IMPORTANT MANUAL
OWNER'S MANUAL
MODEL NUMBER:
PP11TEP30
SNOW THROWER
Always Wear Eye Protection During Operation
Do Not Throw Away
WARNING:
Read the Owner's Manual and
fol low all Warnings and Safety
In struc tions. Fail ure to do so
can result in serious injury.
406860 Rev. 2 10.27.06 BY
Printed in U.S.A.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Poulan Pro PP11TEP30
Summary of Contents for Poulan Pro PP11TEP30
- Page 1 Do Not Throw Away OWNER'S MANUAL MODEL NUMBER: WARNING: Read the Owner's Manual and PP11TEP30 fol low all Warnings and Safety In struc tions. Fail ure to do so SNOW THROWER can result in serious injury. 406860 Rev. 2 10.27.06 BY Always Wear Eye Protection During Operation Printed in U.S.A.
-
Page 2: Auger Housing / Impeller Assembly
REPAIR PARTS SNOW THROWER - MODEL PP11TEP30 (96198000700) AUGER HOUSING / IMPELLER ASSEMBLY... - Page 3 REPAIR PARTS SNOW THROWER - MODEL PP11TEP30 (96198000700) AUGER HOUSING / IMPELLER ASSEMBLY KEY PART KEY PART DESCRIPTION DESCRIPTION 191079 Pulley, Impeller 405972X479 Auger Assembly, LH 188909 Bearing Assembly, Flange 407768 O-Ring 198541 Nut, Hex Flange 5/16-18 407769 Bushing, Flange 3/4...
-
Page 4: Control Panel / Discharge Chute
REPAIR PARTS SNOW THROWER - MODEL PP11TEP30 (96198000700) CONTROL PANEL / DISCHARGE CHUTE... - Page 5 REPAIR PARTS SNOW THROWER - MODEL PP11TEP30 (96198000700) CONTROL PANEL / DISCHARGE CHUTE KEY PART DESCRIPTION 183334 Knob, Lever 17501010 Screw #10-24 x 5/8 198475 Control Assembly, Defl ector 73800600 Nut, Lock 3/8-16 19131316 Washer, Flat 3/8 198473 Control Assembly, Chute Rotater...
- Page 6 REPAIR PARTS SNOW THROWER - MODEL PP11TEP30 (96198000700) HANDLES...
- Page 7 REPAIR PARTS SNOW THROWER - MODEL PP11TEP30 (96198000700) HANDLES KEY PART DESCRIPTION 405783X479 Lever, Auger Control, RH 405999X479 Lever, Traction Drive Control, LH 178888 Bushing, Flange 169675 Retainer, Hairpin 17060408 Screw, Hex Head 1/4-20 x 3/4 178652 Rod, Interlock 196333X008...
- Page 8 REPAIR PARTS SNOW THROWER - MODEL PP11TEP30 (96198000700) DRIVE 9 10...
- Page 9 REPAIR PARTS SNOW THROWER - MODEL PP11TEP30 (96198000700) DRIVE KEY PART DESCRIPTION 751153 Nut, Lock 5/16-18 198584 Screw, Hex Head 5/16-18 x 1/2 180017 Bearing, Flange 180134 Shaft, Auxiliary 179270 Spacer, Plate 192616X479 Plate, Auxiliary 180082 Gear, Intermediate (12/58) 180065...
-
Page 10: Chassis / Engine / Pulleys
REPAIR PARTS SNOW THROWER - MODEL PP11TEP30 (96198000700) CHASSIS / ENGINE / PULLEYS 10 21... - Page 11 REPAIR PARTS SNOW THROWER - MODEL PP11TEP30 (96198000700) CHASSIS / ENGINE / PULLEYS KEY PART KEY PART DESCRIPTION DESCRIPTION 181044 Spring, Traction Idler 851084 Screw, Hex Head 3/8-24 x 1-3/8 180522 Pulley, Idler (2-1/4) 155452 Guide, Belt - - -...
- Page 12 REPAIR PARTS SNOW THROWER - MODEL PP11TEP30 (96198000700) WHEELS / DECALS 15 12...
- Page 13 REPAIR PARTS SNOW THROWER - MODEL PP11TEP30 (96198000700) WHEELS / DECALS KEY PART DESCRIPTION 192092X421 Wheel Assembly, 16", Power Steering, LH 155443 Pin, Klik 1/4 405161 Cover, Power Steering 184471 Screw, Hex Head #10-24 x 1/2 17000616 Capscrew, Hex Head, Flanged 3/8-16 x 1...
-
Page 14: Limited Warranty
6. In the event you have a claim under this Warranty, you must return the product to an authorized service dealer. Should you have any unanswered questions concerning this Warranty, please contact: In Canada contact: Poulan Pro Poulan Pro, Customer Service Department Customer Service Department 5855 Terry Fox Way 1030 Stevens Creek Road...
