- Page 1 DV-2190K DV-2190K DVD PLAYER OWNER'S MANUAL IMPORTANT! WARRANTY INFORMATION INSIDE. PLEASE READ FOR INQUIRIES CALL 1800 656 700 WWW.TEAC.COM.AU...
- Page 2 *Your nearest Authorised TEAC Service Centre is listed in your Owners Manual Owner's Name 6. In the event that this unit or any defective parts must be returned to TEAC Service Centres, a copy of Owner's Address this warranty certificate and of your purchase receipt must be enclosed to be a valid warranty. Such equipment or parts must be sent to the nearest authorised TEAC Service Centre.
- Page 3 Attention for parents: In order to avoid the situation that you forget the parental lock code and can not enter into the operation of parental lock setting, here we offer you the super secret code: 1369 . You may use this code to enter into the operation of parental setting.
- Page 4 Thanks for purchasing the DVD player . Before operating this player, please read this manual and retain it for future reference. SAFETY PRECAUCTION The lighting flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated dangerous voltage within the product s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
- Page 5 WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT EXPOSE THE APPLIANCE TO RAIN OR MOISTURE. DANGEROUS HIGH VOLTAGES ARE PRESENT INSIDE THE ENCLOSURE. DO NOT OPEN THE CABINET. CAUTION: When replacing the direct plug-in power supply or a separable cord-connected power supply, the replacement must be the exact duplicate, or one that has been recommended by the manufactures.
- Page 6 against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:...
-
Page 7: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS CAUTION: PLEASE READ THESE INSTRUCTIONS AND KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE. PLEASE HEED ALL WARNINGS AND FOLLOW ALL INSTRUCTIONS. This set has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard. The safeguards incorporated in the unit will protect you if you observe the following procedures for installation , use and servicing. - Page 8 company. For products intended to operate from battery power, or other sources, refer to the operating instructions. 3.Grounding or Polarization Do not defeat the safety purpose of the polarized grounding-type plug. A grounding type plug has two blades and a third grounding prong. If the provided plug does not fit into your outlet, consult and electrician for replacement of the obsolete outlet.
- Page 9 registers, stoves, or other products(including amplifiers) that produce heat. 6.Water and Moisture Do not use this apparatus near water, for example, near a bath tub, wash bowl, kitchen sink, laundry tub,swimming pool or in a wet basement and such like. 7.Cleaning Unplug this product from the wall outlet before cleaning .
- Page 10 Never spill liquid of any kind on the product. 12.Attachment Only use attachments/accessories specified by TEAC. 13.Disc Tray Keep your fingers well away the disc tray as it is closing.
- Page 11 15.Disc Do not use a cracked, deformed, or repaired disc. These discs are easily broken and may cause serious personal injury and product malfunction. 16.Damage Requiring Service Unplug this product from the wall outlet and refer ser- vicing to qualified service personnel under the following conditions: a)When the power-supply cord or plug is damaged.
-
Page 12: Notes On Handling
Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquids has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. 18.Replacement Parts When replacement parts are required, be sure the service technician has used replacement parts specified by the... - Page 13 at the factory. * Do not use volatile liquids, such as insect spray, near the DVD player. Do not leave rubber or plastic products in contact with the DVD player for a long time. They will leave marks on the finish. * The top and rear panel of the DVD player may become warm after a long period of use.
-
Page 14: To Obtain A Clear Picture
* For stubborn dirt, soak the cloth in a weak detergent solution, wring well and wipe. Use a dry cloth to wipe it dry. * Do not use any type of solvent, such as thinner or benzine, as they may damage the surface of the DVD player. - Page 15 please read the following carefully. Moisture condensation occurs, for example, when you pour a cold drink into a glass on a warm day. Drops of water form on the outside of the glass. In the same way, moisture may condense on the optical pick-up lens inside this unit, one of the most crucial internal parts of the DVD player.
- Page 16 Do not use the DVD player when moisture condensation may occur: *If you use the DVD player in such a situation, it may damage discs and internal parts. Remove the disc, connect the power cord of the player to the wall outlet, turn on the DVD player, and leave it for two or three hours.
- Page 17 Attention Warning: Do not expose the equipment to the rain or put it in the humid place in order to avoid any fire or electric shock. Do not open the enclosure since there is high voltage and a laser beam inside. If the equipment requires maintaining, turn to some professionals for help.
- Page 18 Precautions for Use of Power Supply: * Choose an appropriate power supply with the voltage specified in ~110-242V the Operation Instruction Manual. 50/60Hz When pulling out or inserting the plug, do not pull the power cable, but grasp the plug to pull out or insert. Make it sure that all connections and power cords are appropriately connected before the equipment is powered on.
