Table of Contents

Need help?

Do you have a question about the R5000 and is the answer not in the manual?

Questions and answers

Summary of Contents for InfiNet R5000

Page 3: Table Of Contents
2. R5000 series ........................14 InfiNet Wireless R5000-I ....................14 InfiNet Wireless R5000-IL ..................... 15 InfiNet Wireless R5000-O ....................3 InfiNet Wireless R5000-M/ R5000-S ................. 4 InfiNet Wireless R5000-L ....................6 III. INSTALLATION PROCEDURE ................... 7 1. Installation preparations ....................7 Required components and accessories ................
Page 4 Service cable soldering procedure .................. 12 «Screw Lock» connectors hermetic sealing ..............17 Tools to be available at the installation site ..............20 2. InfiNet Wireless R5000-I/InfiNet Wireless R5000-IL ............21 Installation guidelines ....................21 Slides installation ......................22 Rack mounting ......................22 Legs mounting ......................
Page 5 RSH ..........................55 SNMP ......................... 55 Console ........................55 VII. GUI “INFINET WIRELESS ROUTER MANAGER” ............56 1. Overall functionality overview ................... 56 2. Application requirements ....................56 3. User guide ........................56 Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 6 Graphs........................63 Telnet Session ......................64 VIII. RECOMMENDATIONS ....................65 1. Using InfiNet Devices for High Speeds (48, 54 Mbps) ............65 2. Design of Multi-sectored Base Stations ................65 3. Asymmetrical System Design .................... 65 IX. SUPPLEMENTARY INFORMATION ................. 66 1.
Page 7: Getting Started
InfiNet Wireless R5000 Technical User Manual I. Getting Started This Technical User Manual is a description of InfiNet Wireless Routers and contains installation and configuration guidelines, recommendations and troubleshooting sections, and supplementary materials. The document is intended to be used by Qualified RF engineers/technicians and IT professionals.
Page 8: Supplementary Information
Powerful integrated diagnostic tools InfiNet Wireless routers are generally used to create geographically spread FBWA transport networks. In its most basic form, a wireless network built with InfiNet Wireless routers consists of a base station and multiple subscriber units deployed one at each end of the wireless links.
Page 9: Abbreviations
InfiNet Wireless R5000 Technical User Manual The data network built on InfiNet Wireless products is implemented as a routed IP network which reduces flooding and broadcast messages specific to bridged networks and to implementation of Quality-of-Service (QoS) features set. QoS definitions per subscriber’s data flows are effectively mapped on MAC level flow...
Page 10: Additional Information
Additional information which is not included in this Manual can be found in the following sources: • Package list located in the box with the device • WANFlex OS User Guide • Our web-site: www.infinetwireless.com Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 11: Ii.hardware Description
All outdoor equipment is equipped with indoor power supply units. Exact type of IDU which is used with each router model is specified in different models description (see below). IDU-5000-SCR Front panel Rear panel Connection scheme for IDU-5000-SCR Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 13 Wires are distributed in the following manner (color-by-color): 1 – White-orange 2 – Orange 3 – White-green 4 – Blue 5 – White-blue 6 – Green 7 – White-brown 8 - Brown Connection scheme for IDU-5000-RJ Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 15: Idu With E1/T1 Ports
Technical User Manual Connection scheme for IDU-5000-CPE IDU with E1/T1 ports IDU with E1/T1 ports can be supplied with 2-4 E1/T1 ports. Below there is an IDU with 2 ports. Front panel Rear panel Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 16 ALARM B Indicator Indicator Indicator Status (green) (yellow) (red) E1/T1 port not configured Normal mode: E1/T1 data are transferred without failures between external E1/T1 source and corresponding E1/T1 port of the IDU Framing error Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 17 Loss of signal on the corresponding E1/T1 port of the IDU Error on an IDU which is on the other end of Alternating the radio link Alternating E1/T1 port in “Loopback” Connection scheme for IDU with E1/T1 ports Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 20: Infinet Wireless R5000-O
InfiNet Wireless R5000 Technical User Manual InfiNet Wireless R5000-O Default factory option: IDU-5000-SCR. Can be both in the housing below and in the housing identical to R5000-L Front panel Top view Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 21: Infinet Wireless R5000-M/ R5000-S
