Reversing The Door - GE DDSS475 Owner's Manual

About reversing the door.

Reversing the Door

Tools needed:
Standard #2 Tape-tipped
Phillips screwdriver putty knife
Remove the four hinge attaching screws.
1
Remove all nine (9) screws from the door and hinges.
2
Pull the bottom of the door liner out (A), then pull
3
down (B), removing the door liner from the door
panel.
Rotate the door panel 180° as shown.
4
Remove the door strike from the door liner and
5
reinstall on the opposite side.
1
4
7
8
Flat-blade
screwdriver
Insert the liner under the flange on the bottom of
6
the door (A), then push the top of the door liner
into place (B).
Reinstall the nine (9) screws removed in Step 2.
7
Using a screwdriver or tape-tipped putty knife,
8
remove the two door plugs and reinstall on the
opposite side of the door opening.
Reinstall the four hinge attaching screws removed
9
in Step 1.
2
5
8
3
B
A
6
B
A
9
