- Page 1 Voice OTP Development System – User Guide aP89W24USB VOICE OTP DEVELOPMENT SYSTEM USER GUIDE July 31, 2008 Aplus Integrated Circuits, Inc. www.aplusinc.com.tw sales@aplusinc.com.tw Page 1 of 11 12/15/2009...
- Page 2 Voice OTP Development System – User Guide Introduction aP89W24USB Voice OTP Development System is designed to support Aplus’ aP89 series Voice OTP chips. It supports the following devices: aP89042 (42 sec OTP chip) aP89021 (21 sec OTP chip) aP89010 (10 sec OTP chip)
-
Page 3: Installation
Voice OTP Development System – User Guide Installation Hardware Installation The aP89W24USB is a USB based writer program. It is intended to be used in Windows XP based computer. Writer Board Connection 1) Connect USB cable from the writer board to the computer. The computer will show a new hardware is found. - Page 4 You will only see a flash of a black colored window to disappear. That means the drivers installation is completed. Double click the file aP89W24USB.EXE to launch the software. Click the About tab and you will see two empty boxes near the bottom of the window. Enter the registration number provided and click the Enter button on the left to finish the registration.
- Page 5 Voice OTP Development System – User Guide Compiler When the aP89 Voice OTP Development System is launched, the Compiler Window is displayed. The Compiler Window consists of the following areas: Directory Folder area: display the current directory path File Display area: display a list of voice files in the current directory...
- Page 6 Voice OTP Development System – User Guide Step 1 – Select Device click the “down arrow" to show device names and select the device you want to work on. Step 2 – Adding Voice Files set the coding format, “ADPCM” or “PCM”, for the input voice file click the “down arrow”...
- Page 7 Voice OTP Development System – User Guide Step 4 – Selecting the Individual Voice Group Options Each Voice Group can have its only triggering and output setting options. double click the empty space in the Group Option Selection area, a details list...
- Page 8 Voice OTP Development System – User Guide The Load DPM file button This function allows the DPM file generated from last step to be loaded into the compiler again so that user can change the options setting. Both the trigger options and the output options can be changed.
- Page 9 Voice OTP Development System – User Guide Writing OTP device After finishing DPM file generation, you can program the OTP device. Click the “Write” tab to enter the OTP programming section. There are the following functions: Load File: load the DPM file from Hard Disk After loading DPM file, the Voice Groups and selected options are displayed.
- Page 10 Voice OTP Development System – User Guide Inserting Devices onto the Programmer Hardware aP89341, 170 and 085 (24-Pin DIP package) 24-Pin DIP aP89042, 42A (20-Pin DIP package) Device should be inserted align to the bottom of the textool socket.
- Page 11 Voice OTP Development System – User Guide aP89021, 010, 21A and 10A (16-Pin DIP package) Device should be inserted to align to bottom of the textool socket. SOP Package Additional SOP adapter should be used and align to bottom of the textool socket.
