Summary of Contents for XtendLan XL-GDB-102E

  • Page 1 XL-GDB-102Ev2 G.SHDSL .Bis User Manual Version 0.03...
  • Page 2: Table Of Contents

    Tables of Contents INTRODUCTION ..........................3 ............................4 EATURES ..........................4 PECIFICATION ........................... 6 PPLICATIONS GETTING TO KNOW ABOUT THE XL-GDB102E ................7 ........................... 7 RONT ANEL 2.1.1. E1 interface model ........................7 2.1.2. Serial interface model ......................7 2.1.3. Ethernet interface model ......................
  • Page 3 3.4.2. Show Statistic on Serial (V.35) Interface ................23 3.4.3. Show Statistic on Ethernet Interface..................24 SYSTEM SETUP ENU TREE FOR ..................... 25 3.5.1. Sub-Menu tree for SETUP SHDSL ................... 26 3.5.2. Sub-Menu tree for SETUP E1 Interface .................. 27 3.5.3.
  • Page 4 3.7.2. BER Test function ........................42 CONFIGURATION WITH CONSOLE PORT ..................43 .......................... 43 OGIN ROCEDURE INDOW STRUCTURE ........................44 ........................UMMARY ..........................47 ONFIGURATION 4.4.1. Configure NTU Interface ......................48 4.4.2. Configure SHDSL parameters....................49 4.4.3. Configure E1 parameters ....................... 52 4.4.4.
  • Page 5: Introduction

    1. Introduction The G.XL-GDB102E offers three different interface (E1, Serial and Ethernet) connected customers to high-speed TDM services .This series have four models on the following:- E1 interface model : Offers two different ways have connect customers to high-speed TDM services with two G.703 E1 interfaces (Balance 120Ω...
  • Page 6: Features

    1 .1 F ea t ur e s Standard G.shdsl .Bis ITU G.991.2 (2004) supports improved reach/speed and greater interoperability Fast and cost-effective provisioning of traditional frame relay (FR or T-HDLC) or TDM leased line services User existing copper loop infrastructures Can operate back to back connection Efficient single wire pair usage Up to 5.696Mbps symmetric service bit rate...
  • Page 7 LAN Interface ( as Ethernet) • Single Ethernet Interface • 10/100Mpbs Half/Full Duplex, Auto-sensing, Auto-Crossover • Up to 1024 MAC address learning, filtering bridge DSL Timing • Internal • From E1 Recovery (as E1) • From DTE ( as V.35 and Ethernet) Performance Monitoring •...
  • Page 8: Applications

    1 .3 A pp lic a ti o ns...
  • Page 9: Getting To Know About The Xl-Gdb102E

    Getting to know about the XL-GDB102E This chapter shows the front and rear panel and how to install the hardware. 2 .1 F ro n t P an e l 2.1.1. E1 interface model 2.1.2. Serial interface model 2.1.3. Ethernet interface model 2.1.4.
  • Page 10 Front panel can be separated into three parts: LCD display, LED indicator and Keypads. The LCD display can show the status and configuration of device. The local management interface will be done by keypads with this LCD display. The purpose of key pads is to configure the setting or selecting of function on this NTU.
  • Page 11 Data receive in 100M. 100M Green No data receive in 100M. Blink Error collision occurs. No error collision. Mode Green Blink E1 Data tramsmit and receive E1 cable cable connected No E1 cable connected Green Blink Serial Data tramsmit and receive DTE Connected DTE Disconnect Green...
  • Page 12: Rear Panel

    2 .2 R ear P a nel 2.2.1. E1 Interface Model The rear panel of this model is including power switch, power socket, RJ-45 console, RJ-45 G.703, BNC jack for transmitting and receiving and RJ-45 for SHDSL from left to right. Connector Description Power switch.
  • Page 13: Serial (V.35) Interface Model

