Summary of Contents for AtVideo CP95-A5
- Page 2 WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECTS THROUGH THE VENTILATION GRILLS OR OTHER OPENINGS ON THE EQUIPMENT. CAUTION EXPLANATION OF GRAPHICAL SYMBOL The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of un-insulated "dangerous voltage"...
-
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. - Page 5 INTRODUCTION The camera provides high-quality images using SONY CCD technology especially designed for closed-circuit television (CCTV) and security surveillance applications. Features: High resolution and high performance 1/3" SONY Super HAD CCD Technology Excellent picture quality 600 lines(Color) of resolution 0.14 Lux(Color), 0.03 Lux(B/W) @ F1.2, 30IRE Sensitivity Auto electronic shutter [1/60(1/50) ~ 1/100,000] and manual electronic shutter modes OSD (On Screen Display)
- Page 9 CAMERA OPERATION WITH O.S.D <MAIN MENU> EXPOSURE SET COLOR SET <EXPOSURE> < COLOR > DAY & NIGHT SET LENS WB MODE SPECIAL SET E. SHUTTER MOTION DET. R-Y GAIN PRIVACY SET B-Y GAIN SETUP RETURN EXIT SENSE UP RETURN <SPECIAL> <...
-
Page 10: Osd Main Screen
OSD MAIN SCREEN ALL operation is via the tact switch [CENTER] Turn OSD menu ON or to go into Sub Menu [UP] / [DOWN] UP or DOWN of Cursor [LEFT] / [RIGHT] Change setting <EXPOSURE SET> Press the [ENTER] button to access the “EXPOSURE SET” mode. 1) LENS : Select the type of lens. - Page 11 <COLOR SET> Press the [ENTER] button to access the “COLOR SET” mode WB Setting (White Balance) 1) WB MODE : Select AWC/ATW/MANUAL/PUSH LOCK (adjust white balance) Select MANUAL WB (Manual white balance mode) Sub Menu -Select M.WB R (Adjust Red level when using manual WH) Sub Menu -Select M.WB B (Adjust Blue level when using manual WH) Adjust RED gain 2) R-Y GAIN :...
-
Page 12: Special Set
<SPECIAL SET> Press the [ENTER] button to access the “SPECIAL SET” mode 1) MIRROR : OFF/MIRROR/V_FLIP/ROTATE Selectable (left&right / up&down / rotate) Adjust Sharpness (Image sharpness can be adjusted) 2) SHARPNESS : GAMMA Setting 3) GAMMA : Select 0.45/0.6/1.0(Adjust gamma level) Image freeze function 4) FREEZE : Y Signal,Color Reverse function... - Page 13 <PRIVACY SET> Press the [ENTER] button to access the “PRIVACY SET” Mode MASK1 Screen setting 1) MASK1 : MASK2 Screen setting 2) MASK2 : MASK3 Screen setting 3) MASK3 : MASK4 Screen setting 4) MASK4 : MASK5 Screen setting 5) MASK5 : MASK6 Screen setting 6) MASK6 : Return to Main menu.
-
Page 14: Specifications
SPECIFICATIONS Power source AC24V ± 10% / DC12V ± 10% Power Power consumption 160mA (4.0 Watts) Image sensor 1/3” SONY Super-HAD CCD Total number of pixels NTSC : 811(H) x 508(V), PAL : 795(H) x 596(V) Scanning system 2:1 interlace NTSC : 15.734KHz(H) x 59.94Hz(V) Scanning frequency PAL : 15.625KHz(H) x 50Hz(V) - Page 15 Sync INTER / AUTO Zoom & Pan/Tilt ZOOM (X1~X3), PAN(-128~+127), TILT(-82~+81) V - Phase (LineLock) 0 ~ 199 Camera ID 0 ~ 254 EXIT EXIT / SAVE & EXIT / FACTORY SET Power input 2-Pin Wire Video output BNC connector Lens mount Fixed Mount Connector...
- Page 16 50302888A...
