OWNER'S MANUAL
FJR1300AS
MOTORCYCLE
Read this manual carefully before oper-
ating this vehicle.
FJR1300-AS
B95-28199-E0

Advertisement

Table of Contents
loading

Related Manuals for Yamaha FJR1300-AS

Summary of Contents for Yamaha FJR1300-AS

  • Page 1 OWNER’S MANUAL FJR1300AS MOTORCYCLE Read this manual carefully before oper- ating this vehicle. FJR1300-AS B95-28199-E0...
  • Page 2 EAU69311 Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold. YAMAHA MOTOR ELECTRONICS CO., LTD. 1450-6, Mori, Mori-machi, Shuchi-gun, Shizuoka-ken, 437-0292 Japan DECLARATION of CONFORMITY Product: IMMOBILIZER Model: 1MC-00 Supplied by...
  • Page 3 Please take the time to read this manual thoroughly, so as to enjoy all advantages of your FJR1300-AS. The Owner’s Manual does not only instruct you in how to operate, inspect and maintain your motorcycle, but also in how to safeguard your- self and others from trouble and injury.

  • Page 4: Important Manual Information

    *Product and specifications are subject to change without notice. EAU10201 FJR1300-AS OWNER’S MANUAL ©2015 by Yamaha Motor Co., Ltd. 1st edition, October 2015 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd.

  • Page 5: Table Of Contents

    Table of contents Safety information ......1-1 For your safety – pre-operation checks ..........4-1 Description ........2-1 Left view ..........2-1 Operation and important riding Right view........2-2 points..........5-1 Controls and instruments....2-3 Starting the engine......5-2 Shifting..........5-3 Instrument and control functions..3-1 Tips for reducing fuel Immobilizer system ......3-1 consumption........
  • Page 6 Table of contents Checking and lubricating the throttle grip and cable....6-27 Checking and lubricating the brake and shift pedals....6-27 Checking and lubricating the brake lever ........ 6-28 Checking and lubricating the centerstand and sidestand ..6-28 Lubricating the rear suspension ... 6-29 Lubricating the swingarm pivots ........

  • Page 7: Safety Information

    Safety information EAU1028B an accident or equipment damage. See page 4-1 for a list of pre-operation checks. Be a Responsible Owner  This motorcycle is designed to As the vehicle’s owner, you are re- carry the operator and a passen- sponsible for the safe and proper oper- ger.
  • Page 8 Safety information  Many accidents involve inexperi- • The passenger should always enced operators. In fact, many op- hold onto the operator, the seat erators who have been involved in strap or grab bar, if equipped, accidents do not even have a cur- with both hands and keep both rent motorcycle license.
  • Page 9 Safety information Avoid Carbon Monoxide Poisoning extra care when riding a motorcycle All engine exhaust contains carbon that has added cargo or accessories. monoxide, a deadly gas. Breathing Here, along with the information about carbon monoxide can cause head- accessories below, are some general aches, dizziness, drowsiness, nausea, guidelines to follow if loading cargo to confusion, and eventually death.
  • Page 10 Genuine before using it to make sure that it Yamaha accessories, which are avail- does not in any way reduce able only from a Yamaha dealer, have ground clearance or cornering been designed, tested, and approved clearance, limit suspension travel, by Yamaha for use on your vehicle.
  • Page 11 Safety information operator and may limit control torcycle, such as the frame or up- ability, therefore, such accesso- per front fork triple clamp (and not, ries are not recommended. for example, to rubber-mounted  Use caution when adding electri- handlebars or turn signals, or cal accessories.

  • Page 12: Description

    Description EAU63371 Left view 1. Coolant reservoir (page 6-15) 2. Accessory box (page 3-39) 3. Owner’s tool kit (page 6-2) 4. Final gear oil filler bolt (page 6-14) 5. Final gear oil drain bolt (page 6-14) 6. YCC-S clutch fluid reservoir (page 6-24) 7.

  • Page 13: Right View

    Description EAU63391 Right view 1. Storage compartment (page 3-38) 2. Fuel tank cap (page 3-31) 3. Electronically adjustable suspension system (page 3-43) 4. Windshield (page 3-13) 5. Fuses (page 6-33) 6. Battery (page 6-31) 7. Brake pedal (page 3-28) 8. Rear brake fluid reservoir (page 6-24)

  • Page 14: Controls And Instruments

    Description EAU63401 Controls and instruments 1. Rear view mirror (page 3-42) 2. Left handlebar switches (page 3-24) 3. Multi-function meter unit (page 3-11) 4. Main switch/steering lock (page 3-2) 5. Front brake fluid reservoir (page 6-24) 6. Right handlebar switches (page 3-24) 7.