InfiNet Wireless R5000 Technical User Manual InfiNet Wireless R5000-M/ R5000-S Default factory option: IDU-5000-RJ (for R5000-S), IDU-5000-SCR (for R5000- M). R5000-S may be equipped with IDU-5000-CPE (market/partner dependent). Front panel Top view Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 22 InfiNet Wireless R5000 Technical User Manual ODU with RJ-45 connector*: Modification 2 (with metal RJ-45 connector). Front panel Top view *For InfiNet Wireless R5000-S and R5000-L only. Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 23: Infinet Wireless R5000-L
Default factory option: IDU-5000-RJ. R5000-L may be equipped with IDU-5000- CPE (market/partner dependent). IW R5000-L ODU is delivered with two types of service cable connectors: "Screw Lock" and "RJ-45". The following shows IW R5000-L ODU with "Screw Lock" service cable connector. IW R5000-L ODU with "RJ-45" service cable connector is similar to IW R5000-S with “RJ-45”...
Page 24: Iii.installation Procedure
In this respect, it is not recommended to use omni-directional antennas when sector antennas can be used. While planning, it is strongly recommended to consult high-qualified and experienced technicians Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 25: Antenna Poles Usage
STP service cable (ODU-IDU) is partially terminated on the grounded IDU case. Partial termination means that the direct lightning strike will probably destroy an STP cable. The service cable pickups from the electromagnetic Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 26: Grounding When Using Idu-5000-Cpe
STP cable. The service cable pickups from the electromagnetic impulses are terminated on the IDU case by the winding shield, and further – on the IDU grounding. IDU is grounded via a three-conductor power cord and a Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 27: Antenna Alignment
• Use GPS receiver and area map • Use build-in InfiNet Wireless Router features. These features allow evaluating current channel/signal quality and perform precise antenna alignment Omni-directional and sector antennas have a wide radiation diagram width, thus usually they either do not require a very precise alignment or it is just not necessary due to radio link requirements.
Page 28: Precaution Measures
This can lead to equipment damaging or may hurt the personnel. While installing or changing the elements of the antenna-fider system one should make sure that open metal parts are temporarily grounded. Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 29: Service Cable Soldering Procedure
Antenna cable must be grounded at all times (not relevant for 5000-M modifications) Service cable soldering procedure The following instruction shows the connector soldering procedure Step 1. Peel STP cable as shown Step 2. Use outdoor unit to fix the connector further faster disassembling Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 30 Step 3. To disassemble the connector detach its bottom part by turning it clockwise as shown Step 4. Disassembled connector is shown on the picture Step 5. Insert the cable into the bottom part of the connector Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 31 Step 6. Solder the top side of the connector according to the soldering scheme. Unscrew the top side of the connector from the unit Step 7. Using outdoor unit as a holder assemble the connector Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 32 RJ-45 connector without grounding to the STP service cable according to the “RJ-45” soldering scheme and crimp the connector. Step 4. Put Part 4 on the attached in the previous step RJ-45 connector. Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 33 Check that the connector is properly fixed on the cable. Step 6. Assemble the connector to the unit. Step 7. Fix the connector by screwing Part 3. Now the connector is hermetically attached to the unit. Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 34: Screw Lock» Connectors Hermetic Sealing
With gel usage no additional sealing is required. Even if connection was disassembled afterwards no additional gel is required. Please see the photos below to learn who gel is put onto the connector. Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 35 Also it is highly recommended to use using special mastic in order to provide proper sealing inside the connectors for the service cable. Step-by-step procedure is shown on the photos below. Mastic is NOT GEL AND IS NOT INCLUDED INTO STANDARD PACKING LIST! Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 37: Tools To Be Available At The Installation Site
InfiNet Wireless R5000 Technical User Manual Tools to be available at the installation site 1. Screwdrivers set 2. Pliers 3. Soldering iron 40 W Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 38: Infinet Wireless R5000-I/Infinet Wireless R5000-Il
6. Additional equipment • GPS receiver or area map (with compass and alidade) • Big zoom binoculars 2. InfiNet Wireless R5000-I/InfiNet Wireless R5000-IL Installation guidelines 1. Unpack the equipment 2. Check items integrity 3. Prepare RF cable of the required length 4.
