  • Page 1 HT6050 Digital Projector Home Cinema Series User Manual...

  • Page 2: Table Of Contents

    Table of contents Important safety System Setup : Advanced menu ..48 Information menu ........50 instructions ....3 Shutting down the projector ....51 Projector features..7 OSD menu structure......52 Shipping contents ........8 Maintenance ....55 Projector exterior view......9 Care of the projector......

  • Page 3: Important Safety Instructions

    Important safety instructions Your projector is designed and tested to meet the latest standards for safety of information technology equipment. However, to ensure safe use of this product, it is important that you follow the instructions mentioned in this manual and marked on the product. Safety Instructions Please read this manual before Always open the lens shutter or...
  • Page 4 Safety Instructions (Continued) Do not block the projection lens with Never replace the lamp assembly or any objects when the projector is any electronic components unless the under operation as this could cause projector is unplugged. the objects to become heated and deformed or even cause a fire.
  • Page 5 Safety Instructions (Continued) When the projector is under Do not block the ventilation holes. operation, you may sense some - Do not place this projector on a blanket, bedding or any other soft surface. heated air and odor from its - Do not cover this projector with a cloth ventilation grill.
  • Page 6 BenQ to have the wrong gauge or length screws. projector serviced. You can purchase a BenQ projector ceiling mount kit from the place you purchased your BenQ projector.

  • Page 7: Projector Features

    Projector features • Full HD compatible The projector is compatible with Standard Definition TV (SDTV) 480i, 576i, Enhanced Definition television (EDTV) 480p, 576p and High Definition TV (HDTV) 720p, 1080i/p 60Hz formats, with the 1080p format providing a true 1:1 image reproduction. •...

  • Page 8: Shipping Contents

    Shipping contents Carefully unpack and verify that you have all of the items shown below. If any of these items are missing, please contact your place of purchase. Standard accessories The supplied accessories will be suitable for your region, and may differ from those illustrated. *The warranty card is only supplied in some specific regions.

  • Page 9: Projector Exterior View

    Projector exterior view External control panel Front/upper side (See "Projector" on page 11 details.) Vent (cool air intake) Anti-dust cap Power button 3D SYNC OUT HDMI-1 input jack HDMI 2 / MHL dual mode port Also can be charging connected MHL compatible smart device as long as the projector is powered on.

  • Page 10: Bottom Side

    Front adjuster foots Ceiling mount holes Bottom side Projector features...

  • Page 11: Controls And Functions

    Controls and functions Projector 11 12 Selects an available picture setup mode. Confirm the selected On-Screen Display (OSD) menu item. See "Using the menus" on page 34 for details. ► Right When the On-Screen Display (OSD) menu is activated, the #2, #4, #5, and #8 keys are used as directional arrows to select the desired menu items and to make adjustments.

  • Page 12: Remote Control

    Remote control Arrow keys (▲ Up, ▼ Down, ◄ Left, ► Right) When the On-Screen Display (OSD) menu is activated, these keys are used as directional arrows to select the desired menu items and to make adjustments. When the OSD menu is off and you are under the MHL connection mode, these arrows keys are available for controlling your smart device.
  • Page 13 13. LIGHT Fast-forward The LED backlight lights up and stays on Fast-forwards during media playback. for approximately 30 seconds when Only available when controlling your pressing any key on the remote control. smart device in MHL mode and when Pressing any other keys within the 10 projector CEC is on.

  • Page 14: Remote Control Effective Range

    Remote control effective range Infra-Red (IR) remote control sensor is located on the front and the rear of the projector. The remote control must be held at an angle within 30 degrees perpendicular to the projector's IR remote control sensor to function correctly. The distance between the remote control and the sensor should not exceed 8 meters (~ 26 feet).

  • Page 15: Replacing The Remote Control Battery

    Replacing the remote control battery Remove the battery compartment cover by sliding the cover in the direction of the arrow. Insert the supplied batteries taking note of the polarity (+/-) as shown here. Replace the cover. • Avoid excessive heat and humidity. •...

  • Page 16: Positioning Your Projector

    Turn on the projector and make the following settings: MENU > System Setup : Basic > Projector Position > Front Ceiling Purchase the BenQ Projector Ceiling Mount Kit from your dealer to mount your projector on the ceiling. Rear Ceiling Select this location with the projector suspended from the ceiling behind the screen.