  • Page 15: Instrument And Control Functions

     Do not grind any key or alter its cess, take the vehicle along with all shape. three keys to a Yamaha dealer to have  Do not disassemble the plastic them re-registered. Do not use the key part of any key.

  • Page 16: Main Switch/Steering Lock

    Instrument and control functions  Keep the standard keys as well EAU10474 Main switch/steering lock as keys of other immobilizer systems away from this vehi- cle’s code re-registering key.  Keep other immobilizer system keys away from the main switch as they may cause signal inter- ference.
  • Page 17 Instrument and control functions To unlock the steering EWA10062 WARNING Never turn the key to “OFF” or “LOCK” while the vehicle is moving. Otherwise the electrical systems will be switched off, which may result in loss of control or an accident. EAU10694 LOCK The steering is locked and all electrical...

  • Page 18: Indicator Lights And Warning Lights

    5. Left turn signal indicator light “ ” or if the warning light remains on, have 6. Engine trouble warning light “ ” a Yamaha dealer check the electrical 7. Oil level warning light “ ” circuit. 8. Neutral indicator light “...
  • Page 19 If this occurs, braking. Have a Yamaha dealer have a Yamaha dealer check the on- check the brake system and electri- board diagnostic system. cal circuits as soon as possible.
  • Page 20 Stop the vehicle when it is safe to do and the lights by following the proce- so, and park it away from traffic. Have dures under “Resetting” on page 3-31. a Yamaha dealer check the YCC-S system. EAU55392 Electronically adjustable suspen- sion system warning light “...
  • Page 21 4. If one or both of the standard keys do not start the engine, take the EAU73120 vehicle and all 3 keys to a Yamaha Immobilizer system indicator dealer to have the standard keys light “ ”...

  • Page 22: Cruise Control System

    Instrument and control functions EAU55382 Cruise control system A.TEMP This model is equipped with a cruise C.TEMP control system designed to maintain a set cruising speed. TIME TR The cruise control system operates only when riding in 3rd gear at speeds between about 50 km/h (31 mi/h) and 160 km/h (100 mi/h), 4th or 5th gear at speeds between about 50 km/h (31...
  • Page 23 Instrument and control functions 2. Push the “SET–” side of the cruise You can also manually increase your control setting switch to activate traveling speed using the throttle. After the cruise control system. Your you have accelerated, you can set a current traveling speed will be- new cruising speed by pushing the come the set cruising speed.
  • Page 24 Instrument and control functions When traveling with a set cruising Using the resume function Push the “RES+” side of the cruise speed, if the cruise control system is control setting switch to reactivate the deactivated under the above condi- cruise control system. The traveling tions, the “...

