- Page 1 X – 6 SQUARED K 021 KIT INSTRUCTION MANUAL Version 1.0 X – 6 SQUARED KIT K021 Instructions v1.0 First Things Page 1...
- Page 2 CONTENTS First Things…………………………………….. 3 A Front Arms & Hubs………………………… 5 B Complete The Front End…………………. 12 C Differential…………………………………. 20 D Transmission………………………………. 25 E Transmission Installation…………………. 32 F Build the C-CVDs…………………………. 38 G Rear Control Arms……………………….. 43 Build The Shocks …………………………….. 48 H Rear Tower, Shocks,Turnbuckles……….
- Page 3 X – 6 SQUARED ASSEMBLY INSTRUCTIONS FIRST THINGS FIRST A) ASSUMPTIONS These instructions assume several things: 1. You have at least some experience building R/C cars. These instructions are not written for a first-timer. 2. You have the usual assortment of R/C tools. If you do not meet both assumptions above, please contact us.
- Page 4 SOME IMPORTANT INFORMATION This is the first time we have made the entire Kit – always before we have made Conversion Kits. We know we are not perfect. If you experience the slightest difficulty assembling your X – 6 Squared – if you have trouble with an instruction or if something does not fit properly –...
