Summary of Contents for AWA MVP932
- Page 1 MVP932 9" Portable DVD Player User Guide • Before attempting to connect, operate or adjust this product, please save and read the User Guide completely. • The style of the product shown in the User Guide may be different from the actual...
-
Page 2: Table Of Contents
CONTENTS CONTENTS .................. 2 FCC AND SAFETY INFORMATION ..........3 IMPORTANT SAFETY INSTRUCTION ........4 PRECAUTIONS ................5 PRODUCT OVERVIEW ............... 6 REMOTE CONTROL ..............7 Remote Control Operation Range ..........9 Battery Installation for the Remote Control ........9 CONNECTION ................ -
Page 3: Fcc And Safety Information
FCC AND SAFETY INFORMATION Since it is usual for DVD movies to be released at dif fer ent CAUTION: times in different regions of the world, all players have This unit employs a laser. Due to possible eye injury, only qualifi ed service personnel should region codes and disc can have an op tion al region code. -
Page 4: Important Safety Instruction
IMPORTANT SAFETY INSTRUCTION 1. Read and keep these instructions. 2. Pay attention to all warnings. 3. Follow all instructions. 4. Do not use this apparatus near water. 5. Clean only with a damp cloth. 6. Do not block any of the ventilation openings. Install in accordance with the man u fac tur er’s instructions. -
Page 5: Precautions
PRECAUTIONS Please read these precautions before op er at ing the unit. AC/DC adaptor protection To avoid any malfunctions of the unit and to protect against electric shock, fi re or personal injury, please observe the fol low ing. Hold the power adapter by its sides fi rmly when connecting or disconnecting it. Keep fi... -
Page 6: Product Overview
PRODUCT OVERVIEW Top Panel Back Panel Right Side Panel 19 20 21 LCD Screen SETUP Button Speakers MENU Button Disc Cover PLAY/SEL. Button LCD Button F.FWD/RIGHT Button MODE Button STOP/DOWN Button PAUSE/UP Button NEXT Button F.BWD/LEFT Button DC IN 12V Jack PREVIOUS Button Volume Dial OPEN Button... -
Page 7: Remote Control
REMOTE CONTROL Name Description • Press to show the playing fi le information, time or chapter INFO. Button Info. title. SETUP Button • Press to bring up the setup menu. ▲ UP/ PAUSE • Press to move up in the menus. •... - Page 8 REMOTE CONTROL Name Description • Press to bring up the View Mode menu. (Refer to page LCD Button 23 for more details.) • Press to display the subtitle language on the screen if SUBTITLE the subtitle is available on the DVD disc. Button TITLE Button •...
-
Page 9: Remote Control Operation Range
REMOTE CONTROL Remote Control Operation Range Point the remote control unit no more than 5 meters from the sensor and Remote within 60° of the front of the unit. Sensor 30° 30° Battery Installation for the Remote Control Push and pull to open the battery compartment. -
Page 10: Connection
CONNECTION Connecting to the Power Back Side Connect one end of the supplied AC power adapter to the unit, and the other end to the wall outlet. DC IN 12V jack Power adapter Wall outlet Turning on the Power Right Side After the power adapter is connected to wall outlet, the LED indicator will be illuminated in red. -
Page 11: Outputting To External Equipment
CONNECTION Outputting to External Equipment • Connect the AV Out of the DVD Player to the Audio In and Video In of your TV with an AV cable. • As default, the player will automatically output the audio/video signals to TV when connected to TV. Ensure your TV is in AV IN mode. VIDEO IN AUDIO IN... -
Page 12: Connecting To Other Equipment
CONNECTION Connecting to Other Equipment Connect earphones. Connect speaker with 3.5mm audio cable (not supplied). • No sound is output from the speakers when the earphone jack is connected. Cautions: Avoid excessive volume levels and listening to sound for a long period of time when using headphones, as this may impair your hearing. -
Page 13: Charging The Battery