    2.2.2. Serial (V.35) Interface Model The rear panel of this model is including power switch, power socket, RJ-45 for console cable, DB-25(Female) for V.35 cable and RJ-45 for SHDSL from left to right. Connector Description Power switch. Press 1 for turn on and press 0 for off. 90~240V AC Power socket.
  • Page 14 2.2.3. Ethernet Interface Model The rear panel of this model is including power switch, power socket, RJ-45 for console cable, LAN for Ethernet cable and RJ-45 for SHDSL from left to right. Connector Description Power switch. Press 1 for turn on and press 0 for turn off. 90~240V AC Power socket.
  • Page 15 2.2.4. Three interface in one Model The rear panel of this model is including power switch, power socket, RJ-45 for console cable, LAN for Ethernet cable, RJ-45 G.703, BNC jack for transmitting and receiving, DB-25(Female) for V.35 cable and RJ-45 for SHDSL from left to right. Connector Description Power switch.
  • Page 16: Ethernet Interface

    2 .3 Ins t al lat ion Note: To avoid possible damage to this NTU, do not turn on the product before hardware installation. Plug the power cord in the power socket. Plug the console port in console if you want to configure the NTU with VT100 program of NB or PC.
  • Page 17: E1 Interface

    2.3.1. E1 Interface 2.3.2. V35 Interface...
  • Page 18: Ethernet Interface

    2.3.3. Ethernet Interface Protective earth: The marked lug or terminal should be connected to the building protective earth bus. Before connecting this unit to a power source and connecting or disconnecting any other cable, the protective earth terminals of this unit must be connected to the protective ground conductor of the mains AC power cord.
  • Page 19: Configuration With Keypad And Lcd

    3. Configuration with Keypad and LCD This chapter provides information about configuration your G.XL-GDB102E via front panel LCD display and keypads. 3 .1 K ey Pa d s The product is designed for user-friendly configuration with keypads and LCD display without using PC or NB with VT100 terminal.
  • Page 20: Main Menu Tree

    3 .2 M ain m e nu Tr e e After turning on device, the LCD display will prompt G.XL-GDB102E. Press Enter to enter. There will display some sub-menu of the following. Please notice that Ethernet interface mode haven’t SYSTEM DIAGNOSTIC.
  • Page 21: Menu Tree For Show Status

    3 .3 M en u t r ee for S H OW S T AT U S You can check the status via LCD display. The SHOW STATUS menu tree is as following.
  • Page 23: Menu Tree For Show Statistics

    3 .4 M en u t r ee for S H OW S T AT IST ICS The product can display two kinds of statistics data: Current 15 minutes period and 96 previous 15-minute period of SHDSL performance. (b) Current 24 hour period and 7 previous 24-hour periods of SHDSL performance.
  • Page 24: Show Statistic On E1 Interface

    3.4.1. Show Statistic on E1 Interface...
  • Page 25: Show Statistic On Serial (V.35) Interface

    3.4.2. Show Statistic on Serial (V.35) Interface...
  • Page 26: Show Statistic On Ethernet Interface

    3.4.3. Show Statistic on Ethernet Interface...
  • Page 27: Menu Tree For System Setup

    3 .5 M en u t r ee for S YS T EM SE T UP You can setup five interface mode via LCD display.
  • Page 28: Sub-Menu Tree For Setup Shdsl

    3.5.1. Sub-Menu tree for SETUP SHDSL SETUP SHDSL Selection items SETUP MODE STU-R, STU-C-INTCLK, STU-C-EXTCLK SETUP ANNEX B, F, G SETUP STARTUP MARGIN to 21 SETUP PSD SYM, ASYM The following are commonly used acronyms for SETUP MODE: STU-R RT side, where the clock source is set to external STU-C-INTCLK CO side, where the clock source is set to internal STU-C-EXTCLK...
  • Page 29: Sub-Menu Tree For Setup E1 Interface

    3.5.2. Sub-Menu tree for SETUP E1 Interface SYSTEM SETUP SETUP E1 E1 parameter setting: E1 Items Setting Channel PCM31 PCM31C PCM30 PCM30C FULL Code HDB3 Build Outs 120 ohms 75 ohms...
  • Page 30 Framer Setting: Framer Slot Number First Slot PCM31 1 to 31 1 to 31 PCM31C FAS+CRC4 1 to 31 1 to 31 PCM30 FAS+CAS 1 to 30 1 to 31 (can’t use 16) PCM30C FAS+CAS+CRC4 1 to 30 1 to 31 (can’t use 16) FULL UNFRAMED...
  • Page 31 The first time slot setting: Channel Number of slot 1 slot FULL ----- ----- (UNFRAMED) PCM31 PCM31C 1~10 1~11 1~12 1~13 1~14 1~15 1~16 1~17 1~18 1~19 1~20 1~21 1~22 1~23 1~24 1~25 1~26 1~27 1~28 1~29 1~30 1~31 PCM30 PCM30C...
  • Page 32 1~10 1~11 1~12 1~13 1~14 1~15 1~15,17 1~15,17~18 1~15,17~19 1~15,17~20 1~15,17~21 1~15,17~22 1~15,17~23 1~15,17~24 1~15,17~25 1~15,17~26 1~15,17~27 1~15,17~28 1~15,17~29 1~15,17~30 1~15,17~31...
  • Page 33: Sub-Menu Tree For Setup Series Interface

