CO2 reactor >>reactor 1000<<
______________________________________________________________________
The CO2-reactor 1000 has been developed for the fertilisation of freshwater and marine
aquaria Carbondioxide.
The unit has been especially designed for external use, outside of the aquarium.
Read and follow asll instructions in this leaflet carefully . The CO2-reactor will thank this
with a safe function and a trouble-free long life.
1. parts of the reactor
2
fig1: reactor 1000
1. reactor – housing, filled with Bactoballs
3. CO2 – inlet
4. false gas outlet
5. holding clamps ( 2 pcs)
6. holder for fixing at the aquarium
9
7. holding plate
8. Water outlet
4
9. 0-ring at the water inlet and outlet.
3
6
5
7
1
8
Advertisement
Table of Contents
Related Manuals for Aqua Medic reactor 1000
Summary of Contents for Aqua Medic reactor 1000
- Page 1 CO2 reactor >>reactor 1000<< ______________________________________________________________________ The CO2-reactor 1000 has been developed for the fertilisation of freshwater and marine aquaria Carbondioxide. The unit has been especially designed for external use, outside of the aquarium. Read and follow asll instructions in this leaflet carefully . The CO2-reactor will thank this with a safe function and a trouble-free long life.
- Page 2 - Mounting outside of the aquarium The reactor 1000 may be mounted at a wall or inside the aquarium cabinet. For this, the holder (6) is removed and the holding plate (7) is directly screwed to the wall or the cabinet.
- Page 3 Please always observe the pH-value and amend the quantity of the bubbles according to demand. Advice: we recommend the bubble counter >>counter No. 71211<< with integrated non return valve of our CO2 programme. 7.25 High Prog H igh O ut pH Computer figu. 2: reactor 1000 on aquarium with automatic CO2 control...
- Page 4 12. outlet of water to the aquarium counter Figure 2 shows the reactor 1000 in exterior fixing together with a complete CO2 supply and steering by Aqua Medic. The water is leaded into the reactor coming from the exterior filter (not shown). The pH-Computer measures the pH-value in the aquarium and switches on the CO2 supply via the solenoid valve according to demand.
- Page 5 the carbonate hardness builder can break down ( so-called biogenetic decalcification). This should be absolutely avoided. The CO2 system compensates for this loss. It is very important only to replace the CO2 and not to supply the aquarium with more CO2 because one thinks that „very much helps very much“.