  • Page 25: Multi-Function Meter Unit

    Instrument and control functions EAU55415 Multi-function meter unit 12 3 9 10 GEAR A.TEMP ˚C C.TEMP ˚C TIME TRIP 0:06 1. Menu switch “MENU” 2. Select switch “ ” 1. “RESET” button multi-function meter unit 2. “TCS” button equipped with the following: 3.
  • Page 26 1. Tachometer play segments will flash repeatedly. 2. Tachometer red zone Have a Yamaha dealer check the vehi- cle. The electric tachometer allows the rid- er to monitor the engine speed and Eco indicator keep it within the ideal power range.
  • Page 27 Instrument and control functions Transmission gear display Function display GEAR GEAR A.TEMP ˚C A.TEMP ˚C C.TEMP ˚C C.TEMP ˚C TIME TRIP 0:06 TIME TRIP 0:06 1. Shift down indicator light “ ” 1. Function display 2. Neutral indicator light “ ”...
  • Page 28 Instrument and control functions The following pages contain an expla- Selecting the information display nation of the grip warmer, information GEAR display, and windshield functions. See TRIP-1 page 3-43 for an explanation of the TRIP-2 preload and damping force adjusting functions.
  • Page 29 Instrument and control functions The odometer shows the total distance In this case, push the select switch to traveled by the vehicle. switch the display in the following or- der: Tripmeter displays: TRIP-F → Display–1 → Display–2 → Display–3 → TRIP-F TRIP-1 To reset a tripmeter, use the select switch to select the information display...
  • Page 30 Instrument and control functions If the message “Hi” flashes, stop the vehicle, then stop the engine, and let There are also “TIME–2” and “TIME–3” the engine cool. (See page 6-37.) elapsed time displays, but they cannot be set to the information display. See GEAR “Setting mode”...
  • Page 31 If there is a malfunction, “– –.–” will SET” button again for 2 seconds while be continuously displayed. Have a the display is flashing. Yamaha dealer check the vehicle. Adjusting the windshield position After resetting the average fuel con- To move the windshield up, push sumption display, “_ _._”...
  • Page 32 Instrument and control functions and return to the normal display, push Adjusting the temperature levels of the and hold the menu switch “MENU” grip warmer settings again for at least 2 seconds. 1. Use the select switch to highlight “Grip Warmer”. Display Description This function allows you to...
  • Page 33 Instrument and control functions Grip Warmer MENU Grip Warmer Hi g h Maintenance Time Trip Middle Unit Display Brightness Clock 4. Use the select switch to highlight 2. Push the “MENU” switch, and “Middle” or “Low”, and then then push the “RESET” button to change the setting using the same select the item to reset.
  • Page 34 Instrument and control functions 2. Push the “MENU” switch to dis- play “TIME–2” and “TIME–3”. To Unit reset a time trip, push the “RE- SET” button to select the item to km or mile reset. km/L or L/100km km/L Time Trip 0:07 TIME-2 3.
  • Page 35 Instrument and control functions Unit Display-1 km or mile A.TEMP km/L or L/100km C.TEMP km/L TIME TRIP 4. Use the select switch to select the Selecting the display items item to show, and then push the 1. Use the select switch to highlight “MENU”...
  • Page 36 Instrument and control functions Adjusting the meter panel brightness 3. When the hour digits start flash- 1. Use the select switch to highlight ing, use the select switch to set “Brightness”. the hours. MENU Clock Grip Warmer Maintenance Time Trip 5 55 Unit Display...

  • Page 37: D-Mode (Drive Mode)

    Instrument and control functions EAU49432 D-mode (drive mode) All Reset D-mode is an electronically controlled engine performance system with two mode selections (touring mode “T” and sports mode “S”). Push the drive mode switch “MODE” to switch between modes. (See page 3-25 for an explanation of the drive mode switch.) The odometer and the clock cannot be...

  • Page 38: Handlebar Switches

    Instrument and control functions EAU1234J Handlebar switches The inside cornering lights come on Left with the high beam. EAU12461 Turn signal switch “ ” To signal a right-hand turn, push this switch to “ ”. To signal a left-hand turn, push this switch to “ ”.
  • Page 39 Instrument and control functions If this function is activated and the ECA10062 NOTICE transmission is in 2nd gear or higher when the rider stops the vehicle, the Do not use the hazard lights for an function will automatically shift down extended length of time with the en- to 1st gear.

  • Page 40: Ycc-S System

    EAU55491 EAU40496 YCC-S system Shift pedal This vehicle features the YCC-S (Yamaha Chip Controlled-Shift) sys- tem. The basic function of this system al- lows the rider to shift gears without the use of a clutch lever. Furthermore, a hand shift lever is equipped on the...

  • Page 41: Hand Shift Lever

    Instrument and control functions 2. Move the shift pedal to the desired EAU55403 Hand shift lever “ ”/“ ” position. 3. Install the bolt, and then tighten it to the specified torque. Tightening torque: Shift pedal bolt: 7 Nm (0.7 m·kgf, 5.1 ft·lbf) –...

  • Page 42: Brake Lever

    Instrument and control functions EAU26825 EAU39542 Brake lever Brake pedal The brake lever is located on the right side of the handlebar. To apply the front brake, pull the lever toward the throttle grip. 1. Brake pedal The brake pedal is located on the right side of the vehicle.

  • Page 43: Abs

    However, special tools are rear brakes independently. required, so please consult your Operate the brakes with ABS as you Yamaha dealer. would conventional brakes. If the ABS ECA16831 is activated, a pulsating sensation may NOTICE...

  • Page 44: Traction Control System

    Instrument and control functions EAU54271 Traction control system Turn the traction control system off to The traction control system helps help free the rear wheel if the motorcy- maintain traction when accelerating on cle gets stuck in mud, sand, or other slippery surfaces, such as unpaved or soft surfaces.

