Valor Fires 954 Installer And Owner Manual

Inset live fuel effect gas fire
Hide thumbs Also See for 954:
Table of Contents

Advertisement

Quick Links

See also: Installer and Owner Manual
INSTALLER AND OWNER GUIDE
Model 954
Inset live fuel effect gas fire
Incorporating the VALOR FIRES
Fitted with one of the following fascia.
BROOKLYN, CHIC, ENVY, HERITAGE,
LUXOR, MOONLIGHT, OPULENT
WESTMINSTER SLIMLINE.
(G.C. Number 32-032-69)
We trust that this guide gives
sufficient details to enable this
appliance to be installed, operated
and maintained satisfactorily.
However, if further information is
required, our
Valor Fires Technical Helpline will
be pleased to help.
Telephone 08706 061 065 (National
call rates apply in the United
Kingdom).
In the Republic of Ireland
Telephone 0044 8706 061 065.
INSTALLER: Please leave this guide with the owner
©
Baxi Heating U.K. Limited 2007.
5129520/02
CONTROL
or
