- Page 1 HHT894 USER’S MANUAL...
-
Page 2: Table Of Contents
CONTENTS CONTENTS ....................2 PREFACE AND FEATURES ............... 3 FEATURES INCLUDE ................. 3 SAFETY ......................4 GENERAL OPERATION OF THE RECEIVER ......... 4 FRONT PANEL ..................... 5 REAR PANEL ....................5 REMOTE CONTROL UNIT KEY LAYOUT ..........6 BATTERY SAFETY PRECAUTIONS ............6 REMOTE CONTROL UNIT KEY FUNCTIONS ........ -
Page 3: Preface And Features
PREFACE AND FEATURES Thank you for choosing a healing HHT894 High Definition Receiver. HHT894 is easy to install with all AV outputs active simultaneously. Built in a small footprint case less than 220mm wide with a removable mains power lead, HHT894 includes full 7 day Electronic Program Guides. -
Page 4: Safety
Control and the front panel keys provide access to many functions. As new software may change the function of a receiver it should not be installed unless specific upgrade instructions have been given by healing for this receiver. Should you experience any difficulties with the operation of your unit, please consult the relevant section of this manual or Trouble Shooting. -
Page 5: Front Panel
FRONT PANEL 1. STANDBY key - Switches between Operational and Standby modes. 2. Numerical LED display - Shows channel selected, Load status etc. Power LED, green - Indicates power supply active. Signal Lock LED, orange - No Light = No Signal = No Pictures and Sound. 3. -
Page 6: Remote Control Unit Key Layout
REMOTE CONTROL UNIT KEY LAYOUT BATTERY SAFETY PRECAUTIONS The following Battery Safety precautions can save your RCU from damage from improper use of or poor quality batteries. 1. Double check that polarities of battery and RCU terminals correspond. 2. If storing your receiver for weeks or longer, remove the batteries from the RCU. 3. -
Page 7: Remote Control Unit Key Functions
REMOTE CONTROL UNIT KEY FUNCTIONS STANDBY. Switch between Standby and Operational. MENU. Show Main Menu. MUTE. Mute audio FAV. Shows Favorite channel list. VOL+/-. Controls Audio levels. TV/R. Switch between Television and Radio programs. ... -
Page 8: Preparing The Remote Control For Use
PREPARING THE REMOTE CONTROL FOR USE Fresh batteries must be loaded for your Remote Control Unit to operate reliably. 1. Open the battery compartment lid on the back of the RCU. 2. Insert the batteries, negative terminals first. Take care that battery polarity markings correspond with those of the Remote Control. -
Page 9: Seting Up
SETING UP Your healing HHT894 High Definition Receiver comes with a selection of Video and Audio outputs. The outputs you use will be determined by the inputs available on your TV monitor and/or HI-FI equipment. This receiver delivers excellent picture and sound quality from High Definition and Standard Definition broadcasts. - Page 10 1. BASIC SET UP- COMPOSITE VIDEO Uses the single Yellow RCA Video connector for Composite Video (CVBS) with the Red and White RCA AUDIO R & L connectors at the back of your receiver. All video outputs are active. 1. 1Prepare your equipment Ensure that the power leads to both the TV monitor and the Set Top Box are unplugged whilst making AV connections.
- Page 11 To the back of your receiver using the IEC C7 figure 8 power lead supplied. You are now ready for GETTING STARTED. 2. BASIC SET UP - COMPONENT VIDEO (Green Blue Red) For a basic component connection, use the Red Blue Green video and the Red White audio connectors on the back of the receiver.
- Page 12 Audio. c) Connect a 2 wire RCA lead to the Red and White AUDIO L&R output connectors on the rear of the set top box. d) Connect the other end of the cable to corresponding the audio input connectors on your television or monitor.
- Page 13 Video and Audio share the one HDMI cable You are now ready for GETTING STARTED.
