Service Manual
TOP NEXT
ORDER NO.DSD0306005C1
B24
DVD Video Recorder
DMR-E80HP
DMR-E80HPC
Colour
(S).......................Silver Type
Power supply:
Power consumption:
Recording system:
Optical pick-up:
Recordable discs:
Recording time:
(Using 4.7 GB disc):
(Using built-in HDD):
Region number:
Discs played:
11/18/2008
Specifications
AC120 V, 60 Hz
35 W
DVD video recording standards (DVD-RAM),
DVD video standards (DVD-R)
System with 1 lens, 2 integration units (662 nm wavelength for DVDs, 790 nm wavelength for CDs)
12 cm 4.7 GB DVD-RAM discs
12 cm 9.4 GB DVD-RAM discs
8 cm 2.8 GB DVD-RAM discs
12 cm 4.7 GB DVD-R discs
(for General Ver. 2.0)
8 cm 1.4 GB DVD-R discs
(for General Ver. 2.0)
Max. 6 hours
XP: 60 minutes
SP: 120 minutes
LP: 240 minutes
EP: 360 minutes
Max. 104 hours
XP: 17 hours
SP: 34 hours
LP: 68 hours
EP: 104 hours
(continuous recording time is 6 hours max.)
Region No.1
12 cm 4.7 GB DVD-RAM discs
12 cm 9.4 GB DVD-RAM discs
8 cm 2.8 GB DVD-RAM discs
12 cm 4.7 GB DVD-R discs
(for General Ver. 2.0)
8 cm 1.4 GB DVD-R discs
(for General Ver. 2.0)
DVD-VIDEOdiscs
Page 1 of 3

