Page 1: Instruction Manual
Automatic BANDSAW H-400GA INSTRUCTION MANUAL MEGA MACHINE CO., LTD. DOC NO ： H-400GA-100.U CTRL NO ： 06 UPDATE ： 2008/02/13 DOC VER ： A1... - Page 2 The machine has been built to the highest standards to enable fast accurate cutting to be obtained. In order that the best results can be achieved from your MEGA circular sawing Machine, we would ask all operators and maintenance engineers to READ THIS MANUAL CAREFULLY BEFORE STARTING THE MACHINE.
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1. Introductory Illustrations 1.1 Principal parts ------------------------------------------------------------------------ 1 2. Specifications 2.1 Specifications ------------------------------------------------------------------------- 2 2.2 Standard Accessories----------------------------------------------------------------. 2 3. Installation 3.1 moving and lifting -------------------------------------------------------------------- 3 3.2 Foundation layout and Set-up ------------------------------------------------------- 4 3.2.1 Foundation ----------------------------------------------------------------------- 4 3.2.2 Leveling ---------------------------------------------------------------------------5 3.2.3 Cleaning and oiling---------------------------------------------------------------.6 3.2.4 Power Source Connection ------------------------------------------------------ 6... -
Page 4: Introductory Illustrations
1. INTRODUCTORY ILLUSTRATIONS (全行程) 1. 1Principal Parts... -
Page 5: Specifications
2 SPECIFICATIONS 2.1 SPECIFICATIONS SPECIFICATIONS MODEL H400GA Ø 400W*400H (MM) Ø Cutting Capacity 16W*16H (IN) (MM) 320W*230H Bundle Cutting (IN) 13W*9H (MM) 32*1.06*4570 Blade Size (IN) 1 1/4*0.042*180 (M/min) 25, 32, 42, 55, 70, 80 Variable Speed 20-80 Blade Speed (F/min) 82, 105, 138, 180, 230, 260 Variable Speed 65-260... -
Page 6: Installation
3. INSTALLATION : 3.1 Moving and Lifting : Unpack your machine carefully , and use a crane or forklift to set it in position. If a crane is used to lift the machine attach the lifting cable carefully to the machine as shown in the fig 2. -
Page 7: Foundation Layout And Set-Up
3.2 Foundation layout and set-up : 3.2.1 Foundation : The foundation should be constructed of reinforced concrete and must be level and flat. After the proper leveling position has been obtained , anchor the machine with anchor bolts. The position of anchor bolts and floor dimensions are shown in fig 4: Fig. -
Page 8: Leveling
3.2.2 Leveling : The production accuracy of all precision machinery depends on the accuracy which the machine is installed . Manufacturing tolerance of the machine can only be guaranteed if the machine is firmly and properly installed . Once the machine is lowered on the prepared foundation . Machinist levels should be used alternately on the vice slide plates and the work feed table , and adjust the left-and-right and fore-and-aft level of the machine with leveling bolt . -
Page 9: Cleaning And Oiling
3.2.3 Cleaning and oiling : After the machine has been placed in position , thoroughly remove its rust preventive coating using a suitable cleaning solvent and then apply a coat of machine oil . To clean the machine , Kerosene is preferable to gasoline . -
Page 10: Operation
4. OPERATION 4.1. Control Panel 1. LCD Panel illustration 2. PILOT LAMP -- This light will comes on when the power supply is on. 3. EMERGENCY STOP -- This switch is used for emergency case to stop the machine only. Turn this switch clockwise makes power source on. - Page 11 12. BLADE DRIVE BUTTON -- When this button is pressed, both the saw blade motor and the cutting fluid pump operate and saw head begins to descend. The saw head descends quickly until the feeler of the quick approach device comes into contact with the workpiece and thereafter, it will descend at the designated cutting speed.
-
Page 12: Lcd Panel Illustration
4.2 LCD Panel illustration 4.2.1 LCD Panel operation sequence After powered on, the LCD panel will display as fig. right. By touching screen, the LCD panel will escape to the next figure. Manual mode: To individually operate each function, turn the “ AUTO - MANUAL to right “manual”. - Page 13 PARAMETER SETTING: ( The panel function key F5) It can adjust the feed system delay time and the frame system delay time and the vise jaw open time and the others by password, which PARAMETER SETTING FEED SYSTEM DELAY TIME set by manufacturer or agent.
-
Page 14: Addition 1 - Amplifying Valve
Amplifying Valve (1.) The outlines and hydraulic circuits: (2.) SET-UP A. The hydraulic pressure indicated in line <p> should be kept in constant during the whole stroke of the lifting cylinder, i.e. Between the very top and bottom position of the swinging saw frame. we use springs <r>... - Page 15 B. Re-zeroing knob "a" & "b" on the amplifying valve: For zeroing knob "a", there is a hydraulic pressure gauge as drawing <S> needed, Please plug it onto the outlet on the amplifying valve. Pressure read at line <p> as the primary pressure....pressure <p> Pressure read at amplifying valve as the secondary pressure..
-
Page 16: Operating Preparation
4.3 OPERATING PREPARATION There are several steps will be taken before start the machine. (1) CHOOSE PROPER SAW BLADE : Select the saw blade best suited to the workpiece to be cut, Size and shape of the workpiece , and type of material should all be considered when selecting the saw blade to be used . - Page 17 (7) ADJUST THE FEED RATE : Select suitable feed rate for the workpiece to be cut. This varies according to the size and shape of the workpiece, type of material , and what type of saw blade is being used. As a guide hard materials, wide workpiece or structural sections and tubing have to be cut at a slower rate that mild steel bar.