  • Page 45: Fuel Tank Cap

    Leaking fuel is a fire hazard. motorcycle may still be ridden; howev- er, have a Yamaha dealer check the motorcycle as soon as possible. 3-31...

  • Page 46: Fuel

    1. Fuel tank filler tube 2. Maximum fuel level Your Yamaha engine has been de- signed to use regular unleaded gaso- line with a research octane number of 3-32...

  • Page 47: Fuel Tank Overflow Hose

    10% (E10). Gas- ohol containing methanol is not 1. Fuel tank overflow hose recommended by Yamaha because it 2. Clamp can cause damage to the fuel system or vehicle performance problems. See page 6-11 for breather hose infor- mation.

  • Page 48: Catalytic Converters

    Instrument and control functions EAU13447 EAU39496 Catalytic converters Seats This vehicle is equipped with catalytic converters in the exhaust system. Passenger seat EWA10863 WARNING To remove the passenger seat The exhaust system is hot after op- 1. Insert the key into the seat lock, and then turn it counterclockwise.
  • Page 49 Instrument and control functions  The rider seat height can be ad- Rider seat justed to change the riding posi- To remove the rider seat tion. (See the following section.) 1. Remove the passenger seat. 2. Push the rider seat lock lever, lo- cated under the back of the rider seat, to the left as shown, and then pull the seat off.

  • Page 50: Adjusting The Rider Seat Height

    Instrument and control functions EAU39633 Adjusting the rider seat height The rider seat height can be adjusted to one of two positions to suit the rid- er’s preference. The rider seat height was adjusted to the lower position at delivery. 1.
  • Page 51 Instrument and control functions 6. Align the projection on the bottom 5. Insert the projection on the front of of the rider seat with the “H” posi- the rider seat into seat holder A as tion slot, and then push the rear of shown.

  • Page 52: Storage Compartment

    Instrument and control functions EAU73470 EWA10962 Storage compartment WARNING  Do not exceed the load limit of 3 kg (7 lb) for the storage com- partment.  Do not exceed the maximum load of 208 kg (459 lb) for the ve- hicle.

  • Page 53: Accessory Box

    Instrument and control functions  Do not exceed the maximum EAU39482 Accessory box load of 208 kg (459 lb) for the ve- The accessory box is located beside hicle. the meter panel. To open the accessory box 1. Insert the key into the main switch, and then turn it to “ON”.

  • Page 54: Adjusting The Headlight Beams

    It may be neces- preference. Have a Yamaha dealer ad- sary to adjust the headlight beams to just the position of the handlebars.

  • Page 55: Opening And Closing The Cowling Vents

    Instrument and control functions EAU54151 Opening and closing the cowl- ing vents The cowling vents can be opened 20 mm (0.79 in) for added ventilation to suit the riding conditions. 1. Projection 2. Upper slot 3. Quick fastener 4. Install the quick fastener. To close a cowling vent 1.

  • Page 56: Rear View Mirrors

    Instrument and control functions EAU39672 Rear view mirrors The rear view mirrors of this vehicle can be folded forward or backward for parking in narrow spaces. Fold the mir- rors back to their original position be- fore riding. 1. Projection 2.

  • Page 57: Adjusting The Front And Rear Suspension

    Yamaha dealer check the sus- Preload pension system. When riding with luggage or a passen- ger, use the preload adjusting function To adjust the preload to adjust the suspension system to 1. Turn the key to “ON”, start the en- match the load.
  • Page 58 Instrument and control functions GEAR GEAR 1. Menu switch “MENU” While the preload is being adjusted, 2. Select switch “ ” the information display may change as 3. Use the select switch to select the follows.  If the key is turned to “OFF” or the desired preload setting pictogram.
  • Page 59 Instrument and control functions GEAR GEAR GEAR HARD HARD 1. Damping force setting  If the preload is adjusted repeat- 2. Damping force setting level edly, the preload setting picto- gram will flash 4 times and the preload cannot be adjusted. Wait If the preload setting was not complet- approximately 6 minutes for the ed correctly:...
  • Page 60 Instrument and control functions GEAR The damping force setting can be set to 7 levels (+3, +2, +1, 0, –1, –2 and –3). “+3” is the hardest level and “–3” is the softest level. 6. Push the menu switch “MENU”. If the vehicle moves while you are ad- justing the damping force, the informa- 1.