  • Page 17: Installing Or Removing The Optional Lens

    Installing or removing the optional lens • Do not shake or place excessive pressure on the projector or the lens components as the projector and lens components contain precision parts. • Before removing or installing the lens, be sure to turn off the projector, wait until the cooling fans stop, and turn off the main power switch.

  • Page 18: Adjusting Projected Image Position Using Lens Shift

    Installing the new lens Remove both end caps from the lens. Removal of the plastic body cap before inserting a lens for the first time. Align the flange and correctly 30° position at the 11 o'clock Flange position as shown in the picture.

  • Page 19: Adjusting The Vertical Image Position

    Adjusting the vertical image position The vertical image height can be adjusted between 60% and -20% for 1080P of offset position. Please consult the Lens Shift Range diagram below for further clarification. Adjusting the horizontal image position With the lens in the center position the horizontal image position can be adjusted to the left or right by up to a maximum of 5% of the image width.

  • Page 20: Obtaining A Preferred Projected Image Size

    Obtaining a preferred projected image size The projected image size is determined by the distance from the projector lens to the screen, the zoom setting, and the video format. Projection dimensions Refer to "Dimensions" on page 65 for the center of lens dimensions of this projector before calculating the appropriate position.
  • Page 21 11.07 6.23 There is 5% tolerance among these numbers due to optical component variations. BenQ recommends that if you intend to permanently install the projector, you should physically test the projection size and distance using the actual projector before you permanently install it, so as to make allowance for this projector's optical characteristics.

  • Page 22: Connection

    Connection When connecting a signal source to the projector, be sure to: Turn all equipment off before making any connections. Use the correct signal cables for each source. Ensure the cables are firmly inserted. • In the connections shown below, some cables may not be included with the projector (see "Shipping contents"...

  • Page 23: Hdmi Connection

    HDMI connection HDMI (High-Definition Multimedia Interface) supports uncompressed video data transmission between compatible devices like DTV tuners, DVD players, Blu-ray players and displays over a single cable. You should use an HDMI cable when making a connection between the projector and HDMI devices. A/V device HDMI cable Connection...

  • Page 24: Smart Devices Connection

    Smart devices connection The projector can project the content directly from a MHL compatible smart device. Using an HDMI to Micro USB cable or an HDMI to Micro USB adaptor, you can connect your smart devices to the projector and then enjoy your content on the big screen. Some smart devices may not be compatible to the cable that you use.
  • Page 25 Using an HDMI to Micro USB adaptor and an HDMI cable Connect one end of the HDMI cable to the HDMI input connector on the projector. Connect the other end of the HDMI cable to the HDMI input socket on the adaptor. Connect the other end of the adaptor to the Micro USB output socket on your smart device.

  • Page 26: Component Video Connection

    Component Video connection A/V device Component Video to Component cable Connection...

  • Page 27: Video Connection

    Video connection A/V device Video cable Connection...

  • Page 28: Pc Connection

    PC connection Notebook or desktop computer VGA cable USB cable Connection...

  • Page 29: Connecting Video Source Devices

    Connecting video source devices You need only connect the projector to a video source device using just one of the connecting methods, however each provides a different level of video quality. The method you choose will most likely depend upon the availability of matching terminals on both the projector and the video source device as described below: Terminal Terminal...

  • Page 30: Operation

    Operation Starting up the projector Plug the power cord into the projector and into a wall socket. Turn on the wall socket switch (where fitted). Check that the POWER indicator light on the projector lights orange after power has been applied. Please use the original accessories (e.g.
  • Page 31 iii. Specify Vertical Keystone. Press BACK for 2 seconds to reset keystone value iv. Specify Auto Source. Now you’ve completed the initial setup. If you are prompted for a password, press the arrow keys to enter a six digit password. See "Utilizing the password function"...

  • Page 32: Adjusting The Projected Image

    Adjusting the projected image Adjusting the projection angle The projector is equipped with two front adjuster foot. These adjusters change the image height and projection angle. To adjust the projector: Screw the front adjuster foot. Once the image is positioned where you want it. Screw the adjuster foot to fine tune the horizontal angle.

