K8093
ILLUSTRATED ASSEMBLY MANUAL H8093IP'1
Remote controlled
home alarm

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the K8093 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Velleman K8093

Summary of Contents for Velleman K8093

  • Page 1 K8093 ILLUSTRATED ASSEMBLY MANUAL H8093IP’1 Remote controlled home alarm...
  • Page 2 Velleman N.V. Legen Heirweg 33 9890 Gavere (België)
  • Page 3 Subscribing our newsletter?, visit www.vellemanprojects.eu Forum Forum Participate our Velleman Projects Forum...
  • Page 4 DO NOT BLINDLY FOLLOW THE ORDER OF THE COMPONENTS ONTO THE TAPE. ALWAYS CHECK THEIR VALUE ON THE PARTS LIST! - 4 -...
  • Page 5 assembly 1. Assembly (Skipping this can lead to troubles ! ) hints Ok, so we have your attention. These hints will help you to make this project successful. Read them carefully. 1.1 Make sure you have the right tools: • A good quality soldering iron (25-40W) with a small tip. • Wipe it often on a wet sponge or cloth, to keep it clean;...

  • Page 6: Specifications

    features • can store up to 4 remote controls (FIFO) • chime function • built-in pre-alarm • always armed after power outage • the built-in relay can switch a regular alarm (not included) (3 A 125 VAC) after 20 s pre-alarm • arm time: • slow with indication: if the door is open or closed (time to leave the room) • quickly...
  • Page 7 Construction I. CONSTRUCTION Ceramic Capacitors Transistors Resistors ‰ C1 : 100nF (104) ‰ C2 : 100nF (104) R... ‰ C3 : 100nF (104) ‰ T1 : BC547 ‰ T2 : BC547 ‰ T3 : BC547 IC socket TVoltage regulator Watch the position of ‰...

  • Page 8: Rf-Receiver

    Construction Sounder Relay RF-receiver ‰ BUZ1 NO NC Terminal blocks ‰ RY1 ‰ RX1 : RX433N LED’s Watch the polarity! ‰ SK2 : 2p (Relais) ‰ LD1: Red (power) ‰ SK3 : 2p (N.O. / N.C) ‰ LD2: Red (status) Output ‰...
  • Page 9 Assembly II. ASSEMBLY Watch the position of the notch! ‰ IC1 : VK8093 Home Alarm System with RF Remote (programmed PIC16F1503-I/P) LEARN 12V DC OUTPUT REED NO NC COM Antenna BOTTOM SCREW - 9 -...

  • Page 10: Connection Diagram

    Driver installation & programs III. CONNECTION DIAgRAM (*) If you want to connect a 12V siren directly to the relay you can connect the +12V of the input volt- age to the COM. Connect the nega- tive lead of the siren to the leftmost (-) connector and the positive to the NC or NO contact of the relay.
  • Page 11 Arming the unit IV. ARMINg ThE UNIT Out of the box no remotes are assigned for safety reasons. When the unit powers up it is always armed! Unit is capable of storing 4 remotes, FIFO. The stored remotes can be cleared from memory by holding the LEARN button while powering up, The unit will beep 10 times (fast) to indicate the erasing process.
  • Page 12 Arming the unit How to arm? There are 3 methodes for arming your unit: • Arming with open door • Quickly arming with open door • Arming with closed door Arming with open door: When the door is open, the unit beeps for prox. 20seconds before actually arming. Closing the door will the unit beeps faster. After the delay periode the unit is armed.
  • Page 13 Diagram +12V UA78L05 ICSP CONNECTOR 1N4007 SCREW02 SCREW02 100n 100n 470µ/16V +12V SCREW02 LED3RL VR15M121C 1N4148 BC547 LED3RL 100n RX433 MODULE PIC16F1503-I/P BUZ1 DIG OUT +12V RA0/ICSPDAT LIN OUT RA1/ICSPCLK BUZZER TEST RA3/MCLR/Vpp 1N4148 +12V BC547 LED3RL SCREW02 BC547 LED3RL 10µ...
  • Page 14 - 14 -...

  • Page 15: Open Collector Outputs

    Leds and how to use them Leds feature a specific voltage Never connect leds in parallel drop, depending on type and colour. Check the datasheet for exact voltage drop and rated current ! How to Calculate the series resistor: Example: operate a red led (1.7V) on a 9Vdc source. Required led current for full brightness: 5mA (this can be found in the datasheet of the led) Supply voltage (V) - led voltage (V) = series resistance (ohms)
  • Page 16 The new Velleman Projects catalogue is now available. Download your copy here: www.vellemanprojects.eu Modifications and typographical errors reserved - © Velleman nv. H8093’IP Velleman NV, Legen Heirweg 33 - 9890 Gavere.