  • Page 61: Sidestand

    Therefore, check this system regularly and have a Yamaha dealer repair it if it does not function properly. 3-47...

  • Page 62: Ignition Circuit Cut-Off System

    Instrument and control functions EAU68770 Ignition circuit cut-off system The ignition circuit cut-off system (comprising the sidestand switch and brake light switches) has the following functions.  It prevents starting when the side- stand is up, but neither brake is applied.
  • Page 63 The neutral switch, a brake light switch or the YCC-S system may not be working correctly. The motorcycle should not be ridden until checked by a Yamaha dealer. With the engine still running: 8. Move the sidestand up. 9. Shift the transmission into gear.

  • Page 64: Auxiliary Dc Jack

    Instrument and control functions 5. Insert the accessory plug into the EAU39656 Auxiliary DC jack auxiliary DC jack. EWA14361 WARNING To prevent electrical shock or short- circuiting, make sure that the cap is installed when the auxiliary DC jack is not being used. ECA15432 NOTICE The accessory connected to the...

  • Page 65: Cornering Lights

    Instrument and control functions EAU73031 Cornering lights 1. Cornering light This model is equipped with 3 corner- ing lights on each side. The cornering lights come on to help illuminate the road when the vehicle is leaned over. According to the direction of the turn, the cornering lights for that side come on.

  • Page 66: For Your Safety - Pre-Operation Checks

    Do not operate the vehicle if you find any problem. If a problem cannot be corrected by the procedures provided in this manual, have the vehicle inspected by a Yamaha dealer. Before using this vehicle, check the following points:...
  • Page 67 • Tighten if necessary. Instruments, lights, • Check operation. — signals and switches • Correct if necessary. • Check operation of ignition circuit cut-off system. Sidestand switch • If system is not working correctly, have Yamaha dealer 3-47 check vehicle.

  • Page 68: Operation And Important Riding Points

    This model is equipped with: there is a control or function you do not  an inertial measurement unit (IMU) understand, ask your Yamaha dealer. that will stop the engine in case of EWA10272 turnover. In this case, turn the key WARNING to “OFF”...

  • Page 69: Starting The Engine

    The neutral indi- a few seconds, then go off. cator light should come on. If not,  Oil level warning light ask a Yamaha dealer to check the  Engine trouble warning light electrical circuit.  Traction control system indi- 3.

  • Page 70: Shifting

    Operation and important riding points the battery. Do not crank the en- EAU55482 Shifting gine more than 10 seconds on any one attempt. ECA11043 NOTICE For maximum engine life, never ac- celerate hard when the engine is cold! 1. Shift pedal 2.
  • Page 71 Operation and important riding points the “ ” side of the hand shift lever 3. At the recommended shift points repeatedly until the neutral indica- shown in the following table, close tor light comes on. the throttle.  When shifting from neutral to 1st 4.

  • Page 72: Tips For Reducing Fuel Consumption

    Operation and important riding points  Make sure that the motorcycle EAU16811 Tips for reducing fuel con- and the engine have sufficiently sumption slowed before shifting to a low- Fuel consumption depends largely on er gear. Engaging a lower gear your riding style.

  • Page 73: Engine Break-In

    There is never a more important period period, immediately have a in the life of your engine than the period Yamaha dealer check the vehi- between 0 and 1600 km (1000 mi). For cle. this reason, you should read the fol- lowing material carefully.

  • Page 74: Parking

    Operation and important riding points EAU40584 Parking When parking, stop the engine by turn- ing the main switch to “OFF”, and then remove the key. When the main switch is turned to “OFF” and the transmission is in gear, the rear wheel cannot be moved. EWA14524 WARNING ...

  • Page 75: Periodic Maintenance And Adjustment

    If you are not familiar with vehicle ser- vice, have a Yamaha dealer perform service. EWA15123 WARNING Turn off the engine when performing...

  • Page 76: Owner's Tool Kit

    If you do not have the tools or experi- ence required for a particular job, have a Yamaha dealer perform it for you.

  • Page 77: Periodic Maintenance Chart For The Emission Control System

     From 50000 km (30000 mi), repeat the maintenance intervals starting from 10000 km (6000 mi).  Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technical skills. EAU63322...

