Table of contents / 目錄 Setup / 設定 What’s in the box / 包裝箱內容 Installation / 安裝 Connection / 連接 Turning on the system / 開啟系統 Listening to the sound / 聆聽聲音 Basic Operations / 基本操作 Enjoying the sound effects / 享受音效 Listening to the sound from BLUETOOTH devices / 從BLUETOOTH裝置聆聽聲音...
Setup / 設定 What’s in the box / 包裝箱內容 Active speaker (1) Remote control (1) 主動式揚聲器(1) 遙控器(1) R03 (size AAA) batteries (2) Optical digital cable for a TV (1) R03(AAA型)電池(2) TV的數位光纖電纜(1) Home Theatre System Startup Guide (this book) (1) Operating Instructions (1) 入門指南(本書)...
Setup / Setup / Setup Setup / 設定 Installation / 安裝 Notes / 註 • Be careful that the subwoofer does not • Place the TV stand at the center of the system so that • Do not impart an impact to the glass top contact anything. no part of it protrudes beyond the perimeter of the of the system. • 小心勿讓主動式重低音揚聲器碰觸其他物 system. • 切勿撞擊系統的玻璃頂部。 • 將TV底座置於系統中央,勿突出系統邊緣。 體。 Subwoofer / 主動式重低音 揚聲器...
Setting up the remote control / 設定遙控器 1. Face the rear of the remote control upward and slide down the cover. 將遙控器背面朝上,將蓋子往下推。 2. Pull up the battery compartment cover and insert in the orientation shown in illustration two AAA batteries. 拿起電池外蓋,依圖示方向裝入兩顆AAA 電池。...
Setup / Setup / Setup Setup / 設定 Connection / 連接 Connecting with TV / 連接TV Or / 或 If the TV to be connected is not equipped with an optical audio output 如果連接的TV沒有配備光纖音訊輸出端,請將一條HDMI電纜(未提供,高 terminal, connect an HDMI cable (not supplied, High Speed type) to the 速類型)連接標示“ARC”的HDMI輸入端。如果標示“ARC”的HDMI輸入端 HDMI input terminal labeled “ARC.” If the HDMI input terminal labeled 已連接另一部裝置,請斷開該裝置的連接,改連接本系統。 “ARC” is connected with another device, disconnect that device and connect this system.
Page 7
When connecting with TV and other devices / 連接TV與其他裝置時 TV / TV Blu-ray Disc player, etc. / Blu-ray Disc 播放器等 This is a connection for enjoying surround sound more effectively. 此連線可更有效地享受環繞聲。 HDMI cable (not supplied, High Speed type) HDMI電纜(未提供,高速類型) If the HDMI input terminal on the TV is not labeled “ARC,” perform 如果TV的HDMI輸入端未標示“ARC”,請連接 和 。 connections both HDMI電纜(未提供,高速類型) HDMI cable (not supplied, High Speed type) 如果已連接TV,請斷開TV的連接,改連接本系統。...
Setup / Setup / Setup Setup / 設定 Turning on the system / 開啟系統 Display / 顯示幕 1 Connect the AC power cord (mains lead). 1 接上交流電源線。 2 Press the (on/standby) button on the remote control or touch 2 按下遙控器上的 (開/待機)按鈕,或觸碰系統上的 the (on/standby) touch key on the system. ...
Setup / Setup / Setup Setup / 設定 Listening to the sound / 聆聽聲音 INPUT INPUT Input device selected / 已選取的輸入裝置 Listening to the audio of the TV 聆聽TV的音訊 1 Press the INPUT button on the remote control or touch the INPUT 1 按下遙控器上的INPUT按鈕,或重複觸碰系統上的INPUT觸鍵,即可選 touch key on the system repeatedly to select “TV” input. 擇“TV”輸入。 2 Press the VOL button on the remote control to adjust the volume. 2 按下遙控器上的VOL按鈕,即可調整音量。 To listen to audio from an input device other than the TV 從輸入裝置(TV除外)聆聽音訊...
Helps make Dialogue range is stressed, and the parts of dialogues clearer. TYPE3 range difficult to be discerned by the elderly are boosted. NIGHT: Activates the Night mode function. Sound is output at low volume with minimum loss of Inactivates the Night mode function. fidelity and clarity of dialogue. * DSEE stands for Digital Sound Enhancement Engine, a high range compensation and fine sound restoration technology developed independently by Sony.
AU.” 2 Set your BLUETOOTH device to pairing mode and select The illumination LED flashes during attempting BLUETOOTH “SONY:HT-XT1.” pairing. If a Passkey is requested, enter “0000.” 2 On the BLUETOOTH device, select “SONY:HT-XT1.” 3 Make sure that the illumination LED lights up. (Connection has 3 Make sure that the illumination LED lights up. (Connection has been established.) been established.) 4 Start the audio playback with the music software in the connected Hint BLUETOOTH device.
Page 14
Basic Operations / 基本操作 When using one-touch connection (NFC) / 使用One-Touch連線方式時(NFC) Illumination LED (blue) / LED燈(藍燈) 1 Download, install, and start the “NFC Easy Connect” app on your 1 在智慧型⼿機上下載、安裝和啟動“NFC快速連線”應用程式。 smartphone. 2 以智慧型⼿機觸碰本系統的N字標示。 2 Touch the N mark of this system with the smartphone. 3 確定LED燈(藍燈)亮起。(已建立連線。) 3 Make sure that the illumination LED (blue) lights up. (Connection • 相容裝置 has been established.) 智慧型⼿機、平板電腦與內建NFC功能的音樂播放器 (作業系統:Android ™2.3.3或以上版本,不含Android 3.x) • Compatible devices Smartphones, tablets, and music players with the NFC function built-in (OS: Android™ 2.3.3 or later, excluding Android 3.x)
