EXPLODED VIEW DIAGRAM
401
402
403
406
407
409
411
screw 1.4x2.5
plastite ( 10x)
5 - 1
screw 1.7x6 CR
plastite (2x)
412
413
417
418
404
423
424
426
408
429
5 - 1
MECHANICAL PARTSLIST - CABINET
401 3140 117 67260
401 3140 117 64340
401 3140 117 66930
402 3140 117 67310
414
402 3140 117 66980
416
403 3140 117 64390
404 3140 117 66480
406 3140 111 22560
407 3140 110 51740
408 3140 114 47480
409 3140 113 33150
411 3140 117 67250
411 3140 117 64330
419
411 3140 117 66920
412 3140 117 66990
412 3140 117 64410
413 3140 111 22610
414 3140 117 67000
414 3140 117 64420
416 3140 117 67010
421
416 3140 117 64430
417 3140 117 66940
422
417 3140 117 64350
418 3140 111 22620
419 3140 111 22640
421 2422 549 45374
422 3140 114 47580
423 3140 111 22580
424 3140 111 22570
426 3140 111 22600
427 3140 117 67350
427 3140 117 64360
428 3140 114 49360
429 3140 117 66910
429 3140 117 66470
Note: Only these parts mentioned in the list are normal service parts.
427
screw 1.7x9 CR
plastite (3x)
428
PANEL-ASSY-1 (red)
PANEL-ASSY-1 (grey)
PANEL-ASSY-1 (blue)
KEY-PLAY
KEY-PLAY (only for blue)
CD KEYSET
CD KEY-STOP
FRAME-LCD
LCD
ZEBRASTRIP
MEMBRANE KEYBOARD
DOOR-CD-ASSY-1 (red)
DOOR-CD-ASSY-1 (grey)
DOOR-CD-ASSY-1 (blue)
SLIDER-DOOR-OPEN
SLIDER-DOOR-OPEN (only for grey)
SPRING-SLIDER-OPEN
KNOB-VOLUME
KNOB-VOLUME (only for grey)
KNOB-DBB
KNOB-DBB (only for grey)
CABINET-ASSY-1
CABINET-ASSY-1 (only for grey)
SPRING-BATTERY-SET, +/-
SPRING-DOOR-OPEN
CD DRIVE DA50
DAMPER-AX5203
SPRING BATTERY, -VE
SPRING BATTERY, +VE
SPRING BATTERY CHARGE
BOTTOM-ASSY-1
BOTTOM-ASSY-1 (only for grey)
RUBBER-FOOT
DOOR-BATTERY-2A
DOOR-BATTERY-2A (only for grey)