  • Page 78: General Maintenance And Lubrication Chart

    Periodic maintenance and adjustment EAU64031 General maintenance and lubrication chart ODOMETER CHECK OR READINGS MAINTENANCE JOB ITEM X 1000 km X 1000 mi √ √ • Clean. 1 * Air filter element √ √ • Replace. • Check operation, fluid level and √...
  • Page 79 Periodic maintenance and adjustment ODOMETER CHECK OR READINGS MAINTENANCE JOB ITEM X 1000 km X 1000 mi Brake lever pivot √ √ √ √ √ • Lubricate with silicone grease. shaft Brake pedal pivot • Lubricate with lithium-soap- √ √ √...
  • Page 80 Periodic maintenance and adjustment ODOMETER CHECK OR READINGS MAINTENANCE JOB ITEM X 1000 km X 1000 mi • Check operation. • Check throttle grip free play, and adjust if necessary. √ √ √ √ √ 27 * Throttle grip • Lubricate cable and grip hous- ing.

  • Page 81: Removing And Installing Panels

    Periodic maintenance and adjustment EAU18773 EAU54133 Removing and installing pan- Panel A The panels shown need to be removed to perform some of the maintenance To remove the panel jobs described in this chapter. Refer to 1. Remove the bolts and the quick this section each time a panel needs to fasteners.
  • Page 82 Periodic maintenance and adjustment Make sure that the fuses are covered and located to the inside of the panel lip. 1. Slot 2. Projection To install the panel 1. Fit the slot at the front of the panel under the projection on the front 1.
  • Page 83 Periodic maintenance and adjustment 1. Panel C 1. Panel B 2. Quick fastener screw 2. Install the seats. 3. Bolt 3. Pull the bottom of the panel out- ward, pull the front of the panel downward, and then slide the panel forward to release it in the rear as shown.

  • Page 84: Checking The Spark Plugs

    The spark plugs are important engine components, which should checked periodically, preferably by a Yamaha dealer. Since heat and depos- its will cause any spark plug to slowly erode, they should be removed and checked in accordance with the peri- odic maintenance and lubrication 1.

  • Page 85: Canister

    Periodic maintenance and adjustment EAU36111 EAU19888 Canister Engine oil and oil filter car- tridge The engine oil level should be checked before each ride. In addition, the oil must be changed and the oil filter car- tridge replaced at the intervals speci- fied in the periodic maintenance and lubrication chart.
  • Page 86 3. Place an oil pan under the engine An oil filter wrench is available at a to collect the used oil. Yamaha dealer. 4. Remove the engine oil filler cap, 6. Apply a thin coat of clean engine the engine oil drain bolt and its...
  • Page 87 See page 8-1. correct, immediately turn the engine Oil quantity: Oil change: off and have a Yamaha dealer check 3.80 L (4.02 US qt, 3.34 Imp.qt) the vehicle. With oil filter removal: 4.00 L (4.23 US qt, 3.52 Imp.qt) 11.

  • Page 88: Final Gear Oil

    Final gear oil The final gear case must be checked for oil leakage before each ride. If any leakage is found, have a Yamaha deal- er check and repair the vehicle. In ad- dition, the final gear oil level must be...

  • Page 89: Coolant

    (See page 3-41.) 3. Check the coolant level in the Recommended final gear oil: coolant reservoir. Yamaha genuine shaft drive gear oil SAE 80W-90 API GL-5 Oil quantity: The coolant should be between the 0.20 L (0.21 US qt, 0.18 Imp.qt) minimum and maximum level marks.
  • Page 90 Have a engine is hot. [EWA15162] Yamaha dealer change the coolant. WARNING! Never attempt to remove the radiator cap when the engine is hot. [EWA10382] 1.

  • Page 91: Air Filter Element

    Check the engine idling speed and, if the periodic maintenance and lubrica- necessary, have it corrected by a tion chart. Have a Yamaha dealer clean Yamaha dealer. or replace the air filter element. Engine idling speed: 1000–1100 r/min...

  • Page 92: Checking The Throttle Grip Free Play

    Measure the throttle grip free play as and/or engine noise. To prevent this shown. from occurring, the valve clearance must be adjusted by a Yamaha dealer at the intervals specified in the periodic maintenance and lubrication chart. 1. Throttle grip free play Throttle grip free play: 1.0–3.0 mm (0.04–0.12 in)

  • Page 93: Tires

    The tires must be checked before each ride. If the center tread depth reaches the specified limit, if the tire has a nail or glass fragments in it, or if the side- wall is cracked, have a Yamaha dealer replace the tire immediately. 6-19...
  • Page 94 EWA10472 their suitability for further use. WARNING EWA10902  Have a Yamaha dealer replace WARNING excessively worn tires. Besides  The front and rear tires should being illegal, operating the vehi- be of the same make and de-...