-
Page 14: Getting Started
3. Turn on your monitor or TV. 4. Turn on your HHT894 receiver. 5. Select the appropriate Input on your monitor or television and connect. 6. The HHT894 Menu should be visible on your Monitor or TV. INITIAL AUTO SCAN Initial Auto Scan For first time set up (from Factory Default), dialogue box says “No valid program to be... -
Page 15: Scan
7. When channels required have been scanned you can press the EXIT key to escape. Program Update - Auto HHT894 detects changes to program line ups within channels, rescans and saves the changes automatically. A brief On Screen message confirms this activity when it occurs. This function virtually eliminates the need for... -
Page 16: Manual Scan
MANUAL SCAN 1. Select the channel to scan by entering its Centre Frequency in KHz. A list of this data appears on page 27 at the end of this Owner’s Manual. Scanning manually by frequency enables non standard channels to also be tuned. -
Page 17: Settings
SETTINGS Default Input Pin is 0000 AV SETTING Screen Ratio. You can set your HHT894 screen shape to match your display or TV. Select 4:3 (normal) or 16:9 (wide) by using the </> keys. 4:3 aspect ratio conventional Analog TV screens;... - Page 18 4. Use the UP/DOWN keys on the Remote Control to highlight “System Setting” and press the OK Key. 5. Use the UP/DOWN keys to select “Parental Lock”. 6. Using the </> key make a selection. 7. Press EXIT, EXIT to automatically save your change and to return to “MAIN MENU”.
-
Page 19: Edit Channels
correctly followed by your new PIN and verification. 4. Press EXIT, EXIT to return to “MAIN MENU”. Factory Reset: Factory Reset returns the receiver to its default settings. 1. From the “MAIN MENU” select the “Settings” sub menu option and press the OK key. - Page 20 to highlight channels to delete. 2. Press the “Red” key and dialogue box will ask you to confirm. 3. Press OK when “YES” is highlighted to complete channel deletion. *To recover deleted channels you must Re-Scan. Favorites - 1. Use the UP/DOWN keys to select channels you wish to make favorites.
-
Page 21: System Information
SYSTEM INFORMATION This shows the Firmware Version etc. of the receiver. OTHER FEATURES Closed Captions Closed Captions can be switched on at any time by pressing the Blue key on the Remote Control Unit. Pressing the Blue key again turns Closed Captions Off. -
Page 22: Extended Information - Now&Next
EXTENDED INFORMATION – NOW&NEXT NOW - Press the INFO key on the remote to activate the basic information plate (picture 1). For more detailed information about this program, press the OK key while the basic information plate is displayed (picture 2). -
Page 23: 7-Day Electronic Program Guide
7-DAY ELECTRONIC PROGRAM GUIDE 1. A comprehensive Electronic Program Guide (EPG) is transmitted by most broadcasters with details of Program Names, Times and Descriptions that can exceed more than 7 days in advance. (picture 1) 2. You can access the EPG by pressing the EPG key on the Remote Control Unit. -
Page 24: Audio Mode Selection
AUDIO MODE SELECTION Using the Audio Control menu: 1. Press the AUDIO key on the remote control, with your receiver in normal mode The AUDIO CONTROL menu displays. 2. Press the UP/DOWN keys to select from TRACK, and OUTPUT. MULAUDIO describes the Audio of the presently tuned channel. -
Page 25: Troubleshooting
TROUBLESHOOTING Check your receiver with the suggestions below. PROBLEM SUGGESTION No Power Check the power cord is plugged in - at both ends. No Reception Check operational antenna cable is properly connected. Receiver not responding to the Check Remote Control batteries and battery contacts. Remote Control Unit. -
Page 26: Specifications
SPECIFICATIONS Decodes High Definition and Standard Definition Digital Terrestrial TV & radio. Video Outputs HDMI, Component Y Pb Pr and Composite CVBS. Video Resolutions 1920x1080i, 1280x720p, 720x576p or 720x576i. Aspect Ratios Widescreen 16:9, Centre Cut 4:3 or Letterbox 4:3. ... -
Page 27: Channel Frequency Table
CHANNEL FREQUENCY TABLE BAND CHANNEL NUMBER REQUENCY in KHz 177500 VHF 3 184500 191500 198500 205500 212500 219500 226500 529500 UHF 4 536500 543500 550500 557500 564500 571500 578500 585500 UHF 5 592500 599500 606500 613500 620500 627500 634500 641500 648500 655500 662500... - Page 28 669500 676500 683500 690500 697500 704500 711500 718500 725500 732500 739500 746500 753500 760500 767500 774500 781500 788500 795500 802500 809500 816500...
-
Page 29: 12-Month Warranty
Subject to the conditions stated below, your new healing receiver is warranted to be free from defects in workmanship and materials for twelve months from date of purchase. For the period of warranty healing digital’s obligation includes labour and materials, but excludes neglect, accident, abuse, and transportation to and from service station. - Page 30 HHT894 USER’S MANUAL...