    3.5.3. Sub-Menu tree for SETUP SERIES Interface SYSTEM SETUP SETUP SERIES...
  • Page 34 Serial interface control signal setting: Serial Items Setting INTERFACE V.35 X.21(RS-530) Nx64K (Rate) 1 ~ 89 (Annex F/G) 1 ~ 36 (AnnexA/B) CLOCK Normal Inverse From DTE From RTS From DTR From DSL DELAY...
  • Page 35: Sub-Menu Tree For Setup Ethernet Interface

    3.5.4. Sub-menu tree for SETUP Ethernet Interface SYSTEM SETUP SET UP ETHERNET If you set Ethernet Auto Negotiation is Enable, the default setting on Duplex is Full and Speed is 100M. If you set Ethernet Auto Negotiation is as Enable, the Duplex and Speed can’t be set up and using auto configuration.
  • Page 36 Table of E1+ Serial interface and E1+Ethernet interface mode (Annex A /B): E1 interface Serial interface Ethernet interface Channel Number of slot 1 Nx64K (Rate) slot FULL ----- ----- (UNFRAMED) PCM31 PCM31C 1~10 1~11 1~12 1~13 1~10 1~14 1~11 1~15 1~12 1~16 1~13...
  • Page 37 1~31 1~35 PCM30 PCM30C 1~10 1~11 1~12 1~13 1~14 1~10 1~15 1~11 1~16 1~12 1~17 1~13 1~18 1~14 1~19 1~15 1~20 1~15,17 1~21 1~15,17~18 1~22 1~15,17~19 1~23 1~15,17~20 1~24 1~15,17~21 1~25 1~15,17~22 1~26 1~15,17~23 1~27 1~15,17~24 1~28 1~15,17~25 1~29 1~15,17~26 1~30 1~15,17~27 1~31...
  • Page 38 Table of E1+ Serial interface and E1+Ethernet interface mode (Annex F /G): E1 interface Serial interface Ethernet interface Channel Number of slot 1 Nx64K (Rate) slot FULL ----- ----- 1~57 (UNFRAMED) PCM31 PCM31C 1~58 1~59 1~60 1~61 1~62 1~63 1~64 1~65 1~66 1~10...
  • Page 39 1~31 1~88 PCM30 PCM30C 1~59 1~60 1~61 1~62 1~63 1~64 1~65 1~66 1~67 1~10 1~68 1~11 1~69 1~12 1~70 1~13 1~71 1~14 1~72 1~15 1~73 1~15,17 1~74 1~15,17~18 1~75 1~15,17~19 1~76 1~15,17~20 1~77 1~15,17~21 1~78 1~15,17~22 1~79 1~15,17~23 1~80 1~15,17~24 1~81 1~15,17~25 1~82...
  • Page 40: Sub - Menu Tree For Reboot System

    3 .6 S ub - me n u t ree fo r RE B OOT S YST E M REBOOT SYSTEM -> * REBOOT * YES -> press ”ENTER” key Some setting must reboot the device after the “Save Configuration”, and then setting items can take effect.
  • Page 41: Sub -Menu Tree For Disgnostic

    3 .7 S ub - Me n u t ree fo r DI S GN O ST IC 3.7.1. Loopback function SYSTEM DIAGNOSTIC DIAG LOOPBACK Note : No SYSTEM DIAGNOSTIC menu on Ethernet Interface Model If the device haven’t connect or under handshake, there will not have farend line, farend payload and V.54.
  • Page 44: Ber Test Function

