GP3D Root User Manual page 5

（Figure 2.2-01）
2.2.2 Assembly of spool holder: Take out the two screws in the middle of
the right side of the GP3D Root and fix the spool holder with the screws.
Note that the rib is on the upper side.
（Figure 2.2-02）
2.2.3 Assembly of filament tube guide: take out the screw at the back of
the upper right of the GP3D Root and fix the filament tube guide with the
screw.
（Figure 2.2-03）
2.2.4 Fixation of hotbed panel: fix the hotbed panel on the build plate
with four clamps.
（Figure 2.2-04）
2.2.5 Preparation of filament rod: the filament free end must be cut to be
flat. Please keep it straight as well.
（Figure 2.2-05）
2.2.6 Hang the feed disk on the spool holder and put the filament
through the filament tube guide.
（Figure 2.2-06）
2.2.7 Pass the filament through Teflon tube. As shown below:
（Figure 2.2-07）
2.2.8 Power on: plug the output end of the power adapter into the power
interface on the GP3D Root.
（Figure 2.2-08）
