Onkyo HTP-645(B) Service Manual

5.1-CH HOME THEATER SPEAKER PACKAGE
MODEL
- - Front Speakers (L/R) - -
"SKF-645F"
- - Surround Speakers (L/R) - -
"SKM-645S"
- - Center Speaker - -
"SKC-645C"
Cannot remove the speaker grill.
B MDD
SAFETY-RELATED COMPONENT
WARNING!!
COMPONENTS IDENTIFIED BY MARK
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ONKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
IN THIS MANUAL.
MAKE LEAKAGE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.
SERVICE MANUAL SERVICE MANUAL
HTP-645(B)
Black model
120V AC, 60Hz
Ref. No. 4036
- - Powered Subwoofer - -
"SKW-540"
ON THE
HTP-645
092007
