OPERATION AND INSTALLATION
TANKLESS ELECTRIC WATER HEATER WITH ELECTROMECHANICAL FLOW SWITCH
» AQM 2-1
» AQM 2.5-1
» AQM 3-1
» AQM 3.5-1
» AQM 4-2
» AQM 6-2
Conforms to ANSI/UL Std. 499
Certified to CAN/CSA Std. C22.2 No. 110
Conforme a ANSI/UL Std. 499
Certificación con CAN/CSA Std. C22.2 No. 110
Conforme à la norme ANSI/UL Std. 499
Certifié à la norme CAN/CSA Std. C22.2 No. 110
Tested and certified by WQA to NSF/ANSI 372
for lead free compliance.
Probado y certificado por WQA NSF/ANSI 372 para
el cumplimiento de las regulaciones sin plomo.
Testé et certifié par WQA à la NSF/ANSI 372 pour une
utilisation sans plomb.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AQM 2-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Aqua Power AQM 2-1

  • Page 1 OPERATION AND INSTALLATION TANKLESS ELECTRIC WATER HEATER WITH ELECTROMECHANICAL FLOW SWITCH » AQM 2-1 » AQM 2.5-1 » AQM 3-1 » AQM 3.5-1 » AQM 4-2 » AQM 6-2 Conforms to ANSI/UL Std. 499 Certified to CAN/CSA Std. C22.2 No. 110 Conforme a ANSI/UL Std.
  • Page 2: Table Of Contents

    CONTENTS | OPERATION GENERAL INfORMATION General Information 2 THIS IS THE SAFETY ALERT SYMBOL. IT IS USED Symbol key ����������������������������������� 2 TO ALERT YOU TO POTENTIAL PERSONAL INJURY Safety precautions  3 HAZARD. OBEY ALL SAFETY MESSAGES THAT FOLLOW THIS SYMBOL TO AVOID POSSIBLE INJURY OR DEATH.
  • Page 3: Safety Precautions

    GENERAL INfORMATION SAfETY PRECAuTIONS Safety precautions Register your product PLEASE READ AND FOLLOW THESE You must register this product within 90 days of INSTRUCTIONS. FAILURE TO FOLLOW THESE purchase on our web site in order to activate the INSTRUCTIONS COULD RESULT IN SERIOUS BODILY standard warranty or to be eligible for the extended war- INJURY OR DEATH.
  • Page 4: Temperature

    AQM 4-2 – – – – AQM 6-2 – – – – – Min. water flow to activate unit. * AQM 2-1 is internally restricted to 0.32 gpm [ °C ] Type l/min AQM 2-1 – – – – – –...
  • Page 5 GENERAL INfORMATION TECHNICAL DRAWINGS V > p > AQM 2-1/2.5-1/3-1/3.5-1 L N GRD AQM 4-2/6-2 L L GRD Figure C legend 5 Electrical junction box 6 Water supply line for faucet installation 7 Sink 8 Cold valve (right) 9 Hot valve (left)
  • Page 6: Overview

    AQM 2-1 models are internally restricted to 0.32 gpm (1.3 l/ warm climate zones such as the Caribbean region, Central America min). AQM 2-1, 2.5-1, 3-1 ship with a 0.5 gpm (1.9 l/min) pressure and Mexico due to the higher ambient water temperatures.
  • Page 7: Incorrect Use

    INSTALLATION INSTALLATION INSTRuCTIONS Incorrect use Mounting the unit The following are not permitted and will void the factory UNIT MUST BE INSTALLED WITH THE PLUMBING warranty: CONNECTIONS POINTING DOWNWARD OR UP- - Installation of the appliance where it is at risk WARD ONLY.
  • Page 8: Electrical Connection

    WARNING: AS WITH ANY ELECTRIC APPLIANCE, FAILURE TO ELECTRICALLY GROUND UNIT MAY RESULT IN SERIOUS INJURY OR DEATH. CAUTION: INSTALLING AN AQM 2-1, AQM 2.5-1, AQM 3-1, OR AQM 3.5-1 ON A 208 V OR 220–240 V CIRCUIT WILL Water heater hand over DESTROY THE HEATING ELEMENT.
  • Page 9: Technical Data

    AQM 2-1 models are internally restricted to 0.32 GPM / 1.2 l/min. AQM 2-1, 2.5-1, 3-1 ship with a 0.5 GPM pressure compensating flow-reducer/aerator that must be installed. AQM 3.5-1, 4-2 ship with a 0.66 GPM pressure compensating flow-reducer/aerator that must be installed.
  • Page 10: Troubleshooting

    INSTALLATION TROubLESHOOTING 12. Troubleshooting Symptom Possible cause Solution No hot water No electrical power. Check the circuit breaker and check despite fully voltage at the wiring block. opened hot water faucet. The activation flow rate needed Clean filter screen. to turn on the heating element has not been reached.
  • Page 11: Warranty

    WARRANTY | ENVIRONMENT AND RECYCLING Tankless Electric Domestic Hot Water Heaters All AQM, AQC, AQE, DHE, & DHE Pro Models Tankless Electric Domestic Hot Water Heaters 14. Warranty All AQM, AQC, AQE, DHE, & DHE Pro Models LIMITED WARRANTY LIMITED WARRANTY Subject to the terms and conditions set forth in this 4.
  • Page 12 AquaPower ® 17 West Street | West Hat eld, MA 01088 Tel. 800.582.2213 | Fax 413.247.3369 info@aptankless.com www.aptankless.com Due to our continuous process of engineering and technological advancement, specifications may change without AQM-5.2016 notice. | Salvo error o modificación técnica! | Sous réserve d‘erreurs et de modifications techniques!
