12288 Brawn Road, Wainfleet, Ontario, Canada L0S 1V0
Phone 905-899-3473
Installation / Operating Instructions for
LIQUID PROPANE OR NATURAL GAS
Technical Data straight and U shape radiant tube heaters.
The installation must comply with local codes and CAN / CGA B – 149 in Canada
WARNING: Improper installation,
adjustment, alteration, service or
maintenance can cause property damage,
injury or death. Read the installation,
operating and maintenance instructions
thoroughly before installing or servicing
this equipment.
e-mail erw@vaxxine.com
Easy Radiant "Works"
EZ-DUZZIT
Infrared Radiant Tube Heater
MODEL NUMBERS
ED-40U
40,000 BTU
5003356
CGA/CSA STD 2.17
or the National Fuel Gas codes
un réglage, une modification, une réparation
ou un entretien incorrect peut entraîner des
dommages matériels, des blessures ou la
mort. Li sez attentivement les instructions
d'installation, de fonctionnement et
d'entretien avant de procéder à l'installation
ou àl'entretien de cet équipement.
Fax 905-899-2262
ED-40S
ETL LISTED
CONFORMS TO
ANSI STD Z83.20
CERTIFIED TO
CSA STD 2.34
AVERTISSEMENT. Une installation,

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ED-40U and is the answer not in the manual?

Questions and answers

Summary of Contents for Easy Radiant Works ED-40U

  • Page 1 Fax 905-899-2262 Installation / Operating Instructions for Easy Radiant “Works” EZ-DUZZIT Infrared Radiant Tube Heater MODEL NUMBERS ED-40U ED-40S 40,000 BTU LIQUID PROPANE OR NATURAL GAS Technical Data straight and U shape radiant tube heaters. ETL LISTED CONFORMS TO ANSI STD Z83.20...
  • Page 2 Consignes De Securite AFETY MELL ENTEZ DEUR 1. Open windows 1. Ouvrez les fenetres 2. Do not touch electrical switches, or telephone 2. Ne touchez pas aux interrupteurs electriques 3. Extinguish any open flame 3. Eteignez toute flamme nue 4. Immediately call your fuel supplier 4.
  • Page 3 CLEARANCES TO COMBUSTIBLES The clearance to combustible materials represents the minimum distance that must be maintained between the heater and a nearby surface. The stated clearance to combustibles represents a surface temperature of 90 degree Fahrenheit (32 degrees Celsius) above room temperature. Building material with a low heat tolerance may be subject to degradation of lower temperatures.
  • Page 4 Thank you for purchasing the “EZ DUZZIT” residential garage heater. You have purchased either an “S” straight model or “U” U-shaped model. Follow the appropriate installation instructions for the model you are installing. “EZ DUZZIT” residential garage heaters are self-contained heating appliances that require gas supply &...
  • Page 5: Gas Connection

    INSTALLATION INSTRUCTIONS FOR U-SHAPED “U” MODELS “U” shaped models consist of burner, U-shaped 3-1/2” dia. radiant tube heat exchanger, 2 hanging brackets and reflectors. For access to controls, remove screw in center of doors and swing open. “U” models must be suspended with the chain provided and suspended at each of the four suspension points.
  • Page 6 VENTING All venting must be in accordance with all applicable codes 1. The maximum allowable length of vent pipe is 30 ft. (9.14 meters). This length includes the combination of inlet air vent for combustion and exhaust venting. THE RADIANT TUBE IS NOT INCLUDED IN THIS MEASUREMENT.
  • Page 7: Combustion Air Venting

    8. Vents for products of combustion shall not terminate less than 3 ft (.9 meters) from a combustion air inlet of any other appliance, or be less than 3 ft (.9 meters) from a building opening or be directly above a gas utility meter or service regulator. 9.
  • Page 8 TECHNICIAN ONLY. READ AND UNDERSTAND THESE INSTRUCTIONS THOROUGHLY BEFORE ATTEMPTING TO INSTALL, OPERATE OR SERVICE THE EASY RADIANT WORKS HEATER. FAILURE TO COMPLY WITH THESE WARNINGS AND INSTRUCTIONS, AND THOSE ON THE HEATER COULD RESULT IN PERSONAL INJURY, DEATH, FIRE, ASPHYXIATION, AND / OR PROPERTY DAMAGE.
  • Page 9: Heater Expansion

    Do not use in an atmosphere containing halogenated hydrocarbons or other corrosive chemicals. Some compounds in the environment can cause an accelerated rate of corrosion to the heat exchanger. The heater manufacturer cannot anticipate all types and chemical composition of possible contaminants at project sites.
  • Page 10: Clearances To Combustibles

    WARNING START-UP SMOKE CONDITION During start up, the heating of material coatings used in the production process of tubes and reflectors will create smoke during the initial period of operation. This condition is normal and temporary. Ensure that there is sufficient ventilation to adequately clear any smoke from the space.
  • Page 11: Installations Other Than Space Heating