  • Page 33: Correcting Keystone

    Fine-tuning the image size and clarity Adjust the projected image to the size that you need using the ZOOM ring. Then sharpen the image by rotating the FOCUS ring. Correcting keystone Keystoning refers to the situation where the projected image is noticeably wider at either the top or bottom.

  • Page 34: Using The Menus

    Using the menus The OSD menu offers complete menu functions. Main menu icon Main menu Status Sub-menu Press BACK to Current input the previous signal page or to exit. The OSD menu overview above is for reference only and may differ from the actual design and the projector model you are using.

  • Page 35: Securing The Projector

    Securing the projector Using a security cable lock The projector has to be installed in a safe place to prevent theft. Otherwise, purchase a lock, such as a Kensington lock, to secure the projector. You can locate a Kensington lock slot on the left side of the projector.

  • Page 36: If You Forget The Password

    Write down the number and turn off your projector. Seek help from the local BenQ service center to decode the number. You may be required to provide proof of purchase documentation to verify that you are an authorized user of the projector.

  • Page 37: Changing The Password

    Changing the password Open the OSD menu and go to the System Setup: Advanced > Password > Change password menu. Press OK. The message 'INPUT CURRENT PASSWORD' displays. Enter the old password. • If the password is correct, another message 'INPUT NEW PASSWORD' displays.

  • Page 38: Switching Input Signal

    Switching input signal The projector can be connected to multiple devices at the same time. However, it can only display one full screen at a time. If you want the projector to always automatically search for the signals: • Under the OSD menu, go to the System Setup : Basic menu, and enable Auto Source.

  • Page 39: Picture Menu

    Picture menu Submenu Functions and Descriptions Selects a preset picture mode to suit your operating environment and input signal picture type. The preset picture modes are described as below: • Bright: Maximizes the brightness of the projected image. This mode is suitable for environments where extra-high brightness is required, such as using the projector in well lit rooms.
  • Page 40 Submenu Functions and Descriptions Adjusts the brightness of the picture. When adjusting this control, the black areas of the picture appear just as black and details in the dark areas are visible. The higher the value, the brighter the picture, while the lower the value, the Brightness darker the picture.

  • Page 41: Color Temperature

    Gamma Selection Gamma refers to the relationship between input source and picture brightness. • 1.6/1.8/2.0/BenQ: Select these values according to your preference. • 2.1/2.2: Increases the average brightness of the picture. Best for a lit environment, meeting room or family room.

  • Page 42: Color Management

    Submenu Functions and Descriptions • Color Management In most installation situations, color management will not be necessary, such as in classroom, meeting room, or lounge room situations where lights remain on, or where building external windows allow daylight into the room. Only in permanent installations with controlled lighting levels such as boardrooms, lecture theaters, or home theaters, should color management be considered.

  • Page 43: Dynamic Iris

    Submenu Functions and Descriptions • CinemaMaster • Color Enhancer: Enhances the color saturation to provide more splendid image quality. The higher the setting, the more vivid the image reveals. The lower the setting, the softer the image reveals. • Flesh Tone: This adjustable item to enable the picture’s vividness to be significantly increased.
  • Page 44 Submenu Functions and Descriptions Selects the projector lamp power from the following modes. • Normal: Provides full lamp brightness. • Economic: Reduces system noise and power consumption by 30%. • SmartEco: Reduces system noise and lamp power consumption by up to Lamp Power 70%.

  • Page 45: Display Menu

    Display menu Submenu Functions and Descriptions The native display resolution of this projector is in a 16:9 aspect ratio. However, you may use this function to display projected picture of different aspect ratio. In the following illustrations, the black portions are inactive areas and the white portions are active areas.
  • Page 46 (with 3D game discs), 3D Blu-ray 3D players (with 3D Blu-ray discs), 3D TV (with 3D channel), and so on. After you have connected the 3D video devices to the projector, wear the BenQ 3D glasses and make sure the power is on to view 3D contents.

  • Page 47: System Setup : Basic Menu

    Allows you to select which logo screen displays during projector start-up. You can Splash Screen choose BenQ logo screen, Blue screen, or Black screen. The projector can be installed on a ceiling or behind a screen, or with one or Projector Position more mirrors.

