- Page 1 FN-300ULX Power Supply/Charger Installation Guide Altronix Corp. 140 58th St. Brooklyn, NY Rev. 101112...
- Page 2 NC C AC Fail 2. Set the FN-300ULX to the desired DC output voltage by setting SW1 (Fig. 1, pg. 2, Fig. 2c, pg. 3) to the appropriate position (refer to Power Supply Voltage Output Selections chart). 3. Connect AC power (115VAC 60Hz) to terminals marked [L, G, N] (Fig. 2, pg. 3). Use 14 AWG or larger for all power connections (Battery, DC output, AC input).
- Page 3 5. Measure output voltage before connecting devices. This helps avoid potential damage. 6. For Access Control applications, batteries are optional. When batteries are not used, a loss of AC will result in the loss of output voltage. When the use of stand-by batteries is desired, they must be lead acid or gel type. Connect battery to terminals marked [+ BAT –] (Fig.
- Page 4 (167mm) 0.9375” (24mm) 3.25” 3.25” (83mm) (83mm) 3.25” (83mm) 1.0” 1.0” (25mm) (25mm) 1.0” 10.5” 1.0” (25mm) (267mm) (25mm) Hochiki America Corp. 7051 Village Drive, Suite 100, Buena Park, CA 90621-2268, 714-522-2246, Fax: 714-690-7890, www.hochiki.com IIFN-300ULX G02N - 4 -...