Advertisement

loading

Related Manuals for Panasonic DMR-E80HP

Summary of Contents for Panasonic DMR-E80HP

  • Page 1 Page 1 of 3 Service Manual TOP NEXT ORDER NO.DSD0306005C1 DVD Video Recorder DMR-E80HP DMR-E80HPC Colour (S).......Silver Type Specifications Power supply: AC120 V, 60 Hz Power consumption: 35 W Recording system: DVD video recording standards (DVD-RAM), DVD video standards (DVD-R)
  • Page 2 Page 2 of 3 CD-Audio discs (CD-DA) Video CD discs DVD-Audio discs CD-R/ CD-RW discs (CD-DA, Video CD, MP3 formatted discs) Video system TV system: NTSC system, 525 lines, 60 fields Recording system: MPEG2 (Hybrid VBR) Input: LINE (pin jack), 1.0 Vp-p; 75 S connector Y: 1.0 Vp-p;...
  • Page 3 Page 3 of 3 © 2003 Matsushita Electric Industrial CO., Ltd. All rights reserved. Unauthorized copying and distribution is a violation of law. TOP NEXT 11/18/2008...
  • Page 4 Page 1 of 1 11/18/2008...
  • Page 5 Page 1 of 1 11/18/2008...
  • Page 6 Page 1 of 1 11/18/2008...
  • Page 7 Page 1 of 27 17 Replacement Parts List TOP PREVIOUS NEXT Notes: *Important safety notice: Components identified by mark have special characteristics important for safety. Furthermore, special parts which have purposes of fire-retardant (resistors), high-quality sound (capacitors), low-noise (resistors), etc. are used. When replacing any of components, be sure to use only manufactures specified parts shown in the parts list.
  • Page 8 FRONT ORNAMENT(R) 20-11 RGK1622-K FRONT ORNAMENT(L) 20-12 RKF0667-K TRAY DOOR 20-13 VMB3410 BLINDER SPRING 20-14 XTN2+6G SCREW 20-15 VGB0560 PANASONIC BADGE 20-16 RMC0539 EARTH PLATE 20-17 RGL0620-Q LIGHTING PIECE 20-18 RKF0666E-S PANEL DOOR 20-19 XTBS26+8J SCREW 20-20 RMA1639 FRONT ANGLE...
  • Page 9 Page 3 of 27 XTW3+6M SCREW EUR7624KB0 REMOTE CONTROL ASS’Y A1-1 UR76EC2403A BATTERY COVER K2KA6CA00001 A/V CORD K2CB2CB00006 AC CORD VJA1091 RF COAXIAL CABLE K1TXAAA00001 RPQF0250 ACCESSORY CASE RPQ1594 RQF5175 FAN BAG ASS’Y RQF5253 FAN BAG ASS’Y (PC) A7-1 RPF0378 POLYETHYLENE BAG(F.B.) (PC) A7-1...
  • Page 10 Page 4 of 27 C3010 ECUV1H680JCV 50V 68P ECJ1VC1H680J C3011 ECJ1VC1H390J 50V 39P C3012 ECJ1VB1H103K 50V 0.01U C3013 ECEA0JKS470 6.3V 47U C3014 ECJ1VC1H220J 50V 22P C3016 ECJ1VC1H220J 50V 22P C3017 ECJ1VB1H103K 50V 0.01U C3018 ECJ1VC1H220J 50V 22P C3019,20 ECJ1VC1H330J 50V 33P C3022 ECJ1VB1H103K 50V 0.01U...
