Related Manuals for VBOX XTi
Summary of Contents for VBOX XTi
- Page 1 VBox VHome XTi - TV Gateway How To Guide: Network Recording Configuration Product Version: 2.40 Release Date: May 2014 Document Revision: 1.0...
-
Page 2: Table Of Contents
Contents Contents Introduction ............................. iii Storage Options ..........................iii Requirements ........................... iii Setting-up Your Storage ..........................iv Microsoft Windows Shared folder ..................... iv 2.1.1 Setting up the recording folder....................iv Network Storage (NAS) Shared folder ....................v Setting-up V@Home TV Gateway Storage Preferences ................vi Setting up network storage ....................... -
Page 3: Introduction
1 Introduction The V@Home TV Gateway records Live TV to an external storage, with options of a removable USB storage or supported network storage. By default the V@Home TV Gateway is configured to record on a removable USB storage. Follow these steps to configure the storage option: 1.1 Storage Options 1. -
Page 4: Setting-Up Your Storage
2 Setting-up Your Storage 2.1 Microsoft Windows Shared folder You can record Live TV directly to a PC in your network; The V@Home TV Gateway will stream the recording from the PC to all supported devices in your network 1. Make sure that the PC you are assigning will be running and connected to the network during recording 2. -
Page 5: Network Storage (Nas) Shared Folder
! IMPORTANT – if your PC does not require a password for login please follow the below steps 1. Open “Control Panel” and choose “Network and Internet” 2. Choose “Network and Sharing Center” and press “Change advanced sharing settings” 3. Make sure that “Password-protected sharing” is turned off 2.2 Network Storage (NAS) Shared folder 1. -
Page 6: Setting-Up V@Home Tv Gateway Storage Preferences
3 Setting-up V@Home TV Gateway Storage Preferences 1. Open the V@Home TV Gateway Settings Web page 2. Go to “Manage” 3. On the left side menu choose “Streaming” and then “Manage Recordings” 4. Choose the preferred recording media a. USB – Attach a USB Storage device directly to the V@Home TV Gateway USB port found on the back of the device b. - Page 7 3. Press “Proceed anyway” on the site’s security certificate warning 4. Choose the domain or workgroup where your PC or NAS is located How To Guide – Network Recording Configuration version 1.0...
- Page 8 5. Locate the PC or NAS in the “Server” list 6. The VBox TV Gateway will attempt to access the PC or NAS How To Guide – Network Recording Configuration version 1.0 viii...
- Page 9 7. If you require a user name and password to login to the PC or NAS, you will be prompt to provide both user name and password 8. Select the folder you have prepared in advance How To Guide – Network Recording Configuration version 1.0...
- Page 10 9. Press “Set” to select the target folder 10. A confirmation message will appear confirming that the recording path was successfully set How To Guide – Network Recording Configuration version 1.0...
- Page 11 11. Your new network path will appear under “Network” you can change the network path at any time by pressing the Edit button How To Guide – Network Recording Configuration version 1.0...
