3 DVD MINI COMPONENT SYSTEM
DVD/CD/MP3-CD/CD-R/RW PLAYBACK
AH68-02059K
WITH USB HOST
user manual
imagine the possibilities
Thank you for purchasing a Samsung product.
To receive a more complete service,
please register your product at
www.samsung.com/global/register
MAX-DA54
MAX-DA55
Advertisement
Table of Contents
Related Manuals for Samsung MAX-DA54
Summary of Contents for Samsung MAX-DA54
- Page 1 3 DVD MINI COMPONENT SYSTEM WITH USB HOST DVD/CD/MP3-CD/CD-R/RW PLAYBACK user manual imagine the possibilities Thank you for purchasing a Samsung product. To receive a more complete service, please register your product at www.samsung.com/global/register AH68-02059K Downloaded From DvDPlayer-Manual.com Samsung Manuals...
-
Page 2: Safety Warnings
Use of this product is for personal use only. Condensation may occur if your player or disc have been stored in cold temperatures. If transporting the player during the winter, wait approximately 2 hours until the unit has reached room temperature before using. Downloaded From DvDPlayer-Manual.com Samsung Manuals... -
Page 3: Table Of Contents
Playing Media Files using the USB feature.........................21 Displaying Disc Information ..............................23 Power Saving Function Fast/Slow Playback................................24 Skipping Scenes/Songs ..............................25 The MAX-DA54/DA55 automatically shuts itself off after 20 minutes in the stop mode(only for Angle Function ..................................26 USB, DVD). Repeat Playback.................................27 A-B Repeat Playback.................................29 Customized TV Screen Display Zoom Function ..................................30... -
Page 4: Description
26. POWER SOUND 14. SLEEP 27. TIMER ON/OFF 15. TUNER MEMORY 28. CD OPEN/CLOSE 16. MULTI JOG 29. CD DISC CHANGE FM Antenna User's Manual 17. ENTER 30. CD DISC SELECTION BUTTONS 18 . TAPE 1/2 Downloaded From DvDPlayer-Manual.com Samsung Manuals... -
Page 5: Remote Control
P.SOUND button ON/OFF P.SOUND TIMER/CLOCK TIMER ON/OFF button TUNER MEMORY DEMO TUNER MEMORY/ P.SCAN DIMMER ECHO REMAIN REMAIN button P.SCAN button SLOW button, MO/ST button LOGO button TIMER/CLOCK button DEMO/DIMMER button ECHO button EQ button Downloaded From DvDPlayer-Manual.com Samsung Manuals... -
Page 6: Connecting The Speakers
Do not install on the wall or on a high place of pole or other unstable place to prevent any safety accident caused by falling of the speaker. • Do not take the speaker near from TV or computer monitor. The speaker near the TV or computer monitor may influence the quality of the screen display. Downloaded From DvDPlayer-Manual.com Samsung Manuals... -
Page 7: P.scan(Progressive Scan) Function
This function works only on TVs equipped with component video inputs (Y, Pr, Pb) that support Progressive Video. (It does not work on TVs with conventional component inputs, i.e., non-progressive scan TVs.) • Depending on the brand and model of your TV, this function may not work. Downloaded From DvDPlayer-Manual.com Samsung Manuals... -
Page 8: Connecting External Components
Note Connect Audio In on the DVD player to Audio Out on the external analog component. • Be sure to match connector colors. Press AUX to select AUX. • ‘ AUX’ appears in the display. Downloaded From DvDPlayer-Manual.com Samsung Manuals... -
Page 9: Setting The Clock
) button is pressed, CHAPTER ELAPSED TOTAL ELAPSED playback starts from the beginning. CHAPTER REMAIN TOTAL REMAIN To temporarily pause playback, press PAUSE button during playback. • To resume playback, press PLAY( ) button again. Downloaded From DvDPlayer-Manual.com Samsung Manuals... -
Page 10: Mp3/Wma-Cd Playback
Icon. • Movie File Icon • To view image files only, select the Icon. • All File Icon • To view movie files only, select the Icon. • To select all files select the Icon. Downloaded From DvDPlayer-Manual.com Samsung Manuals... -
