BANDSAW AUTOMATIC H-550A INSTRUCTION MANUAL MEGA MACHINE CO., LTD. DOC NO : H550A-100.U CTRL NO : UPDATE : 1998/07/27 DOC VER :...
Page 2
The machine has been built to the highest standards to enable fast accurate cutting to be obtained. In order that the best results can be achieved from your MEGA band saw we would ask all operators and maintenance engineers to READ THIS MANUAL CAREFULLY BEFORE STARTING UP THE MACHINE.
TABLE OF CONTENTS Item Unit Page Introductory Illustrations Principal parts Specifications Specifications Standard Accessories Installation Moving and lifting Foundation layout and Set-up 3.2.1 Foundation 3.2.2 Leveling 3.2.3 Cleaning and oiling 3.2.4 Power Source Connection Operation Control Panel Operating preparation Manual Operation Automatic operation Special Operation Break -In Operation...
3. INSTALLATION: 3.1 Moving and lifting: Unpack your machine carefully, and use a crane or forklift to set it in position. If a crane is used to lift the machine attach the lifting cable carefully to the machine as shown in the fig 2.
3.2 Foundation layout and set-up: (1) Foundation: The foundation should be constructed of reinforced concrete and must be level and flat. After the proper leveling position has been obtained, anchor the machine with anchor bolts. The position of anchor bolts and floor dimensions are shown in fig 4: □...
(2) Leveling: The production accuracy of all precision machinery depends on the accuracy which the machine is installed. Manufacturing tolerance of the machine can only be guaranteed if the machine is firmly and properly installed . Once the machine is lowered on the prepared foundation. Machinist levels should be Used alternately on the vise slide plates and the work feed table , and adjust the left-and-right and fore-and-aft level of the machine with leveling bolt .
4. OPERATION 4.1 Control Panel (1) PNC Control Panel Cutting Piece Counter – This counter is used to preset the number of cuts required on the automatic operation. When the counter reaches the preset number, the machine stops automatically . To activate the counter, preset the counter switch with number at least “1”.
Page 10
(2) PILOT LAMP -- This light will comes on when the power supply is on. (3) EMERGENCY STOP -- This switch is used for emergency case to stop the machine only. Turn this switch clockwise makes power source on. When this switch is pressed, all machine's operation stop immediately.
Page 11
4. OPERATION 4.1 Control Panel (1) PNC Control Panel Cutting Piece Counter – This counter is used to preset the number of cuts required on the automatic operation. When the counter reaches the preset number, the machine stops automatically . To activate the counter, preset the counter switch with number at least “1”.
Page 12
(2) PILOT LAMP -- This light will comes on when the power supply is on. (3) EMERGENCY STOP -- This switch is used for emergency case to stop the machine only. Turn this switch clockwise makes power source on. When this switch is pressed, all machine's operation stop immediately.
4.2 OPERATING PREPARATION There are several steps will be taken before start the machine. (1) CHOOSE PROPER SAW BLADE : Select the saw blade best suited to the workpiece to be cut, Size and shape of the workpiece , and type of material should all be considered when selecting the saw blade to be used .
(6) ADJUST THE POSITION OF THE WIRE BRUSH : a. loosen the lock lever of the wire brush case. b. Manually move the wire brush case so that wire brush just contacts the cutting edge of the saw blade. c. Tighten the lock lever. (7) ADJUST THE FEED RATE : Select suitable feed rate for the workpiece to be cut.
4.4 AUTOMATIC OPERATION : Having finished all the procedures described above in (2) Operating Preparation ,and with the workpiece to be cut placed in the vise of the machine , but NOT under the saw blade. (1) Turn the AUTO-MANUAL selector to manual. In control panel – The front vise clamp the workpiece when turn switch NO.(8) right and press button NO.(6) 1.5sec in the same time.
Page 16
ADDITION 1: Amplifying Valve ( Optional ) (1.) The outlines and hydraulic circuits: (2.) SET-UP A. The hydraulic pressure indicated in line <p> should be kept in constant during the whole stroke of the lifting cylinder, i.e. Between the very top and bottom position of the swinging saw frame. we use springs <r>...
Page 17
B. Re-zeroing knob "a" & "b" on the amplifying valve: For zeroing knob "a", there is a hydraulic pressure gauge as drawing <S> needed, Please plug it onto the outlet on the amplifying valve. Pressure read at line <p> as the primary pressure....pressure <p> Pressure read at amplifying valve as the secondary pressure..
5. MAINTENANCE The maintenance of this machine is divided three portions as following. 5.1 HYDRAULIC CIRCUIT 5 - 1...
Page 19
5.2 Oiling and Lubricant The operator should be responsible for the proper lubrication of the machine. The grade and quality of lubricant are given in the lubrication chart below : Oil Lubrication chart Lubricating Point Lubricant Quantity Oiling Frequency Blade Tension Device DAPHNE FLUID 32T Twice a year Drive Wheel Bearing...
5.3 OTHERS VARIABLES WHICH AFFECT BANDSAW BLADE LIFE 1. The Operator - The operator is the most important variable at any test. He can make or break any test and often has a great deal of influence over whose bandsaw blades are used. He can also be a good source of information on what is going on, competitive situations, relationships with manufacturers or distributors, etc.
Page 21
12. Machine Condition-Whether a machine is old or new, and whether well maintained or not contributes to how well it runs and how long the band last. The better shape a machine is in, the better the bands will run. Poor machines ruin bandsaw blades. 13.
6. TROUBLE SHOOTING GUIDE The following charts contains some typical troubles along with the probable causes and remedies for each. 6.1 Sawing Problems and Solution Vibration during cutting Failure to cut Short life of saw blade Curved cutting Broken blade Use blade with correct pitch, ○...
6.2 Minor Operating Troubles and Remedies Symptom Probable Cause Remedy 1. Buttons do not (1) Power disconnected (1) Connect function (2) Circuit protector OFF (2) Turn on (3) Thermal relay activated (3)Push reset button (4) Safety interlocks that is a. Load workpiece a.
