Summary of Contents for PROLiNK PRO2013WE
-
Page 2: Table Of Contents
Before operating the monitor, please read this manual thoroughly. This manual should be retained for future reference. Content IMPORTANT SAFEGUARDS 1.Introduction......................1 1.1 Features......................1 1.2 Checking List....................1 2. Installation......................2 2.1 Install the pedestal..................2 2.2 Connect your monitor to computer.............. 2 3. - Page 3 FCC Class B Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 4: Important Safeguards
IMPORTANT SAFEGUARDS Warnings: Please read all of these instructions and save it for later use. Unplug this monitor from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. Do not use attachments not recommended by the monitor manufacturer as they may cause hazards. - Page 5 When the power cord or plug is damaged or frayed. If liquid has been spilled into the monitor. If the monitor has been exposed to rain or water. If the monitor does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions as improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the monitor to normal...
-
Page 6: Introduction
1. Introduction 1.1 Features Microprocessor based with OSD (On Screen Display) control. Compatible with standard IBM VGA, extended VGA, super VGA, IBM XGA, SXGA modes, as well as VESA resolution standards. Universal power supply 100-240 Vac, 50/60Hz(Power box)/DC 12V(Monitor) ... -
Page 7: Installation
2. Installation 2.1 Install the Pedestal To attach the base to your monitor, please follow the steps for installation of the pedestal as below: 2.2 Connect your monitor to computer Turn off the computer and unplug the power cable. Connect the signal cable to the signal port on the back of the computer. Connect the AC-power code one end to your LCD monitor’s AC-input socket,the other to wall-outlet. -
Page 8: Front Panel Overview
3. Front Panel Overview 1、Menu Button To push menu button turns on the menu, and it activates the items you highlight. 2、Select Button(▲UP/▼DONW) To choose which function you need. You may choose DOWN counterclockwise or UP clockwise. Note: ▲UP:This key for the brightness function keys alone. ▼DOWN:This key for the contrast function keys alone. -
Page 9: Access Features
4. Access Features 4.1 SWITCHING THE MONITOR ON/OFF This power button is used for switching the monitor on and off. Note: The power button does not disconnect the device from the mains voltage. To completely disconnect the mains voltage. Please remove the power plug from the socket. -
Page 10: Osd Functional Control Description
4.4 OSD Functional Control Description 1. Main Menu OSD main menu of controls gives you an overview of the selection of controls available. When you want to make adjustment of the screen image, press and release button Menu Main menu Sub menu Explain menu... - Page 11 Phase 0-100 Adjust the image clock to reduce the vertical scintillation Sharpness 0-100 Select the sharpness to adjust the display definition Reset Reset to the factory settings Do not adjust OSD Timer 5-60 Adjust the OSD display time Transparency 0-100 Adjust the transparency of OSD H.Position 0-100...
-
Page 12: Preset Modes Timing Chart
4.5 Preset Modes Timing Chart The screen image has been optimized during manufacture for the display modes listed below 1. Aspect ratio 16:10 Item Dot X Line Refresh rate(Hz) 720 x 400 640 x 480 60, 75 800 x 600 60, 75 1024 x 768 60, 75... -
Page 13: Plug And Play
4.6 Plug and Play This monitor features the VESA DDC (Display Data Channel) standard, which when used with a DDC compatible video card, will simplify the monitor's set up. With VESA DDC 1/2B, when the monitor is powered up, it will automatically notify a Windows 9X/2000/XP/Vista/7 host computer of its scanning frequencies, capabilities and characteristics. -
Page 14: Technical Information
5. Technical Information 5.1 D-SUB Signal connector pin assignment Signal (D-sub) Signal (D-sub) 5 VDC Green Ground Blue Ground Ground SDA (For DDC) Self Test H. Sync. Red Ground V. Sync. Green Ground SCL (For DDC) Blue Ground D-SUB connector... -
Page 15: Visual Inspection
5.2 Visual Inspection Permanently unlit or lit pixels The standard of production techniques today cannot guarantee an absolutely fault- free screen display. A few isolated constant lit or unlit pixels may be present. The maximum permitted number of pixels faults is stipulated in the stringent international standard ISO-9241-302 (Class II). -
Page 16: Troubleshooting
5.3 Troubleshooting Before calling for service, check the information in this section to see if you can remedy any problems by yourself. If you need assistance, please call the dealer where you purchased the LCD monitor. There is no SCREEN image, please check these items: The power cord or the plug portion of the adapter is securely connected the ...