Page 11: Divx Playback
Among the available DivX audio formats, DTS Audio is not supported. • WMV V8 is not supported for WMV files. • When burning a subtitle file to a CD-ROM with your PC, be sure to burn it as an SMI file. Downloaded From DvDPlayer-Manual.com Samsung Manuals... -
Page 12: Playing Media Files Using The Usb Feature
To select all files select the Icon. The USB host function of this product does not support all USB devices. • To view movie files only, select the Icon. For the information on the supported devices,pls see the Page66. Downloaded From DvDPlayer-Manual.com Samsung Manuals... -
Page 13: Displaying Disc Information
• During fast playback of a CD or MP3-CD, sound is heard only at 2x speed, and not at 4x, 8x, and 32x speeds. DivX display CHAPTER display REPEAT PLAYBACK display STEREO (L/R) display • No sound is heard during slow playback and step motion playback. Downloaded From DvDPlayer-Manual.com Samsung Manuals... -
Page 14: Skipping Scenes/Songs
REMAIN Press STEP button. • The picture moves forward one frame each time the button is pressed during playback. • Note The Angle function works only with discs on which multiple angles have been recorded. Downloaded From DvDPlayer-Manual.com Samsung Manuals... -
Page 15: Repeat Playback
INFO SLEEP SLOW ZOOM LOGO MO/ST REPEAT TIMER P.SOUND TIMER/CLOCK ON/OFF TUNER MEMORY DEMO P.SCAN DIMMER ECHO REMAIN Note • For MP3 and JPEG discs, you cannot select Repeat Play from the information display screen. Downloaded From DvDPlayer-Manual.com Samsung Manuals... -
Page 16: A-B Repeat Playback
To return to normal playback, press the Cursor button to select OFF. • The A-B Repeat function does not operate with DivX, MP3 or JPEG discs. • The Zoom function does not operate with DivX discs. Downloaded From DvDPlayer-Manual.com Samsung Manuals... -
Page 17: Selecting Audio/Subtitle Language
• When playing an MP3 or JEPG disc, you SP 02/ 03 cannot use to move a folder. FR 03/ 03 To move a folder, press (Stop) and OFF / 03 then press Downloaded From DvDPlayer-Manual.com Samsung Manuals... -
Page 18: Using Disc Menu
KEY CONTROL SLEEP INFO Press MENU button to exit the setup screen. SLOW ZOOM LOGO MO/ST REPEAT TIMER P.SOUND TIMER/CLOCK ON/OFF TUNER MEMORY DEMO Press EXIT button to exit the setup screen. P.SCAN DIMMER ECHO REMAIN Downloaded From DvDPlayer-Manual.com Samsung Manuals... -
Page 19: Setting The Language
Press MENU or EXIT button to exit the setup screen. language will not change even if you set it to your desired language. Press RETURN button to return to the previous level. Downloaded From DvDPlayer-Manual.com Samsung Manuals... -
Page 20: Setting Tv Screen Type
P.SOUND TIMER/CLOCK ON/OFF TUNER MEMORY DEMO P.SCAN DIMMER ECHO REMAIN Press RETURN button to return to the previous level. Press MENU button to exit the setup screen. Press EXIT button to exit the setup screen. Downloaded From DvDPlayer-Manual.com Samsung Manuals... -
Page 21: Setting Parental Controls (Rating Level)
Press MENU button to exit the setup screen. Press CANCEL button to cancel the error numeric when you inputting password. Press EXIT button to exit the setup screen. Press MENU button to exit the setup screen. Downloaded From DvDPlayer-Manual.com Samsung Manuals... -
Page 22: Setting The Wallpaper
Press MENU button to exit the setup screen. Select this to set the Select this to set the desired Samsung Logo image as image as your wallpaper. your wallpaper. Press EXIT button to exit the setup screen. Downloaded From DvDPlayer-Manual.com Samsung Manuals... -
Page 23: Setting The Drc (Dynamic Range Compression)
Press RETURN button to return to the previous level. Press MENU button to exit the setup screen. Press RETURN button to return to the previous level. Press EXIT button to exit the setup screen. Press MENU button to exit the setup screen. Downloaded From DvDPlayer-Manual.com Samsung Manuals... -