Page 39: Slides Installation
Rack mounting Rack mounting bracket is an optional accessory and must be ordered separately. Two InfiNet Wireless Routers 5000-I can be mounted into a standard 19” rack using special rack mounting bracket. Legs mounting Legs are included in the package.
Page 40: Infinet Wireless R5000-O
8. Lay the STP cable “from top to bottom” – from ODU to IDU 9. If step 7 is not accomplished, after the STP cable has been laid, install (solder) connector for IDU 10. Install ODU on the mounting bracket connectors down and tighten it Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 41 18. Provide grounding for IDU 19. Connect Ethernet cable to IDU 20. Provide power supply for IDU 21. Connect to the Router using Telnet protocol It is extremely important to install ODU connectors down! Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 42: Tube Mounting For Odu
InfiNet Wireless R5000 Technical User Manual Tube mounting for ODU 4. InfiNet Wireless R5000-L Installation guidelines 1. Unpack the equipment 2. Check items integrity 3. Prepare RF-cables required length. 5GHz devices recommended Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 43 17. Provide grounding for IDU 18. Connect Ethernet cable to IDU 19. Provide power supply for IDU 20. Connect to the Router using Telnet protocol It is extremely important to install ODU connectors down! Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 44: Wall Mounting
Do not tight it too hard unless the antenna alignment is not complete. Install ODU connectors down. 8. Connect the ODU-IDU cable to the ODU Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 45: Wall Mounting Kit Assembling
It is extremely important to install ODU connectors down! Wall mounting kit assembling Attention! By default, the mounting kit for R5000-S/M does NOT contain a plate for wall mounting – it should be ordered separately. Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 46: Pole Mounting Kit Assembling
InfiNet Wireless R5000 Technical User Manual Pole mounting kit assembling Kit №1 Kit №2 Since May devices will be equipped with Kit № 2 instead of Kit № 1. Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 48: Mounting Kits Assembling
InfiNet Wireless R5000 Technical User Manual 6. Mounting kits assembling Pole mounting kit MONT-5000-V.Pole-KIT for vertical mast Attention! Pole mounting kit MONT-5000-V.Pole-KIT does NOT contain metal straps. Mounting kit for IW R5000-S is included. Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 49: Pole Mounting Kit Mont-5000-H.pole-Kit For Horizontal Pole
InfiNet Wireless R5000 Technical User Manual Pole mounting kit MONT-5000-H.Pole-KIT for horizontal pole Attention! Pole mounting kit MONT-5000-V.Pole-KIT does NOT contain metal straps. Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 51: Device Configuration Instructions
Telnet protocol. In order to configure the device using Console port, follow the instructions below: • Device should be connected with host serial interface, using InfiNet Console cable • Start any terminal emulation software (e.g. Hyper Terminal) •...
Page 52: Command Line Interface (Cli)
The procedure is the following: 1. Locate your device’s serial number 2. Send this SN to the InfiNet Wireless Technical Support 3. You will be given a special key 4. Enter the device and use SN as a login and received key as a password 5.
Page 53: Import/Export
The download process has two phases: • File uploading into RAM of InfiNet device. • Programming InfiNet device flash memory from RAM firmware image. This phase is indicated by “O.O.O.O.O.O…” sequence. Do not interrupt this process, otherwise device will be brought into invalid state and it recovery will be possible only at manufacturer premises.