  • Page 95: Cast Wheels

    If any damage is found, have high speeds. a Yamaha dealer replace the  Brand-new tires can have a rel- wheel. Do not attempt even the atively poor grip on certain road smallest repair to the wheel.

  • Page 96: Ycc-S Clutch

    If any of the above occurs, have a Yamaha dealer check the YCC-S clutch. 1. No brake lever free play There should be no free play at the brake lever end.

  • Page 97: Brake Light Switches

    Since the brake light ified in the periodic maintenance and switches are components of the cruise lubrication chart. control system, they must be adjusted by a Yamaha dealer, who has the nec- EAU43432 Front brake pads essary professional knowledge and ex- perience.

  • Page 98: Checking The Brake And Ycc-S Clutch Fluid Levels

    If a brake pad is damaged or if the lining thickness is less than 0.8 mm (0.03 in), have a Yamaha dealer replace the brake pads as a set. 1. Minimum level mark Rear brake 1.
  • Page 99  Clean the filler caps before re- or YCC-S clutch fluid level goes down moving. Use only DOT 4 brake suddenly, have a Yamaha dealer check fluid from a sealed container. the cause before further riding.  Use only the specified brake flu- id;...

  • Page 100: Changing The Brake And Ycc-S Clutch Fluids

    YCC-S clutch master cylinders and damaged or does not move smoothly, calipers as well as the brake and have a Yamaha dealer check or re- YCC-S clutch hoses replaced at the in- place it. WARNING! Damage to the tervals listed below or whenever they outer housing of cables may result are damaged or leaking.

  • Page 101: Checking And Lubricating The Throttle Grip And Cable

    In pedals should be checked before each addition, the cable should be lubricat- ride, and the pedal pivots should be lu- ed by a Yamaha dealer at the intervals bricated if necessary. specified in the periodic maintenance Brake pedal chart.

  • Page 102: Checking And Lubricating The Brake Lever

    Silicone grease WARNING If the centerstand or sidestand does not move up and down smoothly, have a Yamaha dealer check or re- pair it. Otherwise, the centerstand or sidestand could contact the ground and distract the operator, resulting in a possible loss of control.

  • Page 103: Lubricating The Rear Suspension

    The pivoting points of the rear suspen- The swingarm pivots must be lubricat- sion must be lubricated by a Yamaha ed by a Yamaha dealer at the intervals dealer at the intervals specified in the specified in the periodic maintenance periodic maintenance and lubrication and lubrication chart.

  • Page 104: Checking The Front Fork

    If any free there is no danger of it falling play can be felt, have a Yamaha over. dealer check or repair the steer- [EWA10752] 2.

  • Page 105: Checking The Wheel Bearings

    Checking the wheel bearings Battery ECA22960 NOTICE Use only the specified genuine YAMAHA battery. Using a different battery may cause the IMU to fail and the engine to stall. The front and rear wheel bearings must be checked at the intervals specified in the periodic maintenance and lubrica- tion chart.
  • Page 106 Storing a discharged battery can To charge the battery cause permanent battery damage. Have a Yamaha dealer charge the bat- tery as soon as possible if it seems to have discharged. Keep in mind that the battery tends to discharge more quick- ly if the vehicle is equipped with op- tional electrical accessories.

  • Page 107: Replacing The Fuses

    Periodic maintenance and adjustment EAU54515 Replacing the fuses 13 14 The fuse boxes and individual fuses are located under panel A. (See page 6-7.) 17 16 1. ABS motor fuse 2. ABS solenoid fuse 3. Fuel injection system fuse 4. Backup fuse (for clock and immobilizer sys- tem) 5.

  • Page 108: Vehicle Lights

    There are no user replaceable Main fuse 2: bulbs. 30.0 A Terminal fuse 1: If a light does not come on, check the 3.0 A fuses and then have a Yamaha dealer Headlight fuse: check the vehicle. 7.5 A ECA16581 Brake light fuse: NOTICE 1.0 A...