-
Page 18: Manual Operation
4.4 MANUAL OPERATION : Place the workpiece to be cut on the work table , decide how long you want the off-cut , and carry out all the procedures as described above in [4.3] Operating Preparation (1) Press the SAW FRAME RAISE to lift the saw frame until BUTTON the cutting edge of the saw blade... -
Page 19: Automatic Operation
4.5 AUTO OPERATION : Having finished all the procedures described above in [4.3] Operating Then Place the Preparation. AUTO-MANUAL workpiece to be cut on the work table SELECTOR and clamp it. (A) Turn the “ AUTO-MANUAL to “auto”. SELECTOR” (B)Press the “ QUICK APPROACH to make the saw BUTTON... -
Page 20: Special Operation
4.6 SPECIAL OPERATION : (1) While you are cutting a workpiece, if the saw blade suddenly jams in the workpiece, depress the FRAME RAISE button to lift the saw frame immediately. (2) The saw blade jamming in the workpiece is most likely because of : a. -
Page 21: Maintenance
5. MAINTENANCE (全行程) 5.1Oiling and Lubricant The operator should be responsible for the proper lubrication of the machine. The grade and quality of lubricant are given in the lubrication chart below : Oil Lubrication chart Lubricating Point Lubricant Quantity Oiling Frequency Transmission DAPHNE GEAR LUBE 320 3 liter... -
Page 22: Others
5.2 Others VARIABLES WHICH AFFECT BANDSAW BLADE LIFE 1 . The Operator - The operator is the most important variable at any test. He can make or break any test and often has a great deal of influence over whose bandsaw blades are used. He can also be a good source of information on what is going on, competitive situations, relationships with manufacturers or distributors, etc. - Page 23 12. Machine Condition-Whether a machine is old or new, and whether well maintained or not contributes to how well it runs and how long the band last. The better shape a machine is in, the better the bands will run. Poor machines ruin bandsaw blades. 13.
-
Page 24: Trouble Shooting Guide
6. TROUBLE SHOOTING GUIDE The following charts contains some typical troubles along with the probable causes and remedies for each. 6.1 Sawing Problems and Solution Vibration during cutting Failure to cut Short life of saw blade Curved cutting Broken blade Use blade with correct pitch, Use of blade with incorrect pitch suited to workpiece... -
Page 25: Minor Operating Troubles And Remedies
6.2 Minor Operating Troubles and Remedies Symptom Probable Cause Remedy 1. Buttons do not (1) Power disconnected (1) Connect function (2) Circuit protector OFF (2) Turn on (3) Thermal relay activated (3)Push reset button (4) Safety interlocks that is a. Load workpiece a. -
Page 26: Error Code
6.3 Error Code ALARM CODE ALARM MESSAGE SOLUTION 1. Fix the breakdown RAME RAISE TIME OVER 2.Press the saw frame raise button 1. Fix the breakdown FRAME RAISE POSITION L/S 2.Press the saw frame raise button OUT-OF-ORDER 1. Fix the breakdown FEED FORWARD SOLENOID 2.Press the saw frame raise button OUT-OF-ORDER... - Page 27 ALARM CODE ALARM MESSAGE SOLUTION 1. Fix the breakdown BLADE DOWN BUTTON 2.Press the saw frame raise button OUT-OF-ORDER 1. Fix the breakdown FEED FORWARD BUTTON 2.Press the saw frame raise button OUT-OF-ORDER 1. Fix the breakdown FEED BACKWARD BUTTON 2.Press the saw frame raise button OUT-OF-ORDER 1.
-
Page 28: Reference Charts
7. REFERENCE CHARTS 7.1 Standard Cutting Chart Material Blade Pitch Blade Speed Cutting Rate Service Life Sq c ㎡/min Sq c ㎡/PCE JIS code m/min S20C-S50C 50-70 42000-58000 S9CK-S15C 42-60 38500-54000 S53C-S58C 42-60 35000-58000 SS-50 42-60 38500-58000 SS-41 40-55 35000-54000 SM-50 40-55 35000-54000... -
Page 29: Standard Cutting Chart
7.2 Standard Cutting Chart Material AISI Brinell Blade speed Cutting rate code No. hardness Bhn Sq in/min 1108-1111 150-175 220-260 9.0-12.0 1112-1118 125-150 240-270 10.0-14.0 1115-1132 140-165 220-260 9.0-12.0 1137-1151 155-180 180-200 5.0- 8.5 1212-1213 150-175 240-270 10.0-14.0 1008-1013 150-175 220-260 7.0- 9.0 1015-1035... -
Page 30: Standard Cutting Chart
7.3 Standard Cutting Chart Material AISI Brinell blade peed Cutting ate code No. hardness Bhn sq in/min. Stainless Steels 302,304 130-170 80-90 303,303F 150-200 90-100 308,309,310 160-220 60-80 314,317,330 160-220 50-80 316,420 160-220 70-80 321,347 165-200 90-100 410,420F 140-185 100-110 416,430F 155-195 140-150... -
Page 31: Appendix
Appendix Appendix 1 : HYDRAULIC CIRCUIT(1/1) Appendix 2 : ELECTRICAL CIRCUIT... - Page 32 Appendix 1 Hydraulic Circuit (全行程)