Page 54: Ip Address Formats
To learn your device’s radio module capabilities type the command: rfconfig <IF-NAME> capabilitites <IF-NAME> - radio interface name. Can be read on the device’s labeling located on the case. Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 55 Base Station. In this case devices will automatically adjust their settings selecting an optimal value for the distance parameter. Base Station will calculate a distance to the remotest Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 56: Routed Multiple Access Protocol Configuration
63 distance 0 9. Routed Multiple Access protocol configuration Every InfiNet Wireless Router can be configured as a subscriber unit or as a base station. Each link between a base station and a subscriber unit is described as a PTP connection (or a subnetwork consisting of two units).
Page 57 0 indicates the weakest signal quality, 16 – the strongest. <signal level from CPE>/<signal level from BS> Status field. A – active B – burst mode on P – polling mode on <transmitting speed>/<receiving speed> Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 58: Cpe Configuration
– current signal quality level • 7/6 – “signal level from the subscriber”/”signal level from the BS”. Measured according to the relative InfiNet scale from 0 to 16 (0 – min, 16 – max) • IP – IP-address for the radio interface from the BS side •...
Page 59: Bitrate Control
Burst – Burst mode is turned on Bitrate control Traditional ways of InfiNet router's usage imply a fixed connection speed between a base station and a subscriber. A subscriber while searching and registering on a base station chooses an optimal mode which is available in the configuration and afterwards does not change connection parameters even if radio channel characteristics (signal levels, noise level) are changing.
Page 60: Polling
A Base Station performs a permanent link testing with a subscriber. Each testing is accompanied by subscriber’s information update in the Base Station’s tables. This mechanism provides a system operator with comprehensive data concerning registered subscribers and links quality without any additional tests launching. Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 61: Rma Usage
• Enable polling mode on the BS • Define which links are not stable at the configured speeds and try using autobitrate mode either for some specific CPEs or for the whole cell Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 62: Link Configuring
Base Station: 5000-O 5.8 36P3000. Sector antenna gain 17 dB • Nearest subscribers (e.g. 2.5 km coverage area): 5000-O 5.8 19 dB directional antenna • Remote subscribes (e.g. 5 km coverage area): 5000-O 18 with 29 dB directional antenna Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 63: Frequency Planning For Multi-Sectored Base Stations
7. Press “Recalculate” button 8. Perform the following actions: • For UPSTREAM speed prognosis use “Signal level by InfiNet scale” parameter for Unit №1. Subtract “Sinking Offset” parameter provided below. Search the calculated value in “Minimal InfiNet scale level required for maximal throughput” in the tables below. If the value matches with the predicted speed, the link works with selected parameters.
Page 64: Speed Range Calculator
Normal operation of the radio is not possible in this mode. This regime can be useful on the first steps of link configuration. One can observe the activity on the selected list of frequencies and make decisions of Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 65 The mac2 regime checks both data packets rfconfig and the link-level ACK messages sent by protocol supported devices. Normal operation of the radio is not possible in this mode. The picture below shows the output mac2 regime. Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 66 MAC-address separately, you can reveal the problem for some specific unit on the wireless network The “muffer stat” command shows the statistics only from registered devices. To view statistics type the following command: muffer stat To reset all counters please type Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 67: Rma Test
LostIn and LostOut parameters even when the packet length is long (e.g. 1400 bytes). For multicast mode the threshold value below which the link can be defined as satisfactory is approximately 20% of lost packets. Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 69: Acquiring Interfaces Statistics
If the interface has several aliases the statistics is still measured for physical interface in a whole. For example, see rf4.0 or eth0 interfaces above. The numbers shown in 4 right columns correspond in physical interface. Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 70: Services, Features And Tools
Whether the packet is a TCP/IP connection request (a packet attempting to initiate a TCP/IP session) or not; • Whether the packet is a head, tail or intermediate IP fragment; • Whether the packet has certain IP options defined or not; Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 71: Qos
IP packets at one end of a link and is delivered to its opposite end through the existing transport network. Routing core InfiNet Wireless Router supports the standard TCP/IP (IPv4) protocols stack. 2. Utilities and services Telnet Telnet system protocol support.
