SERVICE MANUAL
1
Order No.Ref0908S006V0
Refrigerator
HRF-265F
MODEL:
WARNING
This service information is designed for experienced repair technicians only and is not designed for use by the general public. It
dose not contain warnings and cautions to advice non-technical individuals of potential dangers in attempting to service a product.
Product powered by electricity should by serviced or repaired only by experienced professional technicians. Any attempt to service
or repair the product or products dealt with in this service information by anyone else could result in serious injury or death.
2009(HAIER ELECTRICAL APPLIANCES COR. LTD)
All right reserved. Unauthorized copying and distribution is a violation of law
Advertisement
Table of Contents
Related Manuals for Haier HRF-265F
Summary of Contents for Haier HRF-265F
- Page 1 Product powered by electricity should by serviced or repaired only by experienced professional technicians. Any attempt to service or repair the product or products dealt with in this service information by anyone else could result in serious injury or death. 2009(HAIER ELECTRICAL APPLIANCES COR. LTD) All right reserved. Unauthorized copying and distribution is a violation of law...
-
Page 2: Table Of Contents
SERVICE MANUAL Issue 20090827 Rev. Ref0908S006V0 HRF-265F Model: Contents Table of Contents ·········································································································· 2 1. General Information ·································································································· 3 1-1. General guideline ······························································································· 1-2. Insurance test ····································································································· 1-3. How to read this Service Manual········································································ 2. Product Feature ········································································································ 5 2-1. Specifications ·····································································································... -
Page 3: General Information
SERVICE MANUAL Issue 20090827 Rev. Ref0908S006V0 HRF-265F Model:HRF-265F Chapter 1 General Information 1-1. General Guidelines When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or damaged by the short circuit. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly installed. - Page 4 SERVICE MANUAL Issue 20090827 Rev. Ref0908S006V0 HRF-265F Model: Photo used in this manual The illustration and photos used in this Manual may not base on the final design of products, which may differ from your products in some way. 1-3. How to read this Service Manual 1-3-1.
-
Page 5: Product Feature
SERVICE MANUAL Issue 20090827 Rev. Ref0908S006V0 HRF-265F Model: Chapter 2 Product Feature 2-1. SPECIFICATIONS HRF-265F Models Sketch Product description (Refrigerator/Freezer) Refrigerator Type of appliance (FS= freestanding/BI= built-in) Type of cooling system(NF=no frost/ S=static) Climate class* Freezer compartment / Star rating... - Page 6 SERVICE MANUAL Issue 20090827 Rev. Ref0908S006V0 HRF-265F Model: Colors: W=white G=silver gray SS=stainless steel F= flat / R= rounded / S= streamline Inside colour Compartments number n° Bottle compartment n° Hinged (r =right l =left) / reversible reversible Shelves: Number...
-
Page 7: External Views
SERVICE MANUAL Issue 20090827 Rev. Ref0908S006V0 HRF-265F Model: 2-2. External views Control panel Lamp Food shelf Fresh food container Drawers Low bottle holder cover Low bottle holder Small bottle holder cover Small bottle holder High bottle holder... -
Page 8: Product Dimensions
SERVICE MANUAL Issue 20090827 Rev. Ref0908S006V0 HRF-265F Model: 2-3. Product Dimensions letter remark value 1773 1776-1782... -
Page 9: Build-In Installing
SERVICE MANUAL Issue 20090827 Rev. Ref0908S006V0 HRF-265F Model: Chapter 3 Installation and Disassembly 3-1Build-in Installing 1. Ensure that the doors of the kitchen unit and the refrigerator are of the same opening direction. (Take the right-opening door as an example) 2. - Page 10 SERVICE MANUAL Issue 20090827 Rev. Ref0908S006V0 HRF-265F Model: Installation instruction and ventilation requirements Location Before installation It is advisable that your appliance is only installed in After delivery, wait for eight hours before a location where the ambient temperature of the connecting the appliance to your mains supply.
-
Page 11: Changing Door Open Direction
SERVICE MANUAL Issue 20090827 Rev. Ref0908S006V0 HRF-265F Model: 3-2 Changing Door open direction 1. Firmly hold the refrigerator door and remove Lower hinge thescrews from the right lower hinge. Lower pivot pin Remove the doorand place aside. Remove Lower pivot pin hole... -
Page 12: Control And Display System
SERVICE MANUAL Issue 20090827 Rev. Ref0908S006V0 HRF-265F Model: Chapter 4 Control and display system 4-1. Control and display panel When refrigerator is connected a power source, the green lamp (E) and the red over temp warning lamp (G) illuminate. B. Temperature setting E. -
Page 13: Sensor Positions
SERVICE MANUAL Issue 20090827 Rev. Ref0908S006V0 HRF-265F Model: Temperature sensors are installed in the refrigerator and the freezer. The red warning lamp will blink if problems occur with the refrigerator temperature sensor, please check and repair connections of sensor. 4-2 Sensor positions... -
Page 14: System Flow Principle
SERVICE MANUAL Issue 20090827 Rev. Ref0908S006V0 HRF-265F Model: Chapter 5 System flow principle 5-1. Refrigeration flow chart Principle diagram and description of the refrigeration cycle The refrigerating system of frosting-free dual-system refrigerator belongs to the category of dual circulating system. It is formed by a single system. The refrigerant flows in the sequence:1->2->3->4->5->6->8.The motor for frosting-free by some other controlling functions. -
Page 15: Circuit Diagram
SERVICE MANUAL Issue 20090827 Rev. Ref0908S006V0 HRF-265F Model: Chapter 6 Circuit diagram 6-1. Circuit diagram 6-2. PCB connect diagram brown... -
Page 16: Trouble Shooting
SERVICE MANUAL Issue 20090827 Rev. Ref0908S006V0 HRF-265F Model: Chapter 7 Trouble shooting 7-1. Normal phenomena In a domestic refrigerator, there is not only a complicated electric control system, but also a refrigerating system that is difficult to discern whether it is in a good working condition. Both the systems are related and affect each other. -
Page 17: Remedies
SERVICE MANUAL Issue 20090827 Rev. Ref0908S006V0 HRF-265F Model: 7-2 Common Troubles in Refrigerators and Their Remedies Causes for troubles occurring in refrigerators are closely related to the quality of components and workmanship in assembling by manufacturers as whether refrigerators are properly used and maintained .The parameters generally used to express the working conditions of a refrigerator... - Page 18 SERVICE MANUAL Issue 20090827 Rev. Ref0908S006V0 HRF-265F Model: During the normal operation of compressor ,a slight and uniform hum sound due to undulation of electric current can be heard generally ,this is a normal phenomenon .However ,if it sounds like “tong ,tong …”,i.e., an impact sound inside the compressor ,this means that a large quantity of wet...