    3.7.2. BER Test function SYSTEM DIAGNOSTIC DIAG BER TEST This is the internal Bit Error Rate Tester (BERT) for complete testing of local and remote modem and the link quality without any external test equipment. This built-in Bit Error Rate Test generator can generates a standard 2047 (2 -1) test pattern.
  • Page 45: Configuration With Console Port

    4. Configuration with Console Port This chapter will deal with the specifics of configuration and operation of this product via console port with terminal emulation program. The configuration G.XL-GDB102E is performed via a menu-driven embedded software, using a standard ASCII terminal or a PC running a terminal emulation application connected to the rear panel CONSOLE port.
  • Page 46: Window Structure

    Press the SPACE key until the login screen appears. When you see the login screen, you can logon to device. Username use “admin”. When the system prompts you for a password, type “admin” to enter is O.K. 4 .2 Win d ow st r uc t ure After you type the password, there will displays the main menu.
  • Page 47 Above screen capture shows the common structure for all windows used throughout the configuration console terminal. From top to bottom, the window is divided into four major sections. The very top line displays the product name. Next a block of commands is listed where the ">>" symbol indicates the current cursor placeholder.
  • Page 48: Main Menu Summary

    4 .3 M ain M e nu Su m m a r y The main menu is prompt as follow. Menu Title Function Setup Use this menu to setup SHDSL type, SHDSL parameters and E1 parameters or restore factory default setting. Status Use this menu to show SHDSL status, E1 /V.35/Ethernet status and statistics or clear the statistics...
  • Page 49: Configuration

    4 .4 C on fig u ra t ion This section provides information about configuration the XL-GDB102E. Follow the procedures: In main menu, select setup and press [ENTER] or [RIGHT] The screen will prompt as following If you setup the local side, select LocCH and press [ENTER] or [RIGHT]. Otherwise, setup the remote side by select RmtCH.
  • Page 50: Configure Ntu Interface

    4.4.1. Configure NTU Interface If the XL-GDB102E is the three interfaces in one model, it will display five types of interface can select.
  • Page 51: Configure Shdsl Parameters

    Model Interface modes support E1 interface model Serial interface model Serial Ethernet interface model Ethernet Three interface in one model Serial Ethernet E1+Serial E1+Ethernet 4.4.2. Configure SHDSL parameters This section provide to setup SHDSL parameters: SHDSL Mode, Annex type, Psd Mask, SNR margin.
  • Page 52 For setting the SHDSL Annex type, move the cursor to Annex and press [ENTER]. Select the annex type by using [TAB] key. The Annex have four mode: A, B, F and G. For configuring SHDSL PSD, move the cursor to psd and press [ENTER]. Select the parameter via [TAB] key.
  • Page 53 For setting SHDSL Margin, move the cursor to margin and press [ENTER]. Select the margin via [TAB] key and key in the Next margin. SNR margin is an index of line connection. You can see the actual SNR margin in STATUS SHDSL.
  • Page 54: Configure E1 Parameters

