2. Specifications

Display
dimensions
Panel
Resolution
Net dimensions
Net weight
Temperature
Ambient
conditions
Relative humidity
Power supply
Power consumption/at standby
Audio output
(RGB input)
Input terminals
Input signals
Video signals
Sync signals
(Video input)
Input terminals
Input signals
Video signals
Video output Signal
(RF input)
Input terminals
Input signals
RF Video System
Applicable video signals for each input terminal
Downloaded From TV-Manual.com Manuals
Approx. 28 inches (599.04 (H) x 359.42 (V) mm)
1280 (H) x 768 (V) pixels
854 (W) x 516 (H) x 277 (D) mm
21.9kg
Operating : 5 C to 35 C, Storage : 0 C to 60 C
Operating : 20% to 80%, Storage : 20% to 90% (non-condensing)
AC100 - 240V, 50/60Hz
155W / <1W
12W + 12W (6 )
RGB1 DVI input terminal (DVI-D)
RGB1 audio input terminal (3.5mm Stereo Mini Jack)
RGB2 analog RGB input terminal (D-sub 15-pin)
RGB2 audio input terminal (3.5mm Stereo Mini Jack)
0.7 V/1.0 Vp-p, analog RGB (Recommended Signal)
480i, 576i, 480p, 576p, 1080i/50, 1080i/60, 720p/60
H/V separate, TTL level [2K ]
H/V composite, TTL level [2K ]
Sync on green, 0.3 Vp-p [75 ]
AV1: composite video input terminal (RCA)
AV1: Y PB PR video input terminal (RCA)
AV1: L/R audio input terminal (RCA)
AV2: composite video input terminal (RCA)
AV2: Y/G PB/B PR/R video input terminal (RCA)
AV2: L/R audio input terminal (RCA)
AV3: composite video input terminal (RCA)
AV3: S video input terminal (RCA)
AV3: L/R audio input terminal (RCA)
AV4: composite video / S video / RGB / L/R audio input terminal (Scart)
AV1: PAL, SECAM, NTSC3.58, NTSC4.43
AV1: 480i, 576i, 480p, 576p, 1080i/50, 1080i/60, 720p/60
AV2: PAL, SECAM, NTSC3.58, NTSC4.43
AV2: 480i, 576i, 480p, 576p, 1080i/50, 1080i/60, 720p/60, RGB
AV3: PAL, SECAM, NTSC3.58, NTSC4.43
AV4: PAL, SECAM, NTSC3.58, NTSC4.43
AV4: RGB
OUTPUT (MONITOR): composite video monitor-output terminal (RCA)
OUTPUT (MONITOR): L/R audio monitor- output terminal (RCA)
AV4: composite video / L/R audio output terminal (SCART)
ANT : 75 Unbalanced
PAL B, G, H / I / D, K
Terminal RCA/SCART
Signal CVBS S-video
AV1
AV2
AV3
AV4
RGB1
RGB2
28LD5200E (PW1L)
SECAM B, G / D, K / K1
DVI
Component RGB PC
4
D-sub
STB RGB Component
( :Available)