  • Page 48: System Setup : Advanced Menu

    System Setup : Advanced menu Submenu Functions and Descriptions • Reset Lamp Timer Activates this function only after a new lamp is installed. When you select Reset, a “Reset Successfully” message displays to notify that the lamp time has been Lamp Settings reset to “0”.
  • Page 49 BenQ video display devices. Accordingly, we recommend that setup and calibration be performed by an ISF certified installation technician.

  • Page 50: Information Menu

    Information menu Submenu Functions and Descriptions Source Displays the current signal source. Picture Mode Displays the current picture mode under the Picture menu. Resolution Displays the native resolution of the input source. Color System Displays input system format. Lamp Usage Time Displays the number of hours the lamp has been used.

  • Page 51: Shutting Down The Projector

    Shutting down the projector To turn the projector off, press on the remote control to turn projector off directly. Or you can press POWER on the projector and a warning message appears. Press POWER again. Once the cooling process finishes, the POWER indicator light is a steady orange and fans stop.

  • Page 52: Osd Menu Structure

    Game/User 1/User 2/ISF Night/ ISF Day Rename User Mode Brightness Contrast Color Tint Picture Sharpness 1.6/1.8/2.0/2.1/2.2/2.3/2.4/2.5 /2.6/ Gamma Selection 2.8/BenQ Preset/Red Gain/Green Gain/Blue Color Temperature Gain/Red Offset/Green Offset/ Blue Offset Primary Color/Hue/Gain/ Color Management Saturation Advanced Color Enhancer/Flesh Tone/Pixel Cinema Master...

  • Page 53: Main Menu

    3D Mode Frame Packing/Top-Bottom/ Side-by-Side/2D 3D Conversion 3D Depth Adjust 3D Sync Invert Language Background Color Black/Blue/Purple Splash Screen BenQ/Black/Blue Front/Front Ceiling/Rear/Rear System Projector Position Ceiling Setup: Basic Disable/5 min/10 min/15 min/ Auto Off 20 min/25 min/30 min Direct Power On...

  • Page 54: System Setup

    Main menu Sub-menu Options Lamp Settings Reset Lamp Timer Reset/Cancel Lamp Usage Time/ Equivalent Lamp Lamp Timer Hour Auto/Full Range/Limited Range HDMI Range Full Range: 0 ~255 level Limited Range: 16~235 level On/Off HDMI Settings Off/Bidirectional/ Power On Link Projector->Device/ Device ->...

  • Page 55: Maintenance

    Maintenance Care of the projector Your projector needs little maintenance. The only thing you need to do on a regular basis is to keep the lens clean. Never remove any parts of the projector except the lamp. Contact your dealer if other parts need replacing.

  • Page 56: Lamp Information

    Transporting the projector It is recommended that you ship the projector with its original packing or equivalent. Lamp information Getting to know the lamp hour When the projector is in operation, the duration (in hours) of lamp usage is automatically calculated by the built-in timer.

  • Page 57: Timing Of Replacing The Lamp

    An old lamp may cause a malfunction in the projector and in some instances the lamp may explode. Go to http://www.benq.com for a replacement lamp. The Lamp indicator light and Temperature warning light will light up if the lamp becomes too hot.

  • Page 58: Replacing The Lamp

    • To assure optimal performance from the projector, it is recommended that you purchase a BenQ projector lamp for lamp replacement. • Ensure good ventilation when handling broken lamps. We recommend that you use respirators, safety glasses, goggles or face shield and wear protective clothing such as gloves.
  • Page 59 Slowly pull the lamp out of the projector. • Pulling it too quickly may cause the lamp to break and scatter broken glass in the projector. • Do not place the lamp in locations where water might splash on it, children can reach it, or near flammable materials.