    4.4.3. Configure E1 parameters When using on E1 interface, select the E1 item and press [ENTER] or [RIGHT]. The E1 settings include the Channel (frame mode), line code, AIS and build out settings. Setup E1 Parameter, Channel...
  • Page 55 Framing is required to recover the channelized E1. In transparent operation, the framing is configured as Unframed. In this case the G.SHDSL framer must be set to Nx64 with N=32. For any framing such as FAS or CAS, the G.SHDSL framer must be set to E1, then the E1 framing here may be set accordingly.
  • Page 56 Time Slot 9 ~ 30 1408k Maximun Data Rate 2048kbps ITU 991.2 (2004) (G.SHDSL .Bis) supports data rate up to 56964Kbps, but G.703 (E1) only supports data rate of 2048kbps so the maximum data rate of SHDSL line, connected with DCEs, depends on data rate of E1, 2048kbps.
  • Page 57 For fractional E1, FE1, the data rate is from 64k, N=1, to 1984k, N=31, according to the E1 frame. If the E1 frame is FAS or FAS+CRC4, there are 1~31 available time slot for use data. If the data rate of SHDSL line set to be 512k, the time slot number is 8 and first time slot number is 1.
  • Page 58 Time Slot 9 ~ 30 Data Data Data Data Data Data Data Data 1408k The First Time Slot setting of FAS and FAS+ CRC4 have to follow the rule: RULE First Time Slot ≦ 31- Time Slot Number Using E1 frame of FAS+CAS or FAS+CAS+CRC4, the FAS will occupy Time Slot 0 and CAS Time Slot 16.
  • Page 59 Data Data Data Data Data Data Data Data Data Data Data 1408k...
  • Page 60 Setup E1 Parameter, Line Code The G.XL-GDB102E supports two different line codings. HDB3 is the most popular and preferred line coding and is also the default setting. AMI line coding is also selectable. In this line coding, the transmitter substitutes a deliberate bipolar violation when excessive zeros in the data stream are detected.
  • Page 61 Setup E1 Parameter, AIS AIS (Alarm Indication Signal) is a method to inform the remote connection that there is a signal or sync problem with the E1. AIS is only valid in framed mode E1, not in Unframed E1. The setting here of AIS enabled (on) or not (off) and is for testing with AIS.
  • Page 62 Setup E1 Parameter, Build Out The XL-GDB102E can support both unbalanced E1 at 75 ohms and balanced E1 at 120 ohms. The settings for impedance are made here under the build out menu setting.
  • Page 63: Configure Serial Parameters

    4.4.4. Configure Serial parameters When using on Serial interface, select the Serial item and press [ENTER] or [RIGHT]. The serial settings include the data rate, clocking and handshaking lines setup. Setup Serial Parameter, Interface There have two interfaces: V.35 and RS-530(X.21) can be setup. Setup Serial Parameter, Data Rate...
  • Page 64 For Annex A and B, the rate can be adjusted in increments of 64kbps from 64kbps to 2304kbps (N=1~36). For Annex F and G, the rate can be adjusted in increments of 64kbps from 64kbps to 5696kbps (N=1~89). Setup Serial Parameter, Clock Polarity The data port clock polarity may be adjusted to solve some rare clocking issues.
  • Page 65 The behavior of the RTS (Request To Send) signal may be set in one of two ways. When set 'on', the RTS signal is always forced high (on, positive voltage or SPACE), when set 'from DTE' the RTS signal will follow the DTE's condition. The default setting for RTS is on. Setup Serial Parameter, CTS The behavior of the CTS (Clear To Send) signal may be set in one of three ways.
  • Page 66 Setup Serial Parameter, DSR The behavior of the DSR (Data Set Ready) signal may be set in one of three ways. When set 'on', the DSR signal is always forced high (on, positive voltage or SPACE), when set 'off' the signal is always forced low (off, negative voltage or MARK), or DSR will follow DTR (Data Terminal Ready) condition of 'on' for DTR on or 'off' for DTR off.
  • Page 67: Configure Ethernet Parameter

    Setup Serial Parameter, Delay The delay setting is used to cause a delay for CTS to follow RTS. The delay setting may be set from 0 to 3 milliseconds. The default setting is 3 milliseconds. 4.4.5. Configure Ethernet parameter When using on Ethernet interface mode, select the Ethernet item and press [ENTER] or [RIGHT]. The Ethernet settings include the data rate, negotiation, duplex the speed.
  • Page 68 Setup Interface Parameter, Data Rate For Annex A and B, the rate can be adjusted in increments of 64kbps from 64bps to 2304kbps (N=1~36). For Annex F and G, the rate can be adjusted in increments of 64kbps from 64bps to 5696kbps (N=1~89).
  • Page 69 Setup Interface Parameter, Duplex When auto negotiation setup to disable, there have select on duplex mode: Full-Duplex and Half-Duplex. Setup Interface Parameter, Speed When auto negotiation setup to disable, there have select on speed setting: 10M and 100M. If auto negotiation setup to Enable, the items Duplex and Speed can’t been set. The message will display “Ethernet is in auto negotiate”.
  • Page 70: Remote Configuration

    4.4.6. Remote configuration You can set the “Enable/Disable function” to let the side remote side can configure parameters to this device remotely. 4.4.7. Restore factory default The G.XL-GDB102E can have all settings restored to their original factory settings simply by going to the setting menu, selecting the Default item, and then press ENTER.
  • Page 71: Reboot