-
Page 19: Table Of Contents
TABLE OF CONTENTS 1.User Interface-------------------------------------------------------------------------------------1 2.Playable discs for the Player--------------------------------------------------------------------4 3.Preparation Before Playing---------------------------------------------------------------------6 3.1 Accessories---------------------------------------------------------------------- -------------- 3.2 Battery installation for remote control---------------------------------------- --------------- 3.3 System connection-------------------------------------------------------------- --------------- 3.4 Setup of Output System-------------------------------------------------------- -------------- 4.Functional Buttons ---------------------------------------------------------------- ------------- 4.1 Functional Buttons on the DVD Player--------------------------------------- -------------- 4.2 Functional Buttons on the Remote Contro------------------------------- ------------------... -
Page 20: User Interface
1. User Interface Stop Front Panel: Play Menu Open/Close Audio Standby Disc Tray MIC Jack 1 ECHO MIC Jack 2 MIC Volume Back Panel Ports: Audio Outputs Video Outputs Video Outputs Video Outputs Audio Outputs... -
Page 21: Remote Control
Remote Control Open/Close Mute Spectrum Progressive Recall Numeric Clear Stop Search Zoom Play Audio(L/R) Pause Setup Right Left Enter Down Menu Volume Control(-) Volume Control(+) Previous Fast Forward Next Fast Reverse Title A-B Repeat Slow Motion Repeat Angle Program Window Navigation Standby Subtitle... - Page 22 Vacuum Fluorescent Display Disc Format Play Repeat Hour Minute Second Title Chapter/track Pause...
-
Page 23: Playable Discs For The Player
2. Playable discs for the Player Disc Type Symbol Dimensions... -
Page 25: Preparation Before Playing
3. Preparation before Playing 3.1 Accessories (Please check whether all the following accessories are available after unpacking.) Instruction Manual Video/Audio cord A Pair of Batteries Remote control... -
Page 26: Battery Installation For Remote Control
3.2 Battery Installation for Remote Control Open the battery compartment lid and insert a pair of AAA batteries with correct polarity as indicated. Please point at the remote sensor on the player while using the remote control. 3.3 System Connection 1.Turn off the power before connection. - Page 27 2.Connect with S-Video Terminal Connect the S-Video output and the Audio(L,R) outputs of the DVD player to matching inputs of your TV. 3.Connect with YUV (Y Pb/Cb Pr/Cr) Terminal Connect the Y, Pb/Cb, Pr/Cr jacks on the disc player and the corresponding jacks on the TV with audio cord.
- Page 28 Connecting an Audio Power Amplifier 1. Connection with a dual-channel power amplifier. The specific connection is indicated in the picture on the right.
- Page 29 2.Connection to an AV power amplifier with 5.1 channels and surrounding audio input.
-
Page 30: Setup Of Output System
3. Connection to digital audio optical fiber or coaxial terminal. Directly connect the optical fiber cord or the coaxial cord of the AV amplifier with the optical fiber or coaxial terminal of this equipment (This equipment has a factory-setting mode SPDIF-PCM , then, connect the video terminal of this equipment with the video terminal of the TV set. -
Page 31: Functional Buttons
4. Function Buttons 4.1 Function Buttons on the DVD Player (the same as the function of the corresponding buttons on the remote control) 1.STANDBY Press the button for the first time and the player will be in standby state and reduce the power consumption. Press the button again and the player will recover operation. -
Page 32: Functional Buttons On The Remote Contro
For the Super VCD and VCD 2.0 disc, press this button to shift between the on and off states of PBC. For VCD 1.1 and CD disc, this button is invalid.. 6. AUDIO(L/R) Press to select the language for audio channels.(DVD can hold up to 8 different languages and VCD up to 4 languages. - Page 33 5. PAUSE In play state, press the button for the first time and the player will be in pause state. Press the button again, and the player will be in step state. In pause state or step state, press PLAY button, the player will be in playing state.
- Page 34 11.ANGLE Press this button to enjoy pictures shot from different angles. ( Disc support is required) 12. WINDOW Press this button to enter the window interface of multimedia. (Refer to 4.4) 13. MUTE Press this button once to turn off the sound and press it again to turn on the sound.
- Page 35 18. 3D Press button to choose a variety of surrounding effects. 19.SETUP Press this button to enter into the menu for system setting and press this button again to exit the menu. 20.ENTER Press the button to activate the selected menu option. 21.OSD Press this button to display the information about the disc being played.
- Page 36 25. PROGRAM Press the button and enter numbers into the corresponding interface. Then move the highlighted bar to START column and press button to perform the programmed PLAY ENTER play function. If you don't want a programmed play, just enter into the programming menu and move the highlighted bar to the STOP column.
-
Page 37: Navigation
4.3 Navigation Press NAVIGATION to display a figure similar to that of the remote control. Press the arrow keys and ENTER button on the remote control to perform functions such as fast forward, fast reverse, previous track, next track, step, slow motion, slow rewind, pause, play, audio, subtitle, angle, etc. - Page 38 Turn the MIC knobs on the front VOLUME ECHO panel to the minimum and then connect microphones to jacks. You may connect two microphones to enjoy antiphonal singing. 4.5.2.Start KARAOKE (1) Turn knob to adjust the volume of microphone. MIC VOLUME (2) Turn ECHO knob to adjust the volume of echo.
