D. MEASUREMENT TECHNIQUES

1. Controls and Functions:

Push Buttons
F1-F5
D Mode Selects digital scope mode with functions displayed
Hold A
RGE
PROG
T.BASE Push once to select time base, push again to
MEM
Rotary Switch
OFF
V
V
Ω
µA
mA
A
Hz
LOGIC
15 13
Selects additional functions displayed across the
bottom of the LCD.
across the bottom of the LCD.
Freezes the analog reading on the LCD.
Push once to select manual ranging, push again to
return to functions.
Push once to select REC, REL% and COMPARE
functions. Once selected, use the EDIT button to set
parameters.
return to functions.
Push once to waveform and setup memory, push
again to return to functions.
Turn back light on and off.
Select help text.
Turns the instrument off.
Selects the DCV function.
Selects the ACV function.
Selects resistance or continuity buzzer function.
Selects the diode test function.
Selects DC or AC microamps.
Selects DC or AC milliamps.
Selects DC or AC amps.
Selects the Frequency function.
Selects the Logic Test function.