  • Page 11 Page 5 of 27 C3086-91 ECJ1VB1H103K 50V 0.01U C3092 ECJ1VB1C104K 16V 0.1U C3093,94 ECJ1VB1H103K 50V 0.01U C3095 ECEA0JKS470 6.3V 47U C3096 ECJ1VB1C104K 16V 0.1U C3097 ECJ1VC1H220J 50V 22P C3098 ECJ1VC1H150J 50V 15P C3099 ECJ1VC1H220J 50V 22P C3100 ECJ1VB1H103K 50V 0.01U C3101,02 ECEA0JKS470 6.3V 47U...
  • Page 12 Page 6 of 27 C4902 ECJ1VF1C104Z 16V 0.1U C4903 F2A0J470A179 6.3V 47U C4904 ECJ1VF1C104Z 16V 0.1U C4906 ECJ1VC1H220J 50V 22P C7404 ECJ1VB1H103K 50V 0.01U C7405 F2A0J470A013 6.3V 47U C7411 ECJ1VB1C104K 16V 0.1U C7412 F2A1A470A140 10V 47U C7416 ECJ1VB1H103K 50V 0.01U C7417 F2A1H1R0A147 50V 1U...
  • Page 13 Page 7 of 27 D7513,14 B0JACE000001 DIODE DP7501 A2BD00000070 FL DISPLAY TUBE IC1502 C0DBEFG00002 IC1504 C0DBZGG00010 IC1505 C0DBZHG00012 IC1508 C0DBZHE00014 IC1513 C0DBZHE00014 IC3002 C2BBFE000137 IC3003 C1AB00001805 IC3005 C9ZB00000377 IC4002 C0JBAR000285 IC4003 C0ABBB000118 IC4009 C0ABBB000118 IC4010 C0DBZJG00006 IC4011 C0DBZHG00012 IC4012 C0ABBB000118 IC7405 C0BBBB000006 IC7501...
  • Page 14 Page 8 of 27 L3019 VLQ0599J6R8 COIL 6.8UH G0C6R8JA0026 L3020 G0C120JA0019 COIL 12UH L3021 VLQ0599J6R8 COIL 6.8UH G0C6R8JA0026 L3022,23 G0C120JA0019 COIL 12UH L4901 ELESE220KA COIL 22UH L7501 ELESE101K COIL 100UH L7502 G0C220JA0019 COIL 22UH LB1501-05 J0JHC0000032 COIL LB3001 VLP0323A601T COIL J0JCC0000103 LB3901-04 VLP0323A601T...
  • Page 15 Page 9 of 27 QR3002 UN5213TX TRANSISTOR UNR521300L QR3004,05 UN5211 TRANSISTOR UNR5211 QR3006-10 UN5213TX TRANSISTOR UNR521300L QR3011 UN5113TW TRANSISTOR QR4002-07 UN5211 TRANSISTOR UNR5211 QR4010-12 UN5211 TRANSISTOR UNR5211 QR7401 UN5213TX TRANSISTOR UNR521300L QR7501 UN5212TX TRANSISTOR UNR521200L QR7504 UN5113TW TRANSISTOR R1501 ERJ3GEY0R00V 1/16W 0 R1502 ERJ3GEYJ471V...
  • Page 16 Page 10 of 27 R3049,50 ERJ3GEYJ151V 1/16W 150 R3051 ERJ3GEYJ222V 1/16W 2.2K D0GB222JA002 R3052 MCR03PZHJ561 1/16W 560 R3053 ERJ3GEYJ103V 1/16W 10K D0GB103JA002 R3054 ERJ3GEYJ104 1/16W 100K R3055 ERJ3GEYJ102V 1/16W 1K R3056 ERJ3GEYJ222V 1/16W 2.2K D0GB222JA002 R3057 ERJ3GEYJ471V 1/16W 470 R3058 ERJ3GEYJ103V 1/16W 10K D0GB103JA002...
  • Page 17 Page 11 of 27 R4024 ERJ3GEYJ562V 1/16W 5.6K D0GB562JA002 R4026 ERJ3GEYJ183V 1/16W 18K D0GB183JA002 R4030 ERJ3GEYJ103V 1/16W 10K D0GB103JA002 R4037,38 ERJ3GEYJ184V 1/16W 180K R4040-43 ERJ3GEYJ184V 1/16W 180K R4044,45 ERJ3GEY0R00V 1/16W 0 R4046,47 D0HB752ZA002 1/16W 7.5K R4048 ERJ3GEYJ184V 1/16W 180K R4049-54 ERJ3GEYJ683V 1/16W 68K D0GB683JA002...