Page 72: Routing Protocols
The router has a feature of its configuration management via console. By specifying the correct parameters of the RS-232 interface and connecting the device via console cable one can get an access to the WanFlex OS command prompt in order to configure the device. Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 73: Vii.gui "Infinet Wireless Router Manager
InfiNet Wireless R5000 Technical User Manual VII.GUI “InfiNet Wireless Router Manager” 1. Overall functionality overview “InfiNet Wireless Router Manager” (“IWR Manager” for short”) is used for the following purposes: • View and change system parameters of the router • View and change interfaces parameters of the router •...
Page 74: System Settings
Enables/disables the ability of the system to deal with icmp redirect messages to adjust route tables in the wrong routing • Enables/disables the ability of the system to send icmp redirect messages to suppress source of the packages when routing is configured incorrectly. Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 75: Interfaces
Distance. this parameter is used as an alternative method of link range configuring in order to set the exact distance value between two devices (in kilometers There are several ways to manage this parameter: Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 76 The application has the following functionality to manage the interfaces: • Add/delete/change primary and secondary (alias) IP-address on each interface • Change the state of the interfaces (up/down). • Change MTU (Maximum Transfer Unit) parameter for each of the interfaces Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 77: Base Station
Signal levels from BS to CPE and from CPE to BS. Signal levels are measured from 1 to 16 • Upstream and downstream speeds • Distance to the Base Station • Mnemonic name of the CPE Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 78: Cpe - Customer Premises Equipment)
IP-address for the radiointerface from the side of the BS. For CPE, the address for the radiointerface will be assigned automatically. • Signal levels from BS and to BS • Current upstream and downstream speeds Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 79: Interfaces Statistics
INPUT/OUTPUT: pckts – total number of incoming/outgoing pps through the interface • TOTAL: sum – total number of kbps that went through the interface • TOTAL: pckts – total number of pps went through the interface Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 80: Routing/Arp Tables
CPU Load. Builds a graph, showing CPU load changing in time • CPE signal levels. Shows how levels from different CPEs change in time • Interfaces Graphs. Displays current load on all interfaces. Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 81: Telnet Session
Nothing is different from the standard Telnet Windows utility. User name and password for accessing the device are filled automatically at module startup. Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 82: Viii.recommendations
Technical User Manual VIII.Recommendations 1. Using InfiNet Devices for High Speeds (48, 54 Mbps) Using InfiNet devices on greater speeds 48 and 54 Mbps can specific limitations and requirements because of low noise immunity of high-order modulation techniques (64 QAM).
Page 83: Supplementary Information
InfiNet Wireless R5000 Technical User Manual IX. Supplementary information 1. Connectors soldering schemes «Screw Lock» service cable connector soldering scheme Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 84: Rj-45" Service Cable Connector Soldering Scheme
InfiNet Wireless R5000 Technical User Manual “RJ-45” service cable connector soldering scheme Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 85: Console Cable Connector For 5000-M And 5000-O Soldering Scheme
InfiNet Wireless R5000 Technical User Manual Console cable connector for 5000-M and 5000-O soldering scheme Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 86: Console Cable Connector For 5000-I Soldering Scheme
InfiNet Wireless R5000 Technical User Manual Console cable connector for 5000-I soldering scheme Copyright © 2004-2006 by InfiNet Wireless Limited.
Page 87: Cable Cutting Scheme For Idc110(B) Distribution Box
InfiNet Wireless R5000 Technical User Manual Cable cutting scheme for IDC110(B) distribution box Copyright © 2004-2006 by InfiNet Wireless Limited.
