- Page 1 04MM-MMC-01 USER MANUAL HDMI Multimedia Converter Enjoy the vivid world! REMARK Manufacturer does not make any commitment to update the information contained herein.
- Page 2 Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. The products are designed to make your A/V device use more convenient, comfortable, productive and cost-efficient.
- Page 3 l One Switch Key at the front panel and the other Switch key at the rear panel, the two key have the same function that can do switch at the input video signal sources. l DC5V/2A power supply PACKAGE CONTENTS: 1、...
- Page 4 MHL: MHL input (can charge for MHL devices) External IR receiver jack SOURCE: Source selection key HDMI OUT DC 5V FIG.1.1 Left Panel View FIG.1.2 Right Panel View USB: USB2.0 interface (pass-through port) : Telephone (pass-through port) HDMI OUT: HDMI output port : Ethernet (pass-through port) DC 5V: 5V DC in jack Multimedia Converter...
- Page 5 FIG.1.4 Remote Panel View OPERATIONG AND CONNECTION : 1. Connect one cable from each display (monitor or projector) into the converter HDMI output. 2. Plug the network cable, telephone line and USB cable both sides of the converter. 3. Connect 5V power supply to the switcher and inserted into the power socket. 4.
- Page 6 Camera 7. After In the TV menu settings with the MHL DEVICE synchronization, you can use the TV remote controller to control mobile device and switch signal source channel selection. But it requests the TV that can support the CEC function and mobile device can support RCP function. For details, please talk with TV or mobile device manufacturers to confirm.
- Page 7 SPECIFICATIONS: HDMI input resolution ………………………………24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i VGA input resolution..…………….……..…………….……..…………….……up to 1920 x 1080 @60Hz HDMI output resolution ……………………………………………………………………………up to 1080P/60Hz HDMI video color format ……………………………………………………………24bit/deep color 30bit/36bit/48bit HDMI audio format……………………………………DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD MHL pixel clock rate (24-bit mode) …………….…….……………….…75MHz（8bit 1080i/720P 60Hz） MHL pixel clock rate (Packed Pixel mode) …………….…….……150MHz（8bit 1080i 60Hz YCC422） Max bandwidth…………………………………………………………………….…….….…………225MHz Max baud rate……………….…….………………….……………………………….…….………...
- Page 8 Notes: Pls use the machine as the instruction listed to keep the long use lifetime of the machine. 1、 The machine should be placed at the spot far from the Damp, High-Temperature, Dusty, Erosive, and oxidative environment. 2、 All parts will be free from the strong shake, hit, fall. 3、...
