a. Measuring DC Volts (V)
CAUTION!
Do not attempt to make a voltage measurement if a test
lead is plugged in the A or µmA input jack. Instrument
damage and/or personal injury may result.
WARNING!
!
Do not attempt to make a voltage measurement of more
than 1000V or of a voltage level that is unknown.
Instrument set-up:
FUNCTION
V
Measurement Procedure:
1. Disconnect power to circuit to be measured.
2. Plug black test lead into COM input jack.
3. Plug red test lead into the VΩ
4. Set the rotary switch to the V function.
5. Connect test leads to circuit to be measured.
6. Reconnect power to circuit to be measured.
7. Read the voltage on the 440.
Optional DMM Functions (refer to page 27)
REL
F1
PROG (refer to page 27)
REC
F1
Optional D Mode Functions (refer to page 29)
COMBO METER
F1
17 15
BLACK RED
TEST LEAD TEST LEAD
COM VΩ
PEAK FREQ
HOLD
F2
REL% COMP
F2
SCOPE TREND
F2
MINIMUM
READING
0.1mV
input jack.
PERI
F3 F4
EDIT
F3 F4
F3 F4
MAXIMUM
READING
1000V
FULL
AUTO
F5
EXIT
F5
EXIT
F5