  • Page 109: Troubleshooting

    The following troubleshooting charts represent quick and easy procedures for checking these vital systems your- self. However, should your motorcycle require any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, experience, and know-how to service the motorcycle properly.

  • Page 110: Troubleshooting Charts

    Check the vehicle. compression. 4. Compression The engine does not start. There is compression. Have a Yamaha dealer check the vehicle. Operate the electric starter. There is no Have a Yamaha dealer check the vehicle. compression. 6-36...
  • Page 111 Start the engine. If the engine overheats again, The coolant level is have a Yamaha dealer check and repair the cooling system. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended coolant as soon as possible.

  • Page 112: Motorcycle Care And Storage

    Rust and corrosion can develop matte colored finished parts. Be even if high-quality components are sure to consult a Yamaha dealer for used. A rusty exhaust pipe may go un- advice on what products to use be- noticed on a car, however, it detracts fore cleaning the vehicle.
  • Page 113 Motorcycle care and storage structed. Also, thoroughly rinse compounds for plastic may the area off with water, immedi- leave scratches on the wind- ately dry it, and then apply a cor- shield. Test the product on a rosion protection spray. small hidden part of the wind- ...
  • Page 114 3. To prevent corrosion, it is recom-  Consult a Yamaha dealer for ad- mended to apply a corrosion pro- vice on what products to use. tection spray metal, ...

  • Page 115: Storage

    Motorcycle care and storage cylinder head so that the elec- EAU26244 Storage trodes are grounded. (This will limit sparking during the next Short-term step.) Always store your motorcycle in a cool, d. Turn the engine over several dry place and, if necessary, protect it times with the starter.
  • Page 116 Motorcycle care and storage Make any necessary repairs before storing the motorcycle.

  • Page 117: Specifications

    Overall length: Final gear oil: 2230 mm (87.8 in) Overall width: Type: 750 mm (29.5 in) Yamaha genuine shaft drive gear oil SAE Overall height: 80W-90 API GL-5 1325/1455 mm (52.2/57.3 in) Quantity: Seat height: 0.20 L (0.21 US qt, 0.18 Imp.qt) 805/825 mm (31.7/32.5 in)
  • Page 118 Specifications 2nd: Front wheel: 1.722 (31/18) Wheel type: 3rd: Cast wheel 1.350 (27/20) Rim size: 4th: 17M/C x MT3.50 1.111 (30/27) Rear wheel: 5th: Wheel type: 0.963 (26/27) Cast wheel 6th: Rim size: 0.846 (22/26) 17M/C x MT5.50 Chassis: Unified brake system: Frame type: Operation: Diamond...
  • Page 119 Specifications Battery: Main fuse 2: 30.0 A Model: Terminal fuse 1: GT14B-4 3.0 A Voltage, capacity: Headlight fuse: 12 V, 12.0 Ah (10 HR) Bulb wattage × quantity: 7.5 A Brake light fuse: Headlight: 1.0 A Signaling system fuse: Brake/tail light: 7.5 A Ignition fuse: Front turn signal light:...

  • Page 120: Consumer Information

    Yamaha dealer. area. VEHICLE IDENTIFICATION NUMBER: EAU26442 Engine serial number...

  • Page 121: Diagnostic Connector

    Consumer information label in the space provided. This infor- EAU69910 Diagnostic connector mation will be needed when ordering spare parts from a Yamaha dealer. 1. Diagnostic connector The diagnostic connector is located as shown.

  • Page 122: Index

    Index Fuel consumption, tips for reducing ..5-5 Fuel tank cap........3-31 ABS............3-29 Fuel tank overflow hose ....... 3-33 ABS warning light ........3-5 Fuses, replacing ........6-33 Accessory box ........3-39 Air filter element ........6-17 Auxiliary DC jack........3-50 Handlebar position, adjusting ....3-40 Handlebar switches......
  • Page 123 Index Steering, checking ....... 6-30 Stop mode function indicator light..3-6 Stop mode function switch ....3-25 Stop/Run/Start switch......3-24 Storage........... 7-4 Storage compartment ......3-38 Suspension, adjusting the front and rear ............. 3-43 Swingarm pivots, lubricating....6-29 Throttle grip and cable, checking and lubricating ..........
  • Page 126 Original instructions PRINTED ON RECYCLED PAPER PRINTED IN JAPAN 2016.03-0.3×1 CR...

Table of Contents