    INSTALLATION IN COMMERCIAL AIRCRAFT HANGARS Low intensity radiant tube heaters are suitable for use in aircraft hangars when installed in accordance with the latest edition of the Standard for Aircraft hangars, ANSI/NFPA No. 409 in the USA, or the Canadian Natural Gas and Propane Installation Code, B149.1 A minimum clearance of 10 ft (3m) above either the highest fuel storage compartment or the highest engine enclosure of the highest aircraft, which may occupy the hangar.
  • Page 12 GENERAL INSTALLATION PROCEDURE PRE-INSTALLATION SURVEY It is recommended that a full heating design, including a heat loss calculation be conducted. Heater sizing and placement must consider available mounting height, sources of heat loss, and clearances to combustibles with respect to stored material, moveable objects (cranes, vehicles, lifts, overhead doors, etc) sprinkler systems, and other obstructions on the site.
  • Page 13: Suspending The System

    SUSPENDING THE SYSTEM Inadequate or improper suspension of the tube heater can result in collapse of the system, property damage, and personal injury or death. It is the installer’s responsibility to ensure that the hardware and structural supports from which the heater is suspended are sound and of adequate strength to support the weight and expansion forces of the heater.
  • Page 14: Gas Piping

    GAS PIPING 1. All gas piping and connections shall be made in accordance with local codes and CAN/CGA B-149 or ANSI standard Z223.1. 2. Connect the burner to gas supply with flexible gas connector. 3. A drip leg must be installed in the gas line at the heater inlet connection tee followed by a pipe drop to the heater.
  • Page 15 WARNING Never use a match or other flame to test for gas leaks. Use soap and water solution to check for leaks to all connections and joints and if bubbles appear, leaks have been detected and must be corrected. Never operate the heater with leaking connections. The supply system should be checked first with heater turned off followed by another check with the heater on.
  • Page 16: Venting Options

    WARNING This heater will expand in length as it heats up. It is a normal condition that during heat-up and cool-down a tube heater will expand and contract. Allowances for heater expansion must be made in the gas connection, venting and combustion air ducting. Improper installation, alteration, or adjustment can result in property damage, injury or death.
  • Page 17 LISTED ACCESSORIES: AC1010 Ind. Thermostat 120V AC1020 Agricultural Thermostat AC1030 Remote Thermostat AC1050 Agricultural Thermostat AC1060 24V Thermostat AC1070 Flexible Gas Connector AC1080 Outside Air Adapter AC1030 Remote Thermostat AC1100 Outside Air Wall Cap AC1110 Combustion Air Flex Duct AC1120 4x4x6 Tee AC1130 90 degree Elbow...
  • Page 18 EASY RADIANT WORKS ACCESSORIES EASY RADIANT WORKS ACCESSORIES...
  • Page 19: Operating Sequence

    OPERATING SEQUENCE The Easy Radiant gas burner is a very simple device. The normal sequence of events during ignition and operation of the burner is as follows: 1. The heater is energized by means of a thermostat or switch. 2. When 24 volts is applied to the module, the module will energize the blower and close the airswitch.
  • Page 20: Troubleshooting

    TROUBLE SHOOTING Improper adjustment, alteration, service or maintenance can cause property damage, injury or death. This heater must be installed and serviced only by a trained gas service technician. If at the onset of ignition, no ignition occurs, the following should be checked. Lack of power at the input of the controls caused by: ...
  • Page 21: Recommended Maintenance

    PROMPT DISPOSITION OF WARRANTY CLAIMS Easy Radiant Works will make a good faith effort for prompt correction or other adjustment with respect to any product that proves to be defective in material or workmanship within the warranty period.
  • Page 22 START-UP/TECHNICAL SUPPORT INFORMATION This equipment has been factory fired and tested prior to shipment. To ensure that site conditions are compatible with the heater’s performance, the following start up needs to be completed by the qualified gas installer. A technician calling for technical support must provide the information from the following completed reports.
  • Page 23 IS THERE A BAFFLE INSTALLED IN THE RADIANT TUBE IF REQUIRED..WHAT IS THE LENGTH OF THE BAFFLE(S ) FEET IF INSTALLED..IS THE BAFFLE AT FLUE END OF SYSTEM THIS HEATER MUST BE ELECTRICALLY GROUNDED TECHNICAL SUPPORT: FAX 905-899-2262, VOICE 905-899-3473 EASY RADIANT WORKS...
  • Page 25 SYNETEK DH21260K LED STATUS INDICATES CHECK/REPAIR No power to system control. 1. Line voltage input connectors on module. 2. Low voltage 24V and COM connection on module. 3. System wiring harness in good condition and securely connected at both ends. 4.
  • Page 27 HONEYWELL SMARTVALVE LED STATUS INDICATES CHECK/REPAIR No power to system control. 1. Line voltage input power at L1 and L2 connectors on Terminal Board. 2. Low voltage (24V) power at 24VAC and COM terminals on Terminal Board. 3. System wiring harness in good condition and securely connected at both ends.
