Summary of Contents for Compass Navibe GB731
- Page 1 Navibe GB731 GB621 Navibe GB731 GB621 Bluetooth Receiver User manual...
- Page 2 Compass Systems Corp. Information in this User’s Manual is subject to change without notice. Compass Systems Corp. reserves the right to change or improve or modify its products and to make changes to the content without obligation to notify any person or organization of such changes.
- Page 3 Introduction WARNINGS WARNINGS Some certain knowledge is required to be well known by the user for proper and safe use Some certain knowledge is required to be well known by the user for proper and safe use of Navibe Bluetooth GPS receiver. Please read this User’s Manual first before operation. of Navibe Bluetooth GPS receiver.
- Page 4 Introduction CAUTION CAUTION The Global Positioning System(GPS) is a system of 24 satellites which circle the earth The Global Positioning System(GPS) is a system of 24 satellites which circle the earth twice a day in a very precise orbit and transmit information to earth. The Navibe must twice a day in a very precise orbit and transmit information to earth.
- Page 5 Introduction Thank you for choosing Navibe Bluetooth GPS Receiver Thank you for choosing Navibe Bluetooth GPS Receiver Take it now ------ it can be your best friend! Take it now ------ it can be your best friend! Application Conditions: Navibe is designed for outdoors navigation in the temperature range of -20°C~ 70°C. Introduction section gives you a general overview of Navibe features.
- Page 6 Introduction Chapter I Introduction Section 1 Announcement Section 2 Warnings Section 3 Caution Section 4 Welcome to Navibe Section 5 Table of Contents Chapter II Reference Section 1 Hardware Description Section 2 State Table of LED Section 3 Packet PC Setup...
-
Page 7: Hardware Description
Reference External Hardware Description Antenna Connector Charging (MMCX type) Jack Power Switch Hardware Description Power Switch Bluetooth LED (blue- LED3) GPS (green) & Charging Low Power LED (red) -LED2 (red -LED1) - Page 8 Reference The Bluetooth GPS has three LED indicators. The first is Low Power LED indicator that is named LED1. The second is GPS status and charging LED and that is named LED 2. The third is Bluetooth status LED that is named LED 3. The status table of LED shows as follows: State Table of LED State Table of LED...
- Page 9 Reference LED 2: Middle (Green/Red) GPS LED Description GPS Position Fixed Battery Charging Color and Action Green ON Red ON Green + Red ON Green/Red Flashing LED 3: Left (Blue) Bluetooth LED Description Bluetooth Connection Color and Action Blue Flashing Pairing Blue ON Connected...
- Page 10 Reference Turn on To turn on the receiver, push the power switch to “I” position. The green LED (LED 2) indicator will start flashing showing the status is searching GPS satellites. The left blue LED (LED 3) indicator will start flashing for searching Bluetooth device. Turn off To turn off the receiver, push the power switch to “O”...
- Page 11 Reference Search for Bluetooth Device The left LED (LED 3) blue indicator will flash for pairing Bluetooth signals. When connected, the left LED (LED3) blue indicator will become to steady on. Position Fixed for GPS The second LED (LED 2) green indicator will be flashing when searching satellites.
- Page 12 Reference Pocket PC Setup Pocket PC Setup Note : In “ Bluetooth: Device Pairing ” window you will required to enter Note : In “ Bluetooth: Device Pairing ” window you will required to enter Pocket PC Setup the Passkey number 0000 when opening the port in your GPS program.
- Page 13 Reference 4. Tap where indicated to choose a device. 3. Tap Explore a Bluetooth device, then tap Next And select the ID “BT GPS V1X” to continue. (Note: “X” stands for Firmware Version which is subject to change.)
- Page 14 Reference 5. The PDA will begin retrieving services 6. Select “SPP Slave” and tap Next as shown above...
- Page 15 Reference 8. In the future, you may establish the 7. Tap Finish to establish the BT connection from the shortcut, “BT GPS GPS V10 Bluetooth GPS connection V1X: SPP Slave” (Note: “X” stands for Firmware Version which is subject to change.)
- Page 16 Compass Systems Corp. Tel: +886-2-8751-8598 Fax: +886-2-8797-3898 Email: service@cpss.com.tw Web: www.navibe.com ©Copy right 2006 by Compass Systems Corp. All rights reserved. Printed in Taiwan...
