62532 (EN649)
Ethernet Adapter
INSTALLATION AND OPERATING
INSTRUCTIONS
For sales and Service in
Corporate Office:
For sales and service in Europe and
North America contact:
3651 Walnut Avenue,
Asia contact:
ESD Systems.com
Chino, CA 91710
OK International - European Headquarters
www.esdsystems.com
Phone: (909) 627-8178
Eagle Close, Chandlers Ford,
sales@esdsystems.com
Fax (909) 627-7449
Hampshire, SO53 4NF U.K. England
Phone: 508-485-7390
http://www.okintl.com/locations.htm
Fax: 508-480-0257
Tel: +44 (0)23 8048 9100
Fax: +44 (0)23 8048 9109
TB-6108 Page 1 of 9
Revision 07/05
© 2005 DESCO INDUSTRIES INC.
Employee Owned
Advertisement
Table of Contents
Related Manuals for Semtronics 62532
Summary of Contents for Semtronics 62532
- Page 1 62532 (EN649) Ethernet Adapter INSTALLATION AND OPERATING INSTRUCTIONS For sales and Service in Corporate Office: For sales and service in Europe and North America contact: 3651 Walnut Avenue, Asia contact: ESD Systems.com Chino, CA 91710 OK International - European Headquarters www.esdsystems.com...
- Page 2 Semtronic’s 62580 and 62581 Smartlog X3 from anywhere within the LAN or from any location in the world. By using the Semtronics 62532, the Smartlog X3 can be mounted anywhere in the facility without the use of a dictated PC where a network port is accessible.
- Page 3 Operating: 2.4km, 8000ft Storage: 9.1km, 30000ft Note: If operating unit above 2.4km or 8000ft, decrease the operating temperature rating by 1 degree for every 1000ft. Figure 1. Bottom View Figure 2. Top View TB-6108 Page 3 of 9 Revision 07/05 ©...
- Page 4 Current RS-232 Configuration (Use only when DB25 connector is labeled RS-232) Figure 3. Connection Setup TB-6108 Page 4 of 9 Revision 07/05 © 2005 DESCO INDUSTRIES INC. Employee Owned...
-
Page 5: Hardware Setup
Previous RS-485 configuration (Old configuration, no label on DB25) Figure 4. Connection Setup A. Hardware Setup 1. Insert DB25 serial adapter to female DCE DB25 serial port of the 62532 Ethernet adapter. 2. Connect cable from RJ11 jack of serial adapter to RS-485 port (left RJ11 port) of Smartlog X3 (Refer to Figure 4). -
Page 6: Assigning Ip Address
3. On the same LAN connection, you’re going to need a PC to set and program the 62532. Go to your Start icon in Taskbar of Windows®. Go to Run and type in CMD and hit enter. This should take you to the Command Prompt. Type in CD\ and hit enter to get to the root directory. - Page 7 Gate Address: Enter the Gate address If applicable. Enter N and hit enter if you are going to use the 62532 on the same LAN as the PC used to poll the data. For remote access not within the locate LAN,...
- Page 8 enter Y and enter the Gateway IP address, your IT department can supply you with the appropriate Gateway IP address. c. Netmask: Number of bits for host 11. Netmask defines the number of bits taken from the IP address that are assigned for the host sections. d.
- Page 9 PC system isn’t using com 3. 2. Click on Add IP • Enter the IP address that was assigned to the Ethernet adapter 62532 in the box Host. • Subtract 11000 from Port No. to get TCP Port, refer to 8. Enter 1 for Channel 1 Configuration.
-
Page 10: Technical Support
Any unit under warranty should be shipped prepaid to the Semtronics factory. Warranty replacements will take approximately two weeks. If your unit is out of warranty, Semtronics will quote repair charges necessary to bring your unit up to factory standards. Call Customer Service at 909-627-8178 for proper shipping instructions and address.