-
Page 39: How To Enjoy Mp3 Or Wma Discs
auto replace karaoke (When person is singing, the player doesn't sing; vice versa) or auto follow karaoke (when person is singing, the player is singing; vice versa). Note: This function doesn't apply to DVD and SVCD discs. Noise handling: *Take the microphone far away from TV set or SPEAKER. *Turn down the volume of TV set or SPEAKER. -
Page 40: How To Enjoy The Digital Album Of Picture Cd
4.7 How to Enjoy the Digital Album of Picture CD The directory structure of a Picture CD disc is shown in the picture on the right. In the folder play mode, press arrow keys to choose the root directory and then enter the sub directory. Highlight the file name of any picture and a small preview will be displayed. -
Page 41: Other Functions
(as shown in Pictures 1 and 2 in the next page), including the operation instruction for Picture CD. Press EXIT button to exit from this interface. 4.7.2 Other Functions Remote Key Function For other functions, please refer to the introduction of Program Transition Effect Stop... -
Page 42: System Setup
5. System setup With powerful functions, the player can bring you perfect video-audio enjoyment after the following setup. 5.1 Enter the menu * Press SETUP key on the remote control to enter the menu of General Setup Page * Press the direction keys on the remote control to select or adjust, and press key to confirm. -
Page 43: Video Setup Page
5.2.3. Screen Saver When this option is set to ON , the screen saver will be activated within a few minutes to protect the screen of your television if the picture becomes static, for example modes. STOP PAUSE 5.2.4. Disc Menu General Setup Page This item can select several languages (supported by disc) - Page 44 5.3.2. TV Display Here you can select the screen formate of the TV set, Normal/PS (pan scan) , Normal/ LB (letter box) , or wide screen. (This function needs supports of disc) 5.3.3.Component Set the YUV output to progressive or interlacing. When the player is connected to a TV set of progressive scanning though YPbPr, select .
-
Page 45: Audio Setup Page
5.4 Audio Setup Page Audio Setup Page Press direction keys to enter the setup page. Speaker Setup SPDIF Setup Dolby Digital Setup Equalizer Setup 5.4.1. Speaker Setup * Downmix Go To Audio Setup Page LT/RT means audio signal output through left and right . means stereo signal output. - Page 46 *Dialog It is used to enhance definition of dialogue. Note:This function is unavailable if the audio mode is set to 5.1CH. 5.4.2.SPDIF Setup * SPDIF Output If the power amplifier connected to the DVD player includes an AC-3 or DTS decoder set SPDIF toRAW .
-
Page 47: Password Setup Page
3.Dolby Digital Setup *Dynamic The dynamic range(ratio between low volume to high volume passages) can be adjusted to suit different listening requirements. Use low or no compression for realistic audio effects during day time hours. High compression is recommended during the night to automatically reduce the audio level of high volume scenes, such as explosions. -
Page 48: Intelligent Screen Saver Function
6. INTELLIGENT SCREENSAVER AND STANDBY FUNCTION With the same function of screen protection and stand-by function as a computer, it will automatically enter into screen protection after three minutes in stop or no disc state, so as to protect your TV screen. After the screen protection state lasts for 20 minutes, it will automatically enter the stand-by state, then the DVD display doesn't light, there is no video output, and the power consumption is greatly lowered, thus the service... - Page 49 No sound: Remote control does not work. * Ensure that the player is connected properly * Remove the obstacles between the player with other systems, such as power amplifier and the remote control. or TV set. * Point the remote control at the sensor on * Ensure that TV set or power amplifier is the front panel of the player.
-
Page 50: Technical Specifications
8. TECHNICAL SPECIFICATIONS Video system AUTO/NTSC/PAL Audio response 20Hz~20kHz 1dB Audio SNR 90dB Audio output Output level:1~2V (analog audio) Audio output Output level:0.5Vp-p (digital audio) Video output Output level:1Vp-p load impedance: 75 unbalanced negative Output Output level: brightness (Y) 0.7Vp-p, chrominance(C):0.88Vp-p S-Video output load impedance: YUV(Y, Cb,... - Page 51 Power supply ~110-242V 50/60Hz Power consumption < 20W Dimensions of 420(L) X 274(W) X 41(H) mm bare player Net Weight 2.75Kg DOLBY: * Producing under the authorization of Dolby laboratory. The symbol of "Dolby" Dolby and double D are registered trademarks of Dolby laboratory. It is a secret "...
- Page 52 MACROVISION:...
- Page 53 TEAC TOTAL CARE info teac.com.au or visit our website at http://www.teac.com.au Freecall telephone 1800-656700 between Monday to Friday-EST 9am to 5pm [ New Zealand: TOLL FREE 0508 347328,8am to 4:30pm ]...
- Page 54 TEAC CORPORATION 3-7-3,Nakacho, Musashino-shi, Tokyo 180-8550, Japan. Phone:(0422)52-5081 TEAC AUSTRALIA PTY.,LTD. A.B.N.80 005 408 462 280 William Street, Melbourne VIC 3000. Phone:(03)9672 2400 HEAD OFFICE Unit 8,20-22 Foundry Rd,Seven Hills, NSW 2147. Phone:(02)8811 4000 NSW OFFICE 335 Montague Road, West End, QLD 4101.
