- Page 1 SOLID FUEL RANGE COOKER WITH HOT WATER HEATER TYPE 9112-HEU OPERATION & MAINTENANCE MANUAL INSTALLATION MANUAL TYPE 9112-HEU 07/2014...
- Page 2 Law No. 258/2000 Coll., the Ministry of Health Decree No. 38/2001 Coll., and Regulation No. 207/2006 Coll. of the Czech Republic. KVS EKODIVIZE, a. s. Chairman of the Board of Directors TYPE 9112-HEU 07/2014...
- Page 3 OPERATION & MAINTENANCE MANUAL Dear customer, Thank you for purchasing of the appliance KVS MORAVIA - solid fuel range cooker with heat exchange unit for connection to central heating hot water system. We trust that our product serves you well. Some important principles should be observed during its operation. Therefore, in your interest, carefully study this manual and operate the product according to the given instructions.
- Page 4 Technical Specifications TYPE 9112-HEU The TYPE 9112-HEU appliance has been designed for solid fuel combustion in periodic feed rates and it is intended for cooking and baking in households and/or for heating the space in which it is situated, according to the ČSN EN 12815:2002 Standard as amended A1:2005.The appliance can be connected to a chimney from the back, both sides or from the top by means of a hole in the Hob-Top (Drawing 1).
- Page 5 8. Thermometer 3. Oven Door 9. Ash chamber Door 4. Combustion chamber (Fire-box) Door 10. Grate bar 5. Hand Rail 11. Smoke Flap Control 6. Sweeping Door 12. Combustion Air Intake Control 13. Secondary combustion air lever TYPE 9112-HEU 07/2014...
- Page 6 In the course of cleaning take off the hob top plates, then remove the soot first from the sides of the oven walls. Clean all the removed deposits through the ash extracting slot situated under the oven door. This can be done simply by using damp newspaper, for example. TYPE 9112-HEU 07/2014...
- Page 7 (Flap closed) Drawing 3 Following ignition, after the fire has caught, close the ignition flap and operate the appliance with the ignition flap closed. This will influence the flow of flue-gas and increase the efficiency of the appliance. TYPE 9112-HEU 07/2014...
-
Page 8: Appliance Operation
In the area above the oven the range has a lower temperature - this part of the range is suitable for slow cooking and for keeping food war. Use pots with a flat bottom for best results. TYPE 9112-HEU 07/2014... - Page 9 45°C. If the thermostat exceeds the recommended water temperature, this is likely to cause heat damage. Note: For the purpose of taking surplus heat from the heat exchange unit, we recommend to use additional heating device. TYPE 9112-HEU 07/2014...
-
Page 10: Cleaning And Maintenance
-put out of service, do not stoke, close the air grid, let fire burn Fire in the chimney -do not use water to extinguish the fire -close all of the air intakes, cover the chimney if possible -contact a qualified chimney sweep service -contact the manufacturer or your supplier TYPE 9112-HEU 07/2014... -
Page 11: Disposal Of Packaging
Important notice 1. Production standards KVS MORAVIA solid fuel appliances are produced in accordance ČSN EN12815:2002 Standard with amended A1:2005, which is valid for the Czech Republic and European Union. 2. Installation and operation standards All the above installation and operation instructions for the appliances primarily comply with the... - Page 12 – seasonal or yearlong operation (for example according to the Czech governments Decree No. 91/2010 Coll.). Routine operation, especially due to damp fuel, soot and tar creates deposits in the chimney. If regular inspection and chimney cleaning are omitted, the probability of a fire in the chimney increases. TYPE 9112-HEU 07/2014...
- Page 13 Easily flammable sarking felt, cellulose boards, tar panels, С wood-pulp fibre, phellem, polyurethane, polystyrene, polypropylene, polyethylene. Warning for places where burns can occur: hob-top, hob frame • combustion chamber door, oven door • oven inner walls • TYPE 9112-HEU 07/2014...
- Page 14 The cooker cannot be used unless it is connected to a functioning water system even during • the summer months, otherwise the heat exchanger will be overheated and thus permanently damaged. Flue gas ducting connection to the chimney (valid for Czech Republic) correct wrong Drawing 4 TYPE 9112-HEU 07/2014...
- Page 15 Dimensional Sketch of the appliance TYPE 9112 (All of dimensions are in mm) TYPE 9112-HEU 07/2014...
- Page 16 Installation schematic of the range cooker with a heat exchange unit within the interior of a domestic dwelling TYPE 9112-HEU 07/2014...
- Page 17 NOTE: The valves, a pump and other safety accessories are not supplied with the cooker! TYPE 9112-HEU 07/2014...
- Page 18 Spare parts sketch – part 1 TYPE 9112-HEU 07/2014...
- Page 19 Spare parts sketch – part 2 TYPE 9112-HEU 07/2014...
- Page 20 Ash chamber door frame 020B Ash chamber door 020C Air rose 020D Air rose handle 020E Insulation cord Ø8 (0,73m) Sweeping door with frame 021A Sweeping door frame 021B Sweeping door 021C Insulation cord Ø8 (0,86m) Plate Side panel TYPE 9112-HEU 07/2014...
- Page 21 TYPE 9112-HEU 07/2014...
-
Page 22: Czech Republic
Producer: KVS EKODIVIZE, a. s. plant Dvorce Opavská 272 793 68 Dvorce u Bruntálu CZECH REPUBLIC phone: +420 554 797 111 fax: +420 554 745 500 email: prodej.dvorce@kvs-ekodivize.cz www.kvs-ekodivize.cz TYPE 9112-HEU 07/2014...
