- Page 1 SP1 CONTINUOUS LIGHT KIT With Boom Model: 2815 SP1 Light Kit ASSEMBLY AND USER MANUAL Copyright 2013 DTX International...
- Page 2 SP1 CONTINUOUS LIGHT KIT The Square Perfect 2275 Watt Digital Video Continuous Softbox Lighting Kit/Boom Set is used in the studio to provide any form of lighting above the subject. This product is particularly effective as a hair light or back light, which breaks up the subject from the background.
- Page 3 CONTINUOUS LIGHT KIT PARTS Light Stand (2) Carry Bag (1) 45W Light Bulb (10) Light Body (2) Main Diffuser Lens (2) Power Cord (2) Inner Diffuser Lens (2) Soft Box Bag (2) Softbox Body (2) High Tension Support Flex Rod (8) Copyright 2013 DTX International...
- Page 4 SP1 CONTINUOUS LIGHT KIT SETUP 1. First, open the case and remove all of the components. Then remove the components from their boxes and bags. Verify that you have all the parts listed on page 3. Set aside parts belonging to the boom stand (Boom stand parts list is on page 6).
- Page 5 G. Install the inner diffuser lens (I) into the light box using the hook & loop fasteners on the inside the softbox body (Figure 6). H. The final step in completing the softboxes is to install the main diffuser lenses (H) over the softbox body by hooking one corner of the lens over one corner of the body and fitting the entire lens over the soft...
- Page 6 Boomstand and Softbox Parts Copyright 2013 DTX International...
- Page 7 Boomstand and Softbox Assembly Figure 2 1. Obtain the softbox with socket (A) and unfold [figure 1]. Ensure that the inner rods are secure in the corner pockets before proceeding [figure 2]. 2. Next, grasp the center ring [figure 3]and push towards the socket until it locks in place.
- Page 8 Boomstand and Softbox Assembly Cont. 5. Remove the small black cap on the end of the tripod stand (G) and insert the silver end into the bracket on the boom stand adaptor (D). Tighten the wingnut to lock the adapter onto the tripod [figure 8]. 6.
