- Page 1 SOLID FUEL RANGE COOKERS TYPE 9105 TYPE 9107 OPERATION & MAINTENANCE MANUAL INSTALLATION MANUAL TYPE 9105, 9107 07/2014...
- Page 2 TYPE 9105, 9107 07/2014...
- Page 3 OPERATION & MAINTENANCE MANUAL Dear customer, Thank you for purchasing of the appliance KVS MORAVIA - solid fuel range cooker. We trust that our product serves you well. Some important principles should be observed during its operation. Therefore, in your interest, carefully study this manual and operate the product according to the given instructions.
- Page 4 Technical Specifications - TYPE 9105 The TYPE 9105 appliance has been designed for solid fuel combustion in periodic feed rates and it is intended for cooking and in households and/or for heating the space in which it is situated, according to the ČSN EN 12815:2002 Standard as amended A1:2005.
- Page 5 Description - TYPE 9105 1. Hob Top 2. Front door 3. Fuel case Drawing 1 The upper working surface comprises a hob-top. The appliance casing is made of enamelled steel plates. The thermally stressed parts of the appliance are made of cast iron and fireclay.
- Page 6 Width x Height х Depth 230 х 330 x 250 mm Fire grate, Width х Depth 140 х 240 mm Stokehole, Width x Height 167 х 115 mm Accessories Poker 1 pc. Blinding disc 1 set TYPE 9105, 9107 07/2014...
- Page 7 *The hotplate lid is supplied upon the customer’s request only. NOTE: The manufacturer reserves the right to carry out small changes resulting from innovative or technical changes of the product that will have no detrimental affect on the function of the appliance. TYPE 9105, 9107 07/2014...
- Page 8 (danger of overheating). Ventilation levels are provided in your local building regulations. It is advised to check ventilation issues with your local building control office to ensure trouble free operation. Drawing 3 Drawing 4 TYPE 9105, 9107 07/2014...
- Page 9 You should always use pots with flat bases. Drawing 5 – Type 9105 Drawing 6 – Type 9107 (all of this dimensions are in mm)
- Page 10 Chimneys and flue ducting to which solid fuel are connected shall be swept 2 times or 3 times a year – seasonal or yearlong operation (for example according to the Czech governments Decree No. 91/2010 Coll.). Routine operation, especially due to damp fuel, soot and tar creates deposits TYPE 9105, 9107 07/2014...
- Page 11 Easily flammable sarking felt, cellulose boards, tar panels, wood-pulp fibre, BA corkboards, rubber, polyurethane, polystyrene, polypropylene, polyethylene, textile, organic glass .. Warning for places where burns can occur: hob-top, hob frame • combustion chamber door • TYPE 9105, 9107 07/2014...
-
Page 12: Appliance Operation
If the dirt bakes in, it is more difficult to remove later. From time to time (depending on the frequency of operation) wipe the range down with vegetable oil. TYPE 9105, 9107 07/2014... -
Page 13: Cleaning And Maintenance
-put out of service, do not stoke, close the air grid, let fire burn Fire in the chimney -do not use water to extinguish the fire -close all of the air intakes, cover the chimney if possible -contact a qualified chimney sweep service -contact the manufacturer or your supplier TYPE 9105, 9107 07/2014... -
Page 14: Disposal Of Packaging
NOTE: The manufacturer reserves the right to carry out small changes resulting from innovative or technical changes of the product that will have no detrimental affect on the function of the appliance. TYPE 9105, 9107 07/2014... -
Page 15: Important Notice
Drawing 7 Important notice 1. Production standards KVS MORAVIA solid fuel appliances are produced in accordance ČSN EN12815:2002 Standard with amended A1:2005, which is valid for the Czech Republic and European Union. 2. Installation and operation standards All the above installation and operation instructions for the appliances primarily comply with the... - Page 16 Dimensional Sketch of the appliance (all of dimensions are in mm) TYPE 9105 TYPE 9107 TYPE 9105, 9107 07/2014...
- Page 17 TYPE 9105, 9107 07/2014...
-
Page 18: Czech Republic
Producer: KVS EKODIVIZE a.s. (Inc.) – branch plant Dvorce Opavská 272, 793 68 Dvorce u Bruntálu CZECH REPUBLIC phone: +420 554 797 131 fax: +420 554 745 500 email: prodej.dvorce@kvs-ekodivize.cz www.kvs-ekodivize.cz www.kvs-moravia.cz TYPE 9105, 9107 07/2014...
