HP LL763AA Quickspecs

Compaq le2002x 20-inch led backlit lcd monitor
Hide thumbs
1
2
3
4
5
6
7

Advertisement

Quick Links

Download this manual
QuickSpecs
Overview
1. Menu
Opens, selects or exits the OSD menu.
2. Minus
If the OSD menu is on, press to navigate
backward through the OSD menu and
decrease adjustment levels.
3. Plus/source
If the OSD menu is on, press to navigate
forward through the OSD menu and
increase adjustment levels. If the OSD
menu is inactive, press to activate the
source button that chooses the video signal
input (VGA or DVI).
Model
LL763AA
HP Compaq LE2002x 20-inch LED Backlit LCD Monitor
4.
5.
6.
DA - 14082 Canada — Version 8 — May 25, 2012
OK/auto
If the OSD menu is on, press to select the
highlighted menu item.
If the OSD menu is inactive, press to
activate the auto adjustment feature to
optimize the screen image.
Power
Turns the monitor on or off.
Power LED
Blue = Fully powered.
Amber = Sleep mode.
Flashing Amber = Sleep Timer mode.
Page 1

Advertisement

loading

Related Manuals for HP LL763AA

Summary of Contents for HP LL763AA

  • Page 1 QuickSpecs HP Compaq LE2002x 20-inch LED Backlit LCD Monitor Overview 1. Menu Opens, selects or exits the OSD menu. OK/auto If the OSD menu is on, press to select the highlighted menu item. If the OSD menu is inactive, press to activate the auto adjustment feature to optimize the screen image.

  • Page 2: Technical Specifications

    Colour Gamut (typical) Colour Support** Can display up to 16.7 million colours *All performance specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary either higher or lower. ** With the use of FRC technology. On Screen Display Buttons or Switches Menu, Minus ("-"), Plus/Source ("+"), "OK/Auto"...
  • Page 3 QuickSpecs HP Compaq LE2002x 20-inch LED Backlit LCD Monitor Technical Specifications Maximum Pixel Clock 170 MHz Speed User Programmable Yes (10 user modes) Modes Anti-Glare Default Colour 6500 K Temperature Video/Other Inputs Plug and Play Input Connectors VGA (analog), DVI-D w/ HDCP...

  • Page 4: Additional Information

    This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive - 2002/95/EC. This HP product is designed to comply with the Waste Electrical and Electronic Equipment (WEEE) Directive - 2002/96/EC. This product is in compliance with California Proposition 65 (State of California;...
  • Page 5 RoHS Directive on a worldwide basis. By July 1, 2006, RoHS substances will be virtually eliminated (virtually = to levels below legal limits) for all HP electronic products subject to the RoHS Directive, except where it is widely recognized that there is no technically feasible alternative (as indicated by an exemption under the EU RoHS Directive).
  • Page 6 EM870AA* QuickSpecs document. * The HP Quick Release has been designed to support a maximum of up to 24 lbs (10.9 kg) for all devices mounted. Because mounting surfaces vary widely and the final mounting method and configuration may vary, mounting fasteners are not supplied (other than the VESA-compliant screws). HP recommends that...
  • Page 7 All specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary either higher or lower. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