CHARGING THE BATTERY • Connect the DC IN jack to power outlet via supplied power adapter. • The LED indicator lights up green when the power is turned on. The LED indicator lights up red when the built-in rechargeable battery is charging. -
Page 14: Dvd Playback
DVD PLAYBACK Basic DVD Playback Note: Make sure the disc cover is closed properly for all operations. Slide the POWER switch to ON position. Press OPEN button to open the DVD disc cover. Hold the edge of the disc to put it in the disc tray with the printed side up. Close disc cover. -
Page 15: Mp3, Mpeg-4, Jpeg Files Playback
MP3, MPEG-4, JPEG FILES PLAYBACK Note: • Make sure the disc cover is closed properly for all operations. • Load an Audio CD disc or a disc with JPEG Images or MP3 Music or MPEG-4 Video fi les. • For audio CDs without playback control, the DVD player starts playback automatically. -
Page 16: Playing Mpeg-4 Videos
MP3, MPEG-4, JPEG FILES PLAYBACK Playing MPEG-4 Videos STOP / 16 /mpeg/Video 01.AVI Filter Video 01 Repeat : Off Video 02 Mode : Normal Video 03 Video 04 Video 05 JPEG Preview Video 06 Video 07 Press Up / Down to highlight a video fi le and then press Play/Sel. -
Page 17: Playing Jpeg Pictures
MP3, MPEG-4, JPEG FILES PLAYBACK Playing JPEG Pictures STOP jpeg/Picture 01.JPG / 16 Filter Picture 01 Repeat : Off Picture 02 Mode : Normal Picture 03 Picture 04 Picture 05 JPEG Preview Picture 06 Picture 07 W:800 H:600 Press Up / Down to highlight a JPEG fi... -
Page 18: The Playback Navigator And Settings
MP3, MPEG-4, JPEG FILES PLAYBACK The Playback Navigator and Settings ElapsedTime Total fi le number Play status Remaining Time 00:00:20 / 00:04:00 Playing fi le / 16 /mp3/Music 02.MP3 File path Filter Music 01 Repeat : Off Music 02 Preview list Mode : Normal Music 03... -
Page 19: Program Playback
MP3, MPEG-4, JPEG FILES PLAYBACK Program Playback Adding fi les to Program List In full stop mode, press Right to enter the right screen of the navigator. Press Up / Down to select Edit mode, then press Play/Sel. to highlight the Edit mode. •... -
Page 20: Osd Setup
OSD SETUP Press Setup to bring up the Setup Menu. Setup Press Up / Down to select a Language : English Language : English Subtitle setting from the Main menus. Audio : English Video : English DVD Menu Press Right to enter the sub- Rating menus. - Page 21 OSD SETUP Main Menu Sub-menu Options Description Video Aspect Ratio 4:3, 16:9 Select the aspect ratio of viewing screen if the disc has more than one aspect ratio. • Select “Aspect Ratio: 4:3” for outputting 4:3 ratio video for a conventional size TV.
-
Page 22: Rating Explanations
OSD SETUP Note 1: Parental Control • A dialog window will appear on the screen when you select Parental control item. Parental control : 8. Adult • Enter 4-digit password and then press Language Set Password Play/Sel.. Enter Password Video •... -
Page 23: View Mode Setup
VIEW MODE SETUP Aspect Ratio Setting Press LCD to bring up the View Mode window. View Mode Aspect Ratio : 16:9 Back Light : On Press Up / Down to select Aspect Ratio. Press Left / Right / Play/Sel. to choose Aspect Ratio: 16:9 or Aspect Ratio: 4:3. -
Page 24: Helpful Hints
HELPFUL HINTS Before requesting service for the DVD Player, check the chart below for a possible cause of the problem you are ex pe ri enc ing. Some simple checkups or a minor adjustment on your part may eliminate the problem and restore proper op er a tion. -
Page 25: Disc Handling And Maintenance
DISC HANDLING AND MAINTENANCE Handling Precautions • Hold the disc by the edges so the surface will not be soiled with fi ngerprints. (A) Fingerprints, dirt and scratches can cause skipping and distortion. • Do not write on the label side with a ball-point pen or other writing utensils. •... -
Page 26: Specification
SPECIFICATION Disc Format DVD, CD, CD-R, CD-RW, JPEG Picture CD, MP3, MPEG-4 Video System NTSC / PAL Video Decompression MPEG-4 LCD Display 9” Wide-Screen Active-Matrix TFT Type Audio: Audio Characteristic 2-Channel Analogue Dolby Digital Decoding Speaker 2 Built-in stereo speaker Terminals: DVD Player AV OUT Socket x 1, Headphone Socketx 1...