  • Page 18: Tuner Pack

    Page 12 of 27 R7522,23 ERJ3GEYJ104 1/16W 100K R7524 ERJ3GEYJ101 1/16W 100 D0GB101JA002 R7525 ERJ3GEYJ473V 1/16W 47K D0GB473JA002 R7526,27 ERJ3GEYJ101 1/16W 100 D0GB101JA002 R7528 ERJ3GEYJ221V 1/16W 220 R7529-31 ERJ3RBD822 1/16W 8.2K R7532-34 ERJ3GEYJ101 1/16W 100 D0GB101JA002 R7536 ERJ3GEYJ472V 1/16W 4.7K R7537 ERJ3GEYJ223V 1/16W 22K...

  • Page 19: Crystal Oscillator

    Page 13 of 27 X7502 H0D419400020 CRYSTAL OSCILLATOR ZJ7401 VJR0978 EARTH ANGLE K9ZZ00000424 ZJ9701 VJR0978 EARTH ANGLE K9ZZ00000424 REP3496F/REP3496FG C3201 EEE0JA220SR 6.3V 22U C3202 ECJ1VB1C104K 16V 0.1U C3203 ECJ1VB1H222K 50V 2200P C3205 ECJ1VB1C104K 16V 0.1U C3207 ECJ1VB1H103K 50V 0.01U C3208 ECJ1VB1C104K 16V 0.1U C3211...
  • Page 20 Page 14 of 27 C50026,27 EEE1CA100SR 16V 10U C50028 ECJ1VF1C104Z 16V 0.1U D3201,02 MA3S132E0L DIODE D3203,04 MA2ZV0100L DIODE D9001 MA3Z142K0LG DIODE FL3201 F1H0J1050018 FILTER FL3205-13 F1H0J1050018 FILTER FL3216 F1H0J1050018 FILTER FL3218 F1H0J1050018 FILTER FL3220 F1H0J1050018 FILTER FL3225 F1H0J1050018 FILTER FL3401-06 F1H0J1050018 FILTER FL3409-19...
  • Page 21 Page 15 of 27 IC6006 C3CBKD000119 IC6007 74LCX16244MT C0JBAZ001475 IC6701 C1ZBZ0002255 IC6702 C0JBAB000474 IC6704 REP3496F (P)DIGITAL P.C.B. IC6704 REP3496FG (PC)DIGITAL P.C.B. IC9001 C0DBZFE00003 IC50001 C1DB00000895 IC50002 C3ABPG000063 IC50003 MN6775511 IC50004 C3ABPG000063 IC50005 C0JBAR000332 IC50006 C0JBAB000474 IC50010 C0FBBK000035 IC50011 C0CBCBD00002 IC50013 C0JBAD000107 IC50014 C0JBAF000206...
  • Page 22 Page 16 of 27 QR3402,03 UN5213TX TRANSISTOR UNR521300L QR9001 UNR511100L TRANSISTOR QR9005 UN5213TX TRANSISTOR UNR521300L R3202 ERJ3GEY0R00V 1/16W 0 R3204 ERJ3GEYJ103V 1/16W 10K D0GB103JA002 R3205 ERJ3GEYJ622V 1/16W 6.2K R3206 ERJ3GEYJ103V 1/16W 10K D0GB103JA002 R3211,12 ERJ3GEYJ223V 1/16W 22K D0GB223JA002 R3216 ERJ3GEYJ103V 1/16W 10K D0GB103JA002 R3217,18...
  • Page 23 Page 17 of 27 R6005 ERJ3GEYJ333V 1/16W 33K D0GB333JA002 R6006 ERJ3GEYJ103V 1/16W 10K D0GB103JA002 R6007-09 ERJ3GEYJ470V 1/16W 47 R6010 ERJ3GEYJ102V 1/16W 1K R6011 ERJ3GEYJ103V 1/16W 10K D0GB103JA002 R6013,14 ERJ3GEYJ330V 1/16W 33 D0GB330JA002 R6015 ERJ3GEYJ105V 1/16W 1M R6016 ERJ3GEYJ103V 1/16W 10K D0GB103JA002 R6017 ERJ3GEYJ470V...
  • Page 24 Page 18 of 27 R50022 ERJ3GEYJ102V 1/16W 1K R50023 ERJ3GEYJ330V 1/16W 33 D0GB330JA002 R50024 ERJ3GEY0R00V 1/16W 0 R50025 ERJ3RED750V 1/16W 75 R50026 ERJ3GEYJ102V 1/16W 1K R50027 ERJ3GEYJ330V 1/16W 33 D0GB330JA002 R50030 ERJ3RED750V 1/16W 75 R50031 ERJ3GEYJ102V 1/16W 1K R50032 ERJ3GEYJ330V 1/16W 33 D0GB330JA002 R50033...
