EWM TGM 40230 Handy Operating Instructions Manual
Electrode grinding machine
Hide thumbs
Also See for TGM 40230 Handy:
- Operating instructions manual (27 pages) ,
- Operating instructions manual (28 pages)
Related Manuals for EWM TGM 40230 Handy
Summary of Contents for EWM TGM 40230 Handy
- Page 1 Operating instructions Electrode grinding machine TGM 40230 Handy 099-003412-EW501 16.11.2015 Register now and benefit! Jetzt Registrieren und Profitieren! www.ewm-group.com...
- Page 2 +49 2680 181-0. A list of authorised sales partners can be found at www.ewm-group.com. Liability relating to the operation of this equipment is restricted solely to the function of the equipment.
-
Page 3: Table Of Contents
Changing the filter ........................18 Replacing the grinding disk ......................19 Cleaning ............................20 7 Technical data ............................21 TGM 40230 Handy ........................21 8 Accessories ............................22 Replaceable parts ........................22 9 Appendix A ............................23 Overview of EWM branches ......................23 099-003412-EW501 16.11.2015... -
Page 4: Safety Instructions
Safety instructions Notes on the use of these operating instructions Safety instructions Notes on the use of these operating instructions DANGER Working or operating procedures which must be closely observed to prevent imminent serious and even fatal injuries. • Safety notes include the "DANGER" keyword in the heading with a general warning symbol. •... -
Page 5: Explanation Of Icons
Safety instructions Explanation of icons Explanation of icons Symbol Description Special technical points which users must observe. Correct Wrong Press Do not press Press and keep pressed Turn Switch Switch off machine Switch on machine enter the menu ENTER Navigating in the menu NAVIGATION Exit the menu EXIT... -
Page 6: General
Safety instructions General General WARNING Risk of accidents due to non-compliance with the safety instructions! Non-compliance with the safety instructions can be fatal! • Carefully read the safety instructions in this manual! • Observe the accident prevention regulations and any regional regulations! •... -
Page 7: Ambient Conditions
Safety instructions Transport and installation 2.4.1 Ambient conditions CAUTION Equipment damage due to dirt accumulation! Unusually high quantities of dust, acid, corrosive gases or substances may damage the equipment. • Avoid high volumes of smoke, vapour, oil vapour and grinding dust! •... -
Page 8: Intended Use
Documents which also apply 3.2.1 Warranty For more information refer to the "Warranty registration" brochure supplied and our information regarding warranty, maintenance and testing at www.ewm-group.com! 3.2.2 Service documents (spare parts) DANGER Do not carry out any unauthorised repairs or modifications! -
Page 9: Machine Description - Quick Overview
Machine description – quick overview Documents which also apply Machine description – quick overview Figure 4-1 Item Symbol Description Infeed channel Guide element for setting the grinding tracks Grinding attachment Depth gauge Grinding attachment clamping bolt On/off switch Filter casing Grinding angle scale Ventilation slot for machine cooling Retaining bolt... -
Page 10: Design And Function
Design and function Documents which also apply Design and function WARNING Health risks due to electrode materials! Welding electrodes may contain materials that are damaging to health! • Observe the information from the electrode manufacturer! CAUTION Open infeed channel! If the infeed channel is left open, chips and dirt particles can be expelled from the channel when the grinding disk is running and might get into the eyes or be breathed •... -
Page 11: Presets
Design and function Presets Presets 5.1.1 Selecting the grinding track If the result is not satisfactory, the grinding machine provides the option to select different tracks on the disk, depending on the wear of the diamond disk. Figure 5-1 Item Symbol Description Guide element for setting the grinding tracks "S"... -
Page 12: Preparing Electrodes For The Grinding Process
Design and function Presets 5.1.2 Preparing electrodes for the grinding process Various collet chucks modified to the electrode diameter should be used to secure the electrodes for the grinding process. Status on delivery! The collet chuck for an electrode with a diameter of 2.4 mm is pre-fitted in the electrode holder at the factory. -
Page 13: Setting The Grinding Angle Of The Tungsten Electrode
Design and function Presets 5.1.3 Setting the grinding angle of the tungsten electrode The grinding angle can be set from 15° to 180° in 5° increments. The angle of 180° creates a right-angled surface at the electrode tip. Figure 5-3 Item Symbol Description Clamping bolt... -
Page 14: Setting The Speed
Design and function Setting the speed Setting the speed Using a speed that matches the electrode diameter is very important to achieve precise and clean grinding of the electrode. Figure 5-4 Item Symbol Description Motor casing Mains connection cable - See 7 Technical data chapter Speed controller •... -
Page 15: Inserting The Electrode
Design and function Inserting the electrode Inserting the electrode Before every grinding operation: Set the electrode grinding using the grinding attachment clamping bolt depth gauge. Figure 5-5 Item Symbol Description Infeed channel Grinding attachment Depth gauge Electrode holder Inspection glass Electrode Grinding disk Depth gauge setting bolt... -
Page 16: Grinding The Electrode
Design and function Grinding the electrode Grinding the electrode Figure 5-6 Item Symbol Description Grinding attachment Infeed channel Stop piece Electrode holder • Check that the on/off switch is in the "0" position. • Connect the machine to the power supply. •... -
Page 17: Maintenance, Care And Disposal
Maintenance, care and disposal Grinding the electrode Maintenance, care and disposal WARNING Mains voltage! All mains and supply lines on the machine being tested must be disconnected before cleaning or testing. • Disconnect all mains and supply lines. Operation without a filter! Operating the grinding machine without a filter cartridge may mean that poisonous dust, chips and smoke are expelled from the machine. -
Page 18: Changing The Filter
Maintenance, care and disposal Changing the filter Changing the filter The filter needs to be changed when there are considerable deposits of grinding particles on the inspection glass. Figure 6-1 Item Symbol Description Filter casing Retainer grille Retaining bolt Motor casing Allen key, SW 4 Filter cartridge Rubber seal... -
Page 19: Replacing The Grinding Disk
Maintenance, care and disposal Replacing the grinding disk Replacing the grinding disk Figure 6-2 099-003412-EW501 16.11.2015... -
Page 20: Cleaning
Maintenance, care and disposal Cleaning Item Symbol Description Stop bolt Open-ended spanner, SW 17 Grinding attachment Connecting link Allen key, SW 8 Grinding attachment clamping bolt Grinding disk Motor casing Open-ended spanner, SW 14 Open-ended spanner, SW 13 • Remove the electrode holder. •... -
Page 21: Technical Data
Technical data TGM 40230 Handy Technical data TGM 40230 Handy Weight without accessories 2.5 kg Performance 850 W Mains connection (EN 50144) 230 V/50 Hz 8000 – 22000 U/min Speed Diamond disk diameter 40 mm 0.8-4.0 mm Electrode diameter Grinding angle 15-180°... -
Page 22: Accessories
Accessories Replaceable parts Accessories Replaceable parts Type Designation Item no. DG Handy Diamond disk for EWM tungsten electrode grinders 098-003673-00000 EXCENTER excenter 098-004309-00000 COL Porta/Handy Ø 0.8 mm Collet chuck for EWM tungsten electrode grinders 098-003696-00000 COL Porta/Handy Ø 1.0 mm... -
Page 23: Overview Of Ewm Branches
Appendix A Overview of EWM branches Appendix A Overview of EWM branches 099-003412-EW501 16.11.2015...
