Summary of Contents for Maximum 054-2016-4
-
Page 3: Table Of Contents
TABLE OF CONTENTS TECHNICAL SPECIFICATIONS GENERAL POWER TOOL SAFETY WARNINGS SYMBOLS PARTS LIST ACCESSORIES KNOW YOUR DRILL OPERATING INSTRUCTIONS WORKING HINTS FOR YOUR DRILL MAINTAIN TOOLS WITH CARE WARRANTY NOTE: If any parts are missing or damaged, or if you have any questions, please call our toll-free helpline at 1-888-670-6682 SAVE THESE INSTRUCTIONS This manual contains important safety and operating... -
Page 4: Technical Specifications
054-2016-4 | contact us 1-888-670-6682 TECHNICAL SPECIFICATIONS VOLTAGE 120 V 60 Hz AC AMPS 8.5 A NO-LOAD SPEED GEAR 1 0–1300 RPM GEAR 2 0–2700 RPM IMPACT RATE GEAR 1 0–20,800 BPM GEAR 2 0–43,200 BPM KEYED CHUCK 1/2”... -
Page 5: General Power Tool Safety Warnings
WORK AREA SAFETY Keep work area clean and well lit. Cluttered or dark areas invite accidents. • Do not operate power tools in explosive atmospheres, such as in the presence • of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes. -
Page 6: Electrical Safety
054-2016-4 | contact us 1-888-670-6682 ELECTRICAL SAFETY Power tool plugs must match the outlet. Never modify the plug in any way. Do • not use any adapter plugs with grounded power tools. Unmodified plugs and matching outlets will reduce risk of electric shock. -
Page 7: Drill Safety Warnings
the rate for which it was designed. Do not use the power tool if the switch does not turn it on and off. Any power • tool that cannot be controlled with the switch is dangerous and must be repaired. Disconnect the plug from the power source and/or the battery pack from the •... -
Page 8: Symbols
054-2016-4 | contact us 1-888-670-6682 SYMBOLS To reduce the risk of injury, user must read instruction manual Double insulation Warning Wear ear protection Wear eye protection Wear dust mask Don’t use in the rain... -
Page 9: Parts List
No. Description No. Description Switch lock-on button Auxiliary handle On/off switch Depth gauge Forward and reverse Keyed chuck rotation Hammer or drill selector Speed selector Not all the accessories illustrated or described are included in standard delivery. -
Page 10: Accessories
054-2016-4 | contact us 1-888-670-6682 ACCESSORIES Chuck key Auxiliary handle Depth gauge We recommend that you purchase your accessories from the same store that sold you the tool. Use good quality accessories marked with a well-known brand name. Choose the type according to the work you intend to undertake. -
Page 11: Know Your Drill
11 12 9 10 20 21 48 49 No. Description No. Description Depth gauge Middle cover Auxiliary handle Oil shield Screw Ball bearing race Chuck Motor Self-tapping screw Dustproof ring Snap ring Ball bearing race Bearing sleeve Sheath Baffle Output spindle Self-tapping screw Bracket cover Drill/impact selector... -
Page 12: Operating Instructions
054-2016-4 | contact us 1-888-670-6682 ON/OFF SWITCH (Fig. A) Depress to start and release to stop your tool. SWITCH LOCK-ON BUTTON (Fig. A) Depress on/off switch (2) then lock-on button (1), release on/off switch first and lock-on button second. - Page 13 Fig. C ADJUSTABLE DEPTH GAUGE (Fig. D) Fit the drill bit into the chuck. Loosen the depth gauge by rotating the handle grip counter-clockwise. Slide the depth gauge until the distance between the depth gauge end and the drill/driver bit end is equal to the depth of hole you wish to make.
-
Page 14: Working Hints For Your Drill
054-2016-4 | contact us 1-888-670-6682 WORKING HINTS FOR YOUR DRILL If your power tool becomes too hot, set the speed to maximum and run no-load for 2-3 minutes to cool the motor. Tungsten carbide drill bits should always be used for concrete and masonry. -
Page 15: Maintain Tools With Care
MAINTAIN TOOLS WITH CARE Remove the plug from the socket before carrying out any adjustment, servicing or maintenance. Keep tools sharp and clean for better and safer performance. Follow instructions for lubricating and changing accessories. Inspect tool cords periodically and if damaged, have repaired by authorized service facility. -
Page 16: Warranty
(with the same model, or one of equal value or specification), at the sole discretion of the Maximum Canada authorized repair centre (“Service Provider”). We will bear the cost of any repair or replacement and any costs of labour relating thereto. - Page 17 This warranty applies for a period of 5 years from the date of original retail purchase, as indicated on the bill of sale. Neither the retailer, Maximum Canada, nor the manufacturer shall be liable for any other expense, loss or damage, including, without limitation, any indirect, incidental, consequential or exemplary damages arising in connection with the sale, use or inability to use this product.
- Page 18 In addition to the 5-Year Limited Warranty, this MAXIMUM product is covered by our: 1-YEAR REPAIR WARRANTY...