  • Page 25 Page 19 of 27 RX6009-12 D1H84704A024 RESISTOR-RESISTOR RX6013-17 D1H83304A024 RESISTOR-RESISTOR RX6018 D1H82204A024 RESISTOR-RESISTOR RX6019 D1H83304A024 RESISTOR-RESISTOR RX6020 D1H84704A024 RESISTOR-RESISTOR RX6021 D1H83304A024 RESISTOR-RESISTOR RX6022 D1H84704A024 RESISTOR-RESISTOR RX6025 D1H83304A024 RESISTOR-RESISTOR RX6026 D1H84704A024 RESISTOR-RESISTOR RX6027 D1H81034A024 RESISTOR-RESISTOR RX6030-33 D1H84704A024 RESISTOR-RESISTOR RX6034-48 D1H83304A024 RESISTOR-RESISTOR RX6701,02 D1H83324A024 RESISTOR-RESISTOR...
  • Page 26 Page 20 of 27 JK7001 K1U413A00005 JACK,L2 K7002 ERJ3GEY0R00V 1/16W 0 LB7001-05 VLP0323A601T COIL J0JCC0000103 P7001 K1KA20B00132 CONNECTOR(20P) QR7002,03 UN2214 TRANSISTOR UNR2214 R7002 ERJ3GEYJ102V 1/16W 1K R7006,07 ERJ3GEYJ221V 1/16W 220 R7008-10 ERJ3GEYJ750 1/16W 75 R7011 ERDS2FJ330 1/4W 33 S7002 K0H1BA000372 SWITCH,HDD S7003 EVQ11G07K...
  • Page 27 Page 21 of 27 S7809 EVQ11G07K SWITCH,MODE S7810 EVQ11G07K SWITCH,EARSE S7811 EVQ11G07K SWITCH,TIME-WARP S7812 EVQ11G07K SWITCH,PLAY S7815 EVQ11G07K SWITCH,SKIP-F S7816 EVQ11G07K SWITCH,OPEN/CLOSE S7817 K0H1BA000372 SWITCH,DVD REP3542A P9801 K1KB40A00118 CONNECTOR(40P) P9802 K1MN40B00022 CONNECTOR(40P) ETXMM447A4G C001 KH101K 100P C002 KH222M 2200P C003 ECQU2A104ML C004 ECQU2A224ML...
  • Page 28 Page 22 of 27 C121 KY1A471 10V 470 C122 KMG1E470 25V 47 C123 KY0J152 6.3V 1500 C124 TBB224K2 25V 0.22 C125 KY1A221 10V 220 C126 KY1A471 10V 470 C127 KMG1V470 35V 47 C128 MBB104K2 25V 0.1 C129 MBC101K2D 200V 100P C130 ECQB1H102JF 50V 1000P...
  • Page 29 Page 23 of 27 IC102 AN1431T IC103 NJM431U IC301,02 NJM2904M C0ABBA000021 IP101 ICPN15 IC PROTECTOR IP102 ICPN25 IC PROTECTOR L001,02 ELF15N005A COIL L003 LAV35VB150K COIL L004,05 EXCELDR35 COIL L101 EXCELSA24 COIL L103 EXCELSA24 COIL L105 EXCELDR35 COIL L106 LHLZ1R5M COIL L107 EXCELDR35 COIL...
  • Page 30 Page 24 of 27 Q111 2SB709A TRANSISTOR 2SB0709A Q112 2SD965 TRANSISTOR Q113 2SD601A-R TRANSISTOR 2SD0601AR Q301 2SK3366 TRANSISTOR Q302 2SD602A-R TRANSISTOR 2SD0602AR Q303 2SB710A TRANSISTOR 2SB0710A Q304 2SD2000 TRANSISTOR Q305 2SB1218A TRANSISTOR Q306 2SD601A-R TRANSISTOR 2SD0601AR Q307 2SD1328-R TRANSISTOR 2SD13280R Q308 2SB1218A TRANSISTOR...
  • Page 31 Page 25 of 27 R127 CR10J101 0.1W 100 R128 CR10J561 0.1W 560 R129 CR10J101 0.1W 100 R130 ERDS2FJ121 0.25W 120 R131 CR10J102 0.1W 1K R132 CR10J471 0.1W 470 R133,34 CR10J682 0.1W 6.8K R135 ER0S2TKF1430 0.25W 143 R136 CR10J822 0.1W 8.2K R137 CR10J102 0.1W 1K...
  • Page 32 Page 26 of 27 R318 CR10J223 0.1W 22K R319 CR10F2210 0.1W 221 R320 CR10J223 0.1W 22K R321 CR10F2210 0.1W 221 R322 CR10F1002 0.1W 10K R323 CR10F3321 0.1W 3.32K R324 CR10J103 0.1W 10K R325 CR10F1002 0.1W 10K R326 CR10F3321 0.1W 3.32K R327 CR10J103 0.1W 10K...
  • Page 33 Page 27 of 27 RFKZ0164 EXTENSION CABLE (30P~3) MAIN-DIGITAL P.C.B. RFKZ0165 EXTENSION CABLE (20P) FRONT(L)-MAIN P.C.B. RFKZ0166 EXTENSION CABLE (10P) FRONT(R-POWER SUPPLY P.C.B. RFKZ0168 EXTENSION CABLE (3P) FAN MOTOR RFKZ0169 EXTENSION CABLE (4P) HDD-POWER SUPPLY P.C.B. RFKZ0170 EXTENSION CABLE (19P) MAIN-POWER SUPPLY P.C.B.
