Introducing the USB 3.0 2.5" Enclosure
The USB 3.0 to SATA 3Gb/s 2.5" Enclosure provides
large capacity mobile storage using 2.5" SATA
hard disk drives through hot-swapping USB 3.0
interface.
Features and Benefits
•
Quickly adds more storage space to your
USB-enabled PC (USB 3.0 recommended)
•
Supports USB 3.0 data transfer rate up to
5Gb/s
•
Tool-less design and no driver installation
required
•
Supports up to 2 TB hard disk capacity
Note: For maximum data throughput,
use a SATA 3Gb/s hard disk with the
enclosure and connect to a fully functional
USB 3.0 port.
04-0608B
USB 3.0 to SATA 3Gb/s 2.5"
Enclosure

Quick Installation Guide

1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Enclosure and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SIIG Enclosure

Summary of Contents for SIIG Enclosure

  • Page 1: Quick Installation Guide

    USB 3.0 to SATA 3Gb/s 2.5" Enclosure Quick Installation Guide Introducing the USB 3.0 2.5" Enclosure The USB 3.0 to SATA 3Gb/s 2.5" Enclosure provides large capacity mobile storage using 2.5" SATA hard disk drives through hot-swapping USB 3.0 interface.

  • Page 2: System Requirements

    7 (32-/64-bit) ) / Vista (32-/64- ® bit) / XP (32-/64-bit) / Server 2003 & 2008 (32-/64-bit) Package Contents • USB 3.0 to SATA 3Gb/s 2.5" Enclosure • USB 3.0 Y-split (data & power) cable • Carrying bag • Quick installation guide...

  • Page 3: Usb Connectors

    Power and Activity LED The LED indicator illuminates solid blue when the hard drive is connected and powered up. The LED flashes during data transfer. Do not disconnect the enclosure while the LED is flashing. USB Connectors Micro-B Type-A data (blue)
  • Page 4 9.5mm or less. Connect the Micro-B connector of the included USB 3.0 Y-split cable into the USB 3.0 connector of the enclosure. See Figure 2 for more information. Connect the blue Type-A connector of the included USB 3.0 Y-split cable to an available USB port of the computer (USB 3.0...

  • Page 5: Driver Installation

    Note: If Windows doesn't detect the enclosure, chances are the USB port doesn't provide enough power to power it up. In this case unplug the blue Type-A connector from the computer. Next, plug the beige Type-A connector into any USB port, and then replug the blue Type-A connector into any other USB port.

  • Page 6: Disconnecting From The Computer

    Using the USB 3.0 to 2.5" Enclosure An additional drive icon will appear in My Computer when the enclosure is plugged into a USB port. The enclosure acts just like a conventional hard disk drive in your system. Disconnecting From The Computer Before unplugging the USB 3.0 to SATA 3Gb/s...

  • Page 7: Technical Support And Warranty

    Step 1: Submit your RMA request. Go to www.siig.com, click Support, then RMA to submit a request to SIIG RMA or fax a request to 510-657-5962. Your RMA request will be processed, if the product is determined to be defective, an RMA number will be issued.
  • Page 8 Fremont, CA 94538-3152, USA Phone: 510-657-8688 USB 3.0 to SATA 3Gb/s 2.5" Enclosure is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered trademarks of SIIG, Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. All other names used in this publication are for identification only and may be trademarks of their respective owners.