    4 .5 R eb o ot In main menu, move the cursor to reboot and press [ENTER]. The device will reboot after confirming. After the reboot operation have finished, RAM test are starting again.
  • Page 72: View The System Status

    4 .6 V iew t h e s ys t e m s t at u s You can use the status command to view the status of SHDSL, E1, Serial and Interface as well as statistic and clear the statistic log. Select status and press [ENTER]. Select SHDSL command to show the status of SHDSL.
  • Page 73 The SHDSL status will display a real-time status of the DSL on local side and remote side if connected. The screen is refreshed about every 1.5 seconds. The monitoring window displays the DSL line parameters, such as SNR margin and attenuation. The lower half of the window displays the loopback and BER test status.
  • Page 74 4 .7 V iew t h e S ta t is t ic Select Loc_statistic command to show the statistic information in 15 minutes or 24 hour via [TAB] to choose. The statistics display window will display performance monitor data for the selected interval (15 minutes or 24 hours).
  • Page 75 For E1 Interface model, there have SHDSL and E1 item. View the performance monitor data for the selected interval 15 minutes: View the performance monitor data for the selected interval 7days:...
  • Page 76 For Serial and Ethernet Interface model, there have only SHDSL item. View the performance monitor data for the selected interval 15 minutes: View the performance monitor data for the selected interval 7 days:...
  • Page 77 To clear the statistic log file, select clear and press [ENTER]. If you want to show the remote side’s statistics, please use the Rmt-statistics function as the following.
  • Page 78 The following are commonly used acronyms: Number of errored seconds in which one or more CRC (Cyclic Redundancy Check) error events occurred during the current interval. This value is updated every time. Number of unavailable seconds in which a failed signal occurred during the current interval.
  • Page 79: View System Configuration

    4 .8 V iew S y st e m C on fig ur a ti o n By using show command, you can view the system configuring. Select show and press [ENTER] or [RIGHT]. To show system information, please select system and press [ENTER] or [RIGHT]. The screen will prompt the system information.
  • Page 80 Our cursor is already on the System command, so press ENTER and the following screen will display the general system information. Most of the information on this screen is either self explanatory or it is simply irrelevant for the end user. However, two items, the Kernel (SW Version)and FPGA (Field Programmable Gate Array) version will give the software and hardware versions respectively of NTU.
  • Page 81 For Serial interface mode: For Ethernet interface mode:...
  • Page 82 For E1 and Serial interface mode: For E1 and Ethernet interface mode:...
  • Page 83 To show the system script file, please select Script and press [ENTER] or [RIGHT]. The screen will prompt the configuration in script type. For E1 interface mode:...
  • Page 84 For Serial interface mode: For Ethernet interface mode:...
  • Page 85 For E1 and Serial interface mode: For E1 and Ethernet interface mode:...
  • Page 86: Upgrade

    4 .9 U pg r ade This section will introduce how to upgrade the kernel and FPGA code of G.XL-GDB102E. Select upgrade in main menu and press [ENTER] or [RIGHT]. Please notice that when you use Remote Upgrade feature. It means you can use those feature to update firmware to remote side.
  • Page 87 Click Send file in terminal access program, hyper terminal, to send the file. Make sure the sending protocol is Xmodem. Select the source file in window and press OK. Once the upgrade is complete, there required to male the final confirmation to erase and re-write the flash with new code.
  • Page 88 When it was upgrading, you can see as following:...
  • Page 89 This is the remote upgrade feature: Before upgrading the NTU, you must have the Kernel code and FPGA code in your computer. WARNING!!: Do not allow any interruption of power during the erase and re-write operation or the Flash will be left in an unknown state and the device will no longer be able to function. The device must then be returned to the factory for repair.
  • Page 90: Diagnostic

