STEP
SET UP YOUR MONITOR
PACKAGE CONTENTS
2
CONNECT THE ETHERNET CABLE TO A BROADBAND ROUTER (NOT INCLUDED)
FOR REMOTE VIEWING CAPABILITY
ROUTER NOT INCLUDED
4
TURN THE MASTER POWER SWITCH ON (LOCATED ON THE BACK OF THE MONITOR)
TO VIEW PICTURE
WWW.SYLVANIASECURITY.COM
- 4" Color Quad Monitor
4 - Color Cameras
4 - 57 ft. Extension Cables
4 - Camera Brackets
- Remote Control with Batteries
- Ethernet Network Cable
- Set-up CD ROM
- Quick Installation Guide
- Owner's Manual
- Power Cord
CONNECT CAMERAS TO MONITOR
Connect the first camera to the
CH1 input. Follow the same
steps to connect the other
three cameras to the CH2,
CH3, CH4 camera inputs.
3
CONNECT ONE END OF THE POWER CORD TO THE MONITOR; THE OTHER END TO AN
ELECTICAL OUTLET
Version: SY14Q6084CN: 06:02
PAGE
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sylvania SY14Q6084CN
Summary of Contents for Sylvania SY14Q6084CN
- Page 1 CONNECT ONE END OF THE POWER CORD TO THE MONITOR; THE OTHER END TO AN FOR REMOTE VIEWING CAPABILITY ELECTICAL OUTLET ROUTER NOT INCLUDED TURN THE MASTER POWER SWITCH ON (LOCATED ON THE BACK OF THE MONITOR) TO VIEW PICTURE WWW.SYLVANIASECURITY.COM PAGE Version: SY14Q6084CN: 06:02...
- Page 2 STEP 2 SET UP LOCAL VIEWING ON YOUR PC SELECT SYLVANIA IP EDIT PROGRAM OPTION INSERT SYLVANIA NETWORK SETUP SOFTWARE INTO THE COMPUTER’S CD ROM DRIVE Click the Sylvania IP EDIT option DOUBLE CLICK ON THE ITEM LISTED UNDER ‘MONITOR LISTS’ TO...
- Page 3 Information in this document is subject to change without notice. As our products are subject to continuous improvement, SVII and our subsidiaries reserve the right to modify product design, specifications and prices, without notice and without incurring any obligation. E&OE © 2006 SVII. All rights reserved. WWW.SYLVANIASECURITY.COM PAGE 3 Version: SY14Q6084CN: 06:02...
- Page 4 Click the ‘Create Account’ option B. Enter your computer’s MAC Address (recorded in Step 2, Part 4 A. Select the SY14Q6084CN option from the drop down menu C. Enter your unique URL name PRINT AND SAVE AUTOMATED EMAIL OPEN YOUR WEB BROWSER AND...
- Page 5 Information in this document is subject to change without notice. As our products are subject to continuous improvement, SVII and our subsidiaries reserve the right to modify product design, specifications and prices, without notice and without incurring any obligation. E&OE © 2006 SVII. All rights reserved. WWW.SYLVANIASECURITY.COM PAGE 5 Version: SY14Q6084CN: 06:02...