Page 24: Listening To Radio
(This applies only when listening to an FM station.) remote control to select a channel. • Each time the button is pressed, the sound switches between "STEREO" and "MONO". • In a poor reception area, select MONO for a clear, interference-free broadcast. Downloaded From DvDPlayer-Manual.com Samsung Manuals... -
Page 25: Listening To A Cassette
2. In tape stop mode, press and hold the STOP button for 5 seconds, the tape deck will be restored. 3. If you first use the main set, when you turn on the unit, the tape deck will be restored. Downloaded From DvDPlayer-Manual.com Samsung Manuals... -
Page 26: Recording A Compact Disc
• •You can use CD/SYNC. button Press and hold CD SYNC. button only in CD Playback Mode. during the playback of CD to start the recording from the first part of the music being played. Downloaded From DvDPlayer-Manual.com Samsung Manuals... -
Page 27: Recording A Radio Program
During CD Ripping,do not deal impact.If is shocked while CD Ripping,CD Ripping YP-K3 Samsung MP3 Player • REC is displayed and recording maybe disengage. YV-150 Samsung MP3 Player starts. YP-U3 Samsung MP3 Player Sometimes, some of USB devices, CD Ripping time is long. Downloaded From DvDPlayer-Manual.com Samsung Manuals... -
Page 28: Timer Function
You can also use Multi Jog on the front panel to instead button on the remote control in step 4,5,6,7. • If there is no tape, disc or usb, when you select the “TAPE, DVD/CD, USB, it will automatically Downloaded From DvDPlayer-Manual.com Samsung Manuals change to “TUNER”. -
Page 29: Power Sound Function
Result: BASS is displayed and “P. BASS” is When CD Ripping,the EQ function can’t work and the displayed for a few seconds. EQ automatically covert to “PASS” mode. To cancel this function, press P.BASS again, “OFF” is displayed for a few seconds. Downloaded From DvDPlayer-Manual.com Samsung Manuals... -
Page 30: Sleep Timer Function / Mute Function
When you turn off the main unit, DEMO function will be • To turn off mute, press the button again. auto start after 10 senconds. if you want to cancel this DEMO function, press DEMO/DIMMER button again. Downloaded From DvDPlayer-Manual.com Samsung Manuals... -
Page 31: Connecting Headphones/Microphone/Key Control
. • The function can only be used with CDs(except DTS CD). • The Key control function can only be used when a MIC is connected. Downloaded From DvDPlayer-Manual.com Samsung Manuals... -
Page 32: Before Calling For Service
Refer to the chart below when this unit does not function properly. If the problem you are experiencing is not listed below or if the instruction below does not help, turn off the unit, disconnect the power cord, and contact the nearest authorized dealer or Samsung Electronics Service Center. Symptom... -
Page 33: Notes On Discs
(Example : QPEL, GMC, resolution higher than 800 x 600 pixels, etc.) • Sections with a high frame rate might not be played while playing a DivX file. • For more information about the formats authorized by DivX Networks, Inc., please visit "www.divxnetworks.net". Downloaded From DvDPlayer-Manual.com Samsung Manuals... -
Page 34: Specifications
Imation USB 2.0 64M Front Speaker(4 Ω) SONY Micro Vault Sony USB 2.0 64MB XTICK(M) USB 2.0 64M 50W/CH RMS,IEC (total harmonic distortion: 10 %)(MAX-DA54) FLEX DRIVE Serotech USB 2.0 32MB RiDATA EZDrive USB 2.0 64M Front Speaker(4 Ω) 90W/CH RMS,IEC (total harmonic distortion: 10 %)(MAX-DA55) AnyDrive A.L tech... - Page 35 Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre. Region Country Customer Care Center Web Site CANADA 1-800-SAMSUNG(726-7864) www.samsung.com/ca North America MEXICO 01-800-SAMSUNG(726-7864) www.samsung.com U.S.A 1-800-SAMSUNG(726-7864) www.samsung.com...