- Page 19 SERVICE MANUAL Issue 20090827 Rev. Ref0908S006V0 HRF-265F Model: make a hasty conclusion based on only one abnormal phenomenon .It is advisable to find out two or more abnormal phenomenon ,or conduct troubleshooting comprehensively with the aid of instruments or other ways ,because several kinds of troubles may share a common abnormal phenomenon ,and two or more abnormal phenomena may occur simultaneously due to a certain trouble .With this method ,you can reject some suspicious troubles and finally make a correct...
- Page 20 SERVICE MANUAL Issue 20090827 Rev. Ref0908S006V0 HRF-265F Model: current of the compressor rises ,loose frost forms on the evaporator ,the refrigerator temperature drops slowly ,and frost appears on the gas return tube . b) In case excessive refrigerant has been charged, the liquid refrigerant that cannot evaporates in the evaporator will return to the compressor, and thus a phenomenon of “liquid striking”...
- Page 21 SERVICE MANUAL Issue 20090827 Rev. Ref0908S006V0 HRF-265F Model: If a direct cooling refrigerator is to be used for a prolonged period of time ,be sure to defrost its evaporator regularly ;if you fail to do so ,the frost layer on the evaporator tubing will become thicker and thicker .Heat conduction will be severely affected when the whole tubing is wrapped with a...
- Page 22 SERVICE MANUAL Issue 20090827 Rev. Ref0908S006V0 HRF-265F Model: 7-3-2 No Refrigerating The phenomenon that the compressor runs normally, but no frost (or only a little frost) appears on the evaporator, and the refrigerator temperature does not drop down is called “no refrigerating”. There are many causes for this trouble and it is relatively complicated, too.
- Page 23 SERVICE MANUAL Issue 20090827 Rev. Ref0908S006V0 HRF-265F Model: caused by ice clogging . Remedy If there is too much moisture in the refrigerating system, it is advisable to release the refrigerant, purge the tubing with nitrogen, and then charge the system with the filtered refrigerant. However, the...
- Page 24 SERVICE MANUAL Issue 20090827 Rev. Ref0908S006V0 HRF-265F Model: It is quite difficult to differentiate this trouble from others because they often have similar symptoms. In repairing, firstly, hear attentively if there is some abnormal sound coming from the compressor (sometimes , the broken pieces of valve block may strike against the cylinder), and feel the compressor casing with your hand to ascertain whether it is too hot, this is also helpful to the troubleshooting;...
- Page 25 SERVICE MANUAL Issue 20090827 Rev. Ref0908S006V0 HRF-265F Model: one is that the air has been sucked into the system when repairing due to carelessness, or it has not been purged out totally when evacuating the system; the other is that there are leak points at the low pressure end of the refrigerating system.
- Page 26 SERVICE MANUAL Issue 20090827 Rev. Ref0908S006V0 HRF-265F Model: 7-3-4 Compressor could not be start In case the compressor cannot be started, you must find out the origins of this trouble through checkup step by step, because probably there are many causes, including those electrical and mechanical.
- Page 27 SERVICE MANUAL Issue 20090827 Rev. Ref0908S006V0 HRF-265F Model: be preliminarily determine that temperature sensing agent has leaked out, and it must be replaced with a new thermostat. 4) Motor troubles and other electric faults a) Motor windings have been burned or short-circuited between turns 7-3-5 Compressor won’t stop...
- Page 28 SERVICE MANUAL Issue 20090827 Rev. Ref0908S006V0 HRF-265F Model: Analysis of Trouble When the heat-insulation layer inside the case body deteriorates or the door seal is not closely touches the door frame, the temperature in the refrigerator will rise and makes the compressor running continuously.
- Page 29 SERVICE MANUAL Issue 20090827 Rev. Ref0908S006V0 HRF-265F Model: noise during its operation . b) Leveling screws not properly adjusted If the leveling screws on refrigerator legs have not been adjusted properly, vibration and noise will still occur even if the refrigerator has been placed on a level ground.
- Page 30 SERVICE MANUAL Issue 20090827 Rev. Ref0908S006V0 HRF-265F Model: Sincere forever Haier Group Haier Industrial Park, No.1, Haier Road 266101, Qingdao, China http://www.haier.com...
