Summary of Contents for Ecom SHL 100-Ex
- Page 1 SHL 100-Ex Bedienungsanleitung Operating Instructions Notice d‘utilisation Gebruiksaanwijzing Istruzioni per l‘uso Instrucciones de uso Manual de instruçoes Bruksanvisning...
-
Page 2: Purpose Of These Instructions
Application The portable lamp of line SHL 00-Ex are explosion-proof and electrical equipment and serve for illumination of shops and offices of a factory and storages in areas of zone and 2. where there is a danger of explosion. They can be used inside or outside. Purpose of these instructions When working in hazardous areas, the safety of personnel and plant depends on complying with safety regulations. -
Page 3: Conformity With Standards
89/336/EEC “Electromagnetic compatibility“ This potable lamp is approved for use in potentially explosive location (zones and 2) in accor- dance with IEC 60079-0. A) PORTABLE LAMP SHL 100-Ex 2. Technical data Ex-protection: II 2G EEx ib IIC T4 zone and 2... - Page 4 Battery: Lead-gel-accumulator, mainte-nance-free Attention: With distribution of the portable lamp the positive terminal of the battery is not connected! Operating temperature: -20 °C...+50 °C External fuse: A (explosion-proof) Dimensioned drawings (all dimensions in mm) Portable lamp SHL 00-Ex with charging adapter Portable lamp SHL 00-Ex...
- Page 5 3. Function/operating Note: Position number in () see sketches on page 25-26. Activate portable lamp Please plug positive pole onto the ac-cumulator!! For that open the housing: • Unscrew 3 Torx screws on the left and right at the case and on the bottom (5). •...
- Page 6 Only possible with charging set SHL 100-Ex! A bridge b/c (22) is set onto the printed card, which ensures that emergency lamp function –...
-
Page 7: Repair And Maintenance
The plug-in sign (3) can be engraved. These signs can be bought later, too. The sign is interchan- geable with a brass sign. 4. Charging The charging must be executed only with the ecom instruments charging set SHL 00-Ex. It is charged optimally and in due form by the I/U charging characteristic line prescribed for lead-gel accumulators. - Page 8 Attention: a) Take care of a good sealing (protec-tion provided by enclosures)! Is the sealing still okay? b) Insert absolutely an original ecom instruments-battery-pack. Other batteries are not allowed and abolish the explosion proofness! Remember environmental protection! Used batteries must be disposed of in accordance with environmental require-ments. If this is not possible we take them back and have the battery cells recycled correctly and completely, i.e.
- Page 9 5.3 External fuse For that see illustrations on page 26. . Unscrew 3 Torx screws on the left and right at the housing and on the bottom (5). 2. Draw the back panel of casing (8) from the headlamp casing. 3.
- Page 10 Plug the positive pole (+) (14) preoperational!
-
Page 11: Technical Data
B) CHARGING ADAPTER SHL 100-Ex 6. Technical data Housing material: polyamide, black Protection rating: IP 20 Protection class: Nominal voltage: 2 V/24 V DC and 230 V AC Charging current: 0,55 A I/U characteristic Charging time: approx. 2 hours LED display... - Page 12 Note: . Charging set for operation in dry rooms 2. Charging set is not suitable for the use in potentially explosive zones. 3. Charging set has to be fixed – wall installation (see dimensioned drawing)! Dimensioned drawings (all dimensions in mm)
-
Page 13: Function Operation
The temperature must be more than 0 °C when charging is executed. 9. Repair an maintenance The charging set must not be modified or changed. Only the authorized personnel are allowed to execute repairs. Please use only original spare parts of ecom instruments Company. - Page 14 9.1 Replacement of fuse Only an electric specialist or/and the manufacturer is permitted to execute that (in case of replacement of fuse there will have to be a soldering). See for those illustrations on page 30 / 3. Replacing the fuse proceed as following: .
- Page 15 Illustrations...
-
Page 16: Warranty And Liability
Please contact the ecom instruments dealership responsible for your area. 11. Warranty and liability Under the general terms and conditions of business, ecom instruments GmbH offers a two-year warranty for functioning and materials for this product when used under the specified operating and maintenance conditions. -
Page 17: Ec-Type Examination Certificate
12. EC-type examination certificate... - Page 19 Alle Rechte vorbehalten. Statement of reservation: We, ecom instruments GmbH, reserve the right to make changes. Changes, mistakes and printing errors do not justify claims for damages. Copying, publishing or reproduction of this document or extracts from it are only allowed with the written permission of ecom instruments GmbH Assamstadt.