  • Page 60: Cleaning The Filter

    Resetting the lamp timer After the startup logo displays, resetting the lamp timer via the OSD menu. • Under the OSD menu, go to System Setup : Advanced > Reset Lamp Timer, and select Reset. Do not reset if the lamp is not new or replaced as this could cause damage. A "Reset Successfully”...
  • Page 61 Replace a new filter module or replace filter into cover. Replace the filter cover back to the projector by pushing gently in the direction shown. • Do not wash the filter with the water or other liquid matter. • When the lamp is replaced, the filter should also be replaced, not cleaned. Maintenance...
  • Page 62 Indicators Light Power Temp Lamp Status & Description Power events Orange Stand-by mode Green Powering up Flashing Green Normal operation Orange Projector is cooling. Flashing Lamp events The lamp ignition is not lit up. Flashing 1. The projector needs 90 seconds to cool down. Or 2.

  • Page 63: Troubleshooting

    Troubleshooting Problem Cause Remedy Plug the power cord into the AC inlet on the projector, and plug the power There is no power from the power cord into the power outlet. If the power cable. outlet has a switch, make sure that it is The projector does switched on.

  • Page 64: Specifications

    Specifications Projector specifications All specifications are subject to change without notice. Optical Control Resolution 1080P Type-B x1 Display system RS-232 serial control Single-chip DLP™ system 9 pin x 1 Lens F/Number IR receiver x 2 STANDARD LS2SD 12V TRIGGER F=2.46 to 2.56, f=22.8 to 28.5mm 12VDC (Max.

  • Page 65: Dimensions

    Dimensions 431.0 mm (W) x 167.0 mm (H) x 320.5 mm (D) 431.0 Unit: mm 431.0 334.5 320.5 316.9 156.0 167.0 174.5 64.0 83.0 Ceiling Mount Installation 73.5 *Ceiling Mount Screws: M4 (Max. L=12, Min. L=10) 26.5 165.0 20.0 130.0 240.0 260.0 530.8...

  • Page 66: Timing Chart

    119.989 97.551 115.500 ◎ (Reduce Blanking) 1152 x 864 1152 x 864_75 75.00 67.500 108.000 1024 x 576 BenQ NB Timing 60.00 35.820 46.996 1024 x 600 BenQ NB Timing 64.995 41.467 51.419 1280 x 720 1280 x 720_60 45.000 74.250...
  • Page 67 Refresh Clock 3D Frame 3D Top Resolution Mode Frequency side- Rate (Hz) (MHz) Sequential Bottom (kHz) by-side 1280 x 960_60 60.000 60.000 ◎ ◎ 1280 x 960 1280 x 960_85 85.002 85.938 148.500 1360 x 768 1360 x 768_60 60.015 47.712 85.500 ◎...
  • Page 68 Support timing for Component - YPbPr input Horizontal Vertical Dot Clock 3D Frame Timing Resolution Frequency (KHz) Frequency (Hz) Frequency (MHz) Sequential 480i 720 x 480 15.73 59.94 13.5 ◎ 480p 720 x 480 31.47 59.94 ◎ 576i 720 x 576 15.63 13.5 576p...
  • Page 69 68.667 94.500 XGA_120 119.989 97.551 115.500 ◎ (Reduce Blanking) 1152 x 864 1152 x 864_75 75.00 67.500 108.000 BenQ 1024 x 576 60.00 35.820 46.996 Notebook Timing BenQ 1024 x 600 64.995 41.467 51.419 Notebook Timing 1280 x 720 1280 x 720_60 45.000...
  • Page 70 Refresh Clock 3D Frame 3D Top Resolution Mode Frequency side- Rate (Hz) (MHz) Sequential Bottom (kHz) by-side 1360 x 768 1360 x 768_60 60.015 47.712 85.500 ◎ ◎ 1440 x 900 WXGA+_60 59.887 55.935 106.500 ◎ ◎ 1400 x SXGA+_60 59.978 65.317 121.750...
  • Page 71 Supporting timing for HDMI Video input Horizontal Vertical Clock 3D Frame 3D Top side- Timing Resolution Frequency Frequency Frame Frequency Sequential Bottom (KHz) (Hz) Packing (MHz) side 480i 720 (1440) x 480 15.73 59.94 ◎ 480p 720 x 480 31.47 59.94 ◎...

  • Page 72: Warranty And Copyright Information

    Proof of purchase date will be required with any warranty claim. In the event this product is found to be defective within the warranty period, BenQ's only obligation and your exclusive remedy shall be replacement of any defective parts (labor included). To obtain warranty service, immediately notify the dealer from which you purchased the product of any defects.