    4 .10 Di a gn o st ic The diagnostic facility allows you to test the different aspects of your G.XL-GDB102E to determine if it is working properly. Select diag and press [ENTER] or [RIGHT]. Loopback can test whether the NTU is properly worked with the connection device.
  • Page 91 For E1 Interface model as CPE side, there have: Local Digital, remote line, remote payload, farend line and farend payload. For Serial Interface model as CPE side, there have: Local Digital, remote line, remote payload, farend line, farend payload and V.54. If the device haven’t connect or under handshake, there will not have farend line, farend payload and V.54.There are no diagnostic function on Ethernet interface model.
  • Page 92 Loopback Define E1 vs E1 STU-C (E1) STU-R (E1) shdsl shdsl La Lc STU-C (E1) STU-R (E1) shdsl shdsl Lc La Local Digital Local Remote Line Remote Payload Line Payload Loopback Define Serial vs Serial STU-C (Serial) STU-R (Serial) V.35 shdsl V.35 shdsl...
  • Page 93 shdsl V.35 Lc La Local Digital Local Remote Line Remote Payload Line Payload Lf V.54 Loopback Define Fractional E1 vs V35 STU-C (E1) STU-R (V35) shdsl FPGA shdsl La Lc STU-C (V35) STU-R (E1) FPGA shdsl shdsl Lc La Local Digital Local Remote...
  • Page 94 Line Payload...
  • Page 95 The product supports Bit Error Rate Testing (BERT). To configure the BERT, move the cursor to BerTest and press [ENTER] or [RIGHT].
  • Page 96 The BER Test screen is as following: The G.SHDSL Bis NTU includes an internal Bit Error Rate Tester (BERT) for complete testing of local and remote modem and the link quality without any need for an external test equipment. This built-in Bit Error Rate Test generator can generates a standard 2047 (2 -1) test pattern.
  • Page 97: Exit

    4 .11 E xit For exiting the system without saving any configuration, you can use exit command to exit. Select exit and press [ENTER] or [RIGHT]. Answer y(es) to confirm. After press [ENTER], the system will be disconnected. When the system have disconnected, we can see the close screen. You can press Space key to restart.
  • Page 98 The new login screen will show again, you can type username and password again to enter.
  • Page 99: Appendix

    5. Appendix 5 .1 A bb r ev iat ion Alarm Indication Signal Alternate mark inversion ASYM Asymmetric Asynchronous Transfer Mode B8ZS Bipolar with 8 zero substitution Bit error rate BERT Bit Error Rate Tester Bayonet Nut Coupling Bayonet Neill-Concelman Barrel Nut Connector, Bayonet Nipple Connector Bayonet Navy Connector...
  • Page 100 ETSI European Telecommunications Standardization Institute Frame alignment signal Frame Check Sequence HDB3 High-Density Bipolar of order 3 Header error check Interface International Telecommunication Union ITU-T ITU-Telecommunication Standardization Sector Line Build Out Line Interface Unit Loss of Connection Loss of frame Loss of signal LOSW Loss of synchronization word...
  • Page 101 STU-C SHDSL Terminal Unit CO side STU-R SHDSL Terminal Unit RT side STU-C-INTCLK STU-C internal clock STU-R-EXTCLK STU-R external clock Symmetric SYNC Synchronization TC-PAM Trellis Coded Pulse Amplitude Modulation Time Division Multiplexing TPS-TC Transmission Protocol Specific TC layer Transmitter TX POWER Transmission power Unavailable second User interface...
  • Page 102: Console Cable

    5 .2 C on s ole C a ble DB9 vs. RJ45 Cable wire connection DB9 (Female) RJ-45 The table below displays Serial Interface Pin Assignments for the DCE Mode. Console Connector (RJ-45) The Console Port interface is a 8 position Modular Jack. The table below displays the pin out assignments.
  • Page 103 5 .3 S er ial In t er face P in As s ig n me n ts The table below displays Serial Interface Pin Assignments for the DCE Mode. Function Abbrev. Direction DB-25* V.35 V.36 X.21 Frame Ground Transmit Data Input Receive Data Output...
  • Page 104: Db25(M) Vs . M.34(M) Cable

    5 .4 D B2 5 (M) v s . M .3 4 ( M ) C ab le DB25 (M) vs. M.34 (M) Cable (V.35) D B 2 5 M . 3 4...
  • Page 105: E1 Cable

    5 .5 E 1 C ab le G.703 120Ω Connector (RJ-45) The 120Ω E1 Port interface is a 8 position modular jack, the following table displays the pin our assignments. Pin Number Description Figure E1 interface receive pair-ring E1 interface receive pair-tip No connection E1 interface transmit pair-ring E1 interface transmit pair-tip...
